The reader supports the following symbologies (bar code types). Options for
each symbology are included in this chapter.
• UPC-A on page 67
• UPC-E on page 70
• EAN 13 on page 73
• EAN 13 on page 73
• EAN 8 on page 76
• Add-Ons on page 93
• GS1 DataBarTM Omnidirectional on
page 100
• GS1 DataBarTM Expanded on page 102
• GS1 DataBarTM Limited on page 107
• Code 39 on page 109
• Code 32 (Italian Pharmaceutical) on
page 122
• Code 39 CIP (French Pharmaceutical)
on page 124
• Code 128 on page 124
• GS1-128 on page 134
• Interleaved 2 of 5 (I 2 of 5) on page
135
• Interleaved 2 of 5 CIP HR on page 143
Standard Factory Settings for Symbologies
Default settings are indicated at each feature/option with a green arrow. Also
reference
set of standard factory settings. That section also provides space to record any
custom settings needed or implemented for your system.
Programming Reference Guide

Symbologies

(JAN 13)
(JAN 8)
Appendix B, Standard Defaults
• Datalogic 2 of 5 on page 144
• Codabar on page 152
• ABC Codabar on page 165
• Code 11 on page 167
• Standard 2 of 5 on page 177
• Industrial 2 of 5 on page 183
• IATA on page 189
• ISBT 128 on page 190
• MSI on page 193
• Code 93 on page 199
• Codablock F on page 207
• Code 4 on page 211
• Code 5 on page 212
• Follett 2 of 5 on page 216
• BC412 on page 216
• Plessey on page 222
for a listing of the most widely used
