Chapter 2 — Installation

Display

Keyboard

14
The display window contains an LCD (Liquid Crystal Display)
with background illumination and two lines of text, each with 16
characters. It shows a message when certain errors occur and
guides the operator through upgrading, startup, and setup. The
following errors are reported:
Error Messages and Conditions
Message Displayed
PAUSE
PAPER OUT
RIBBON OUT
PRINT HEAD UP/PRESS
FEED
OPEN&SHUT CUTTER
RIBBON FITTED
PAPER FAULT
The keyboard is of the membrane-switch type and has seven keys,
plus one large "Feed/Pause" button. Some keys have hard-coded
functions in Startup and Setup modes.
Feed/Pause button
Error Condition
Empty/Paused
Out of media
Out of ribbon
Printhead lifted
Cutter error
Ribbon fitted
Paper fault
Feeds a page or pauses a print job. Also can
repeat last printed label.
Enter Setup Mode. For more information, see
"Setup Mode" on page
Chapter 6,
Display error message and communication
channel information.
Scroll between types of information after
pressing the Information key. Possible error
messages and information on active
communications channels are shown in a loop.
EasyCoder PF4i User's Guide (IPL Version)
61.
