Command
* (STATUS)
7, 1
7, 2
7, 4
7, 6
7, 7, n (n = output number [1to6])
1 to 2 = onboard outputs;
3 to 6 = module outputs
8, code, 2
8, code, 3
8, installer code, 3
8, code, 6
8, code, 8
0, 0
0, n (n = light number 1 to 9)

Zones/sensors

Test sensors/zones after all programming is completed; whenever there is a change
in environment, equipment, or programming; and whenever a zone- or sensor-
related problem occurs.
If the system does not respond as described in the following procedure, see
Troubleshooting.
Note: While the sensor test is a valuable installation and service tool, it only tests
sensor operation for the current conditions. You should perform a sensor test after
any change in environment, equipment, or programming.
To test zones/sensors:
1. Place all sensors and zones in their nonalarm state.
2. At an alphanumeric touchpad, enter the sensor test mode by pressing 8, installer
code, 3. The touchpad sounds one beep and displays SENSOR TEST. The panel
starts a 15-minute timer.
3. Trip each zone/sensor one at a time. Touchpads (and interior sirens) should sound
one short, high-pitched beep, and the display should show the sensor name (or
number) and OK.
Concord 4 Installation Manual
System response
Indicates current system status
Turns chime feature on and off
Turns energy saver on and off
Partition jump without entering code (only if partition
security option is off)
Identifies alarms in memory
Turns the output on or off. (This command is only functional
after output text is entered into panel memory.)
Initiates a phone test
Initiates a sensor test
Initiates a dealer sensor test
Partition jump
View event history
Turns all controlled lights on and off
Turns individual controlled light on and off
Chapter 4: Testing and troubleshooting
