Interface Cable

Optional Interfaces

EasyCoder PF4i User's Guide (IPL Version)
* The external +5V is limited to 500 mA and is automatically
switched off at overload.
Computer end: Depends on computer model
Printer end: DB-9 plug
The printer can optionally be fitted with an IEEE 1284 Parallel
Interface Board at the right-hand side of the printer's rear plate.
The printer can also be fitted with one of the following EasyLAN
interface boards for connection to a Local Area Network (LAN).
• EasyLAN Ethernet Interface
• EasyLAN Wireless Interface
IEEE 1284 Parallel Interface Board
EasyLAN Ethernet Interface
Chapter C — Interfaces
Parallel interface connector
RJ-45 EasyLAN connector
119
