System event triggers

Table 26 below describes the system event triggers.
Table 26: System event trigger
System event
Null trigger (used for direct control)
Fire alarm
Police alarm
Auxiliary alarm
Any audible alarm
Silent alarm (sensor groups 2, 3, and
duress)
Any audible or silent alarm
HOM group 27, 28, 32 in alarm
Major trouble (phone or receiver
failure)
Arming to stay or away
Arming to away
AVM is interactive (audio session in
progress)
Fail-to-communicate (panel can't
call CS or pager)
AVM trip (edge)
Keychain touchpad star button-
press
Smoke power (for resetting four-wire
smoke detectors)
Exterior siren
Interior siren
AVM trip (pulse)
State of system status
Tamper condition
130
Description
Activates only by schedule or direct command.
When fire sirens are started.
When police sirens are started.
When auxiliary sirens are started.
When any of the above sirens are started.
When a group 2 or 3 sensor goes into alarm or
when a duress alarm is activated (does not
include groups 25, 27, 28, or 32).
When any alarm is started (does not include
groups 25, 27, 28, or 32).
When a sensor in group 27, 28, or 32 goes into
alarm.
When a receiver failure (S94) or a phone failure
(S96) occurs.
When the system is armed to level 2 or 3.
When the system is armed to level 3.
When the central station operator begins
listening or talking to the premises.
When the fail-to-communicate output is
activated.
When an AVM alarm occurs, output is activated
momentarily.
When the star button on a keychain touchpad is
pressed.
Deactivated when hardwire smoke detectors
need to be reset.
Activated for police or fire alarms.
Activation follows all system noises
When an AVM alarm occurs, output is
deactivated for 10 ms
Follows the state of system status (ready or
trouble).
When any tamper is tripped
Trigger
number
000
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
016
017
018
019
020
