Timer - Timm(20) - Omron SYSMAC mini SP10 Operation Manual

Instruction Set
TIM 02
0000
TIM 01
TIM 01
0000
0103
0000 0308
3-7-15

TIMER - TIMM(20)

Limitations
86
TIM 01
TIM 02
1.0 s 1.5 s 1.0 s 1.5 s
A simpler but less flexible method of creating a flicker bit is to AND one of the
dedicated clock pulse bits with the execution condition that is to be ON when
the flicker bit is operating. Although this method does not use TIM, it is in-
cluded here for comparison. This method is more limited because the ON
and OFF times must be the same and they depend on the clock pulse bits
available.
In the following example the 1-second clock pulse is used (0308) so that
0101 would be turned ON and OFF every second, i.e., it would be ON for 0.5
seconds and OFF for 0.5 seconds. Precise timing and the initial status of
0101 would depend on the status of the clock pulse when 0000 goes ON.
Ladder Symbol
TIMM(20) N
SV is between 00.00 and 99.99 seconds. The decimal point is not entered.
Each TC number can be used as the definer in only one timer or counter in-
struction.
TC 11 through TC 15 should not be used in TIMM(20) if they are required for
the specific instruction to which they are assigned. Refer to the table on page
82.
Address Instruction
000 LD
#0010
1.0 s
001 AND NOT
002 TIM
#0015
1.5 s
003 LD
004 TIM
0103
005 LD
006 OUT
Address Instruction
000 LD
0101
001 AND
002 OUT
Operand Data Areas
SV
SP16, SP20: I/O, work, DR, LR, #
Section 3-7
Operands
0000
TIM 02
01
# 0010
TIM 01
02
# 0015
TIM 01
0103
Operands
0000
0308
0101
Definer Values
N: TC number
# (00 through 15)
SV: Set value (BCD)
SP10: #
