Chapter 3: Programming
Partition assign
Output programming
Status beeps
Default: On
Key beeps
Default: On
72
This menu lets you assign bus devices to work in the desired partition.
Note: SuperBus 2000 8Z input modules, SuperBus 2000 4-relay output
modules, and SuperBus 2000 RF receivers are not assigned to partitions.
To assign bus devices to partitions:
1. With the display showing the desired bus device, press #.
2. Press A or B until the display shows DEVICE PTN and then press #. The
display shows PARTITION ASSIGN n.
3. Press 1 to 6 to select the desired partition. The display flashes the entered
selection. Press # and the display shows the new setting.
Use these settings to program the output points of any installed SuperBus
2000 hardwire output module. The installer programs a HOM output point
into the Concord security panel by entering three kinds of information.
• Partition: The system partition (1 to 6).
•Trigger: The event that activates the output point. Trigger events can be
partition alarms, trouble conditions, open sensors, etc.
• Response: How the output responds to a trigger event.
Only the onboard and SnapCard outputs can be configured for user control.
To program each of the HOM output point configurations into the security
panel:
1. With the display showing the desired bus device, press #.
2. Press A or B until the display shows OUTPUTS.
3. Press #. The display shows OUTPUT 1.
4. Press A or B to select an output, then press #. The display shows
PARTITION ASSIGN 1.
5. Press 1 to 6 to select the desired partition assignment for this relay. The
display flashes the entered setting. Press # and the display shows the new
setting.
6. Press A or B. The display shows CONFIGURATION tttrr (current
setting). The point configuration number is tttrr, where ttt is the trigger
number and rr is the response number.
7. Enter the desired five-digit configuration number for this relay. The
display flashes the entered setting. Press # and the display shows the new
setting.
8. Press # and repeat the process until all outputs are programmed.
This setting determines whether the selected touchpad sounds status
beeps. Each touchpad can be set individually. This feature is usually turned
off for a touchpad that is located in or near bedrooms, to avoid disturbing
sleeping persons.
This setting determines whether or not selected touchpads beep when their
buttons are pressed. This feature is usually turned off for a touchpad that is
located in or near bedrooms, to avoid disturbing sleeping persons.
