Accessory modules menu

The Accessory modules menu gives you access to the following menus:
Bus devices: Use these settings to read bus device unit numbers, assign bus devices
to a partition, and configure other features associated with a specific bus device.
(Most bus device settings do not have shortcut numbers).
SnapCards: Use these settings to set the configuration number for each SnapCard
output, assign SnapCard outputs to a partition, and name the SnapCard outputs.
Accessory modules - bus device settings
Unit-ID
Shortcut: 10000 to
10015
Default: **** or None
Device ID
Default: None
Concord 4 Installation Manual
This menu lets you identify all connected bus devices, view each unit
number, view the device ID number, and configure other settings based on
a specific device. This menu also lets you delete learned bus devices.
To help identify bus devices, the 8-digit device ID number is also located on
a label on each SuperBus 2000 device.
To identify bus device unit and ID:
1. With the display showing BUS DEVICES, press #. The display shows the
bus unit number and the 8-digit device ID number. For example: UNIT -
ID 0—02110185. Where 0 is the unit number and 02110185 is the device
ID number.
2. Press A or B to identify all other bus unit numbers (0 to 15) and device ID
numbers.
To delete learned unit numbers:
1. With the display showing BUS DEVICES, press #. The display shows the
bus device set to unit number 0.
2. Press A or B until the bus device unit number you want to delete is
displayed.
3. Press D. The display changes the unit number to None.
This menu lets you change the bus device ID number when replacing a
defective bus device.
To change a device ID:
1. With the display showing the desired bus device, press #, #. The display
shows DEVICE ID (current ID).
2. Enter the ID of the new bus device. The display flashes the entered
selection. Press # and the display shows the new setting.
3. Exit programming mode.
4. Remove AC and battery power from the panel.
5. Replace the defective bus device with a new one.
6. Apply AC and battery power to the panel.
