HP Engage Imaging II Programming Reference Manual

HP Engage Imaging II Programming Reference Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Program
reference guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Engage Imaging II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP Engage Imaging II

Summary of Contents for HP Engage Imaging II

  • Page 1 Program reference guide...
  • Page 2 © Copyright 2019 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
  • Page 3 Table of Contents INTRODUCTION ............................... 1 About this Manual ................................1 Overview ..................................1 Manual Conventions ..............................2 About the Scanner ................................Using the Reader ............................Programming the Reader ..............................Configuration Methods ............................SETUP..................................Unpacking ................................... Setting Up the Scanner ..............................Connect Host Interface .............................
  • Page 4 Baud Rate ..................................Data Bits ..................................Stop Bits ................................... Parity ....................................Handshaking Control ..............................RS-232/USB-COM INTERFACES Standard Factory Settings ............................. Intercharacter Delay ............................... Beep On ASCII BEL ................................Beep On Not on File ................................ ACK NAK Options ................................ACK Character ................................. NAK Character ................................
  • Page 5 Enable/Disable Good Read Indicator ......................... Good Read LED Duration ............................. Scanning Features ................................ Scan Mode ................................Flash On Time ..............................Flash Off Time ..............................Object Detection Indication ..........................Stand Mode/Object Detection Sensitivity ......................Stand Mode/Object Detection Illumination Off Time ..................Illumination Intensity and Frequency ......................
  • Page 6 Optional Add-On Timer ............................Optional GS1-128 Add-On timer ........................GS1 DataBar Omnidirectional ..........................GS1 DataBar Omnidirectional Enable/Disable ....................GS1 DataBar Omnidirectional GS1-128 Emulation ..................GS1 DataBar™ Omnidirectional 2D Component ....................GS1 DataBar™ Expanded .............................. GS1 DataBar Expanded Enable/Disable ......................GS1 DataBar Expanded GS1-128 Emulation ....................GS1 DataBar Expaded 2D Component ......................
  • Page 7 Datalogic 2 of 5 Enable/Disable ......................... Datalogic 2 of 5 Check Character Calculation ....................Datalogic 2 of 5 Check Character Transmission ....................Datalogic 2 of 5 Length Control .......................... Datalogic 2 of 5 Set Length 1 ..........................Datalogic 2 of 5 Set Length 2 ..........................Compressed 2 of 5 ................................
  • Page 8 MSI Check Character Transmission ........................MSI Length Control .............................. MSI Set Length 1 ..............................MSI Set Length 2 ..............................Plessey Enable/Disable ............................Plessey Check Character Calculation ......................... Plessey Check Character Transmission ......................Plessey Length Control ............................Plessey Set Length 1 ............................Plessey Set Length 2 ............................
  • Page 9 Micro QR Code ................................Micro QR Code Enable/Disable .......................... Micro QR Code Length Control ........................... UCC Composite ................................UCC Optional Composite Timer .......................... Postal Code Selection ..............................Postnet BB Control .............................. OCR DECODING OCR predefined template: EU ID Card OCR Format ..................OCR predefined template: IATA Passport ......................

  • Page 11: About The Scanner

    About the Scanner With rich feature sets and extensive model options, the represents the premium level of data collection equipment for general purpose applications. The reader has enhanced Megapixel optics with improved motion tolerance, allowing codes placed on fast-moving objects to be easily and quickly captured, creating the ideal reader for tasks requiring high throughput like those found in retail, light industrial environments and healthcare.
  • Page 12 Introduction Programming the Reader Configuration Methods Programming Bar Codes The reader is factory-configured with a standard set of default features. After scanning the interface bar code, you can select other options and customize your reader through use of the instructions and programming bar code labels available in the corresponding features section for your interface.

  • Page 13: Setting Up The Scanner

    Chapter 2 Setup Unpacking Check carefully to ensure the scanner and any cables or accessories ordered are present and undamaged. If any damage occurred during shipment, contact Technical Support. KEEP THE PACKAGING. Should the unit ever require service, it should be returned in its original shipping container.
  • Page 14 Setup Connect Host Interface The scanner kit you ordered to match your interface should provide a compati- ble cable for your installation. If this is not so, contact Technical Support. The scanner can communicate using the interfaces illustrated below. For corded versions, connect the reader cable by inserting the cable into the handle as shown in the following Figure.
  • Page 15 Setting Up the Scanner Figure 3. Connection to the Host WEDGE RS-232 Specific cables are required for connection to different hosts. The connec- tions illustrated in Figure 3 are examples only. Actual connectors may vary from those illustrated, but the steps to connect the scanner remain the same.
  • Page 16 Setup Stand Installation Hands-Free Stand/Holder An accessory is available which holds the reader (except those with integrated stand) at a convenient angle, allowing hands free scanning of items. It can also be used as a holder. The holder “cup” can be positioned in any of the angles shown in the figure below.
  • Page 17 Setup Using the normally functions by capturing and decoding codes. The aiming system is activated on trigger pull and indicates the center of the field of view which should be positioned over the bar code: Aiming System Relative Size and Location of Aiming System Pattern 2D Matrix Symbol Linear Bar...

  • Page 18: Power Off

    Using the A red beam illuminates the label. The field of view indicated by the aiming sys- tem will be smaller when the reader is closer to the bar code and larger when it is farther from the code. Symbologies with smaller bars or elements (mil size) should be read closer to the unit.

  • Page 19: Interface Selection

    Interface Selection Interface Selection Upon completing the physical connection between the scanner and its host, proceed directly to "Configuring the Interface" for information and programming for the interface type the scanner is connected to (for example: RS-232, Keyboard Wedge, USB, etc.) and scan the appropriate bar code in that section to select your system’s correct interface type.
  • Page 20 Setup Table 3. Available Interfaces RS-232 FEATURES $P,HA05,P RS-232 standard interface *Not supported on USB only models Select RS232-STD $P,HA12,P RS-232 Wincor-Nixdorf Select RS232-WN $P,HA13,P RS-232 for use with OPOS/UPOS/JavaPOS Select RS-232 OPOS $P,HA47,P USB COM to simulate RS-232 standard interface *USB COM driver need to be installed for this interface to work.
  • Page 21 Interface Selection USB-COMPOSITE FEATURES $P,HA45,P USB-Composite (combines USB-KBD emulation and USB-COM) *USB COM driver need to be installed for this interface to work. Select USB-Composite OTHER INTERFACES IBM46xx Port 9b Select IBM46xx Port 9b USB HID POS Select USB HID POS USB Toshiba TEC Select USB Toshiba TEC Select Datalogic Magellan Scanners'...
  • Page 22 Interface Selection KEYBOARD FEATURES $P,HA29,P AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding Select KBD-AT $P,HA11,P Keyboard Wedge for IBM AT PS2 with standard key encoding but without external keyboard Select KBD-AT-NK $P,HA26,P AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 &...

  • Page 23: Customizing Configuration Settings

    Setup Customizing Configuration Settings Using the Programming Bar Codes This manual contains feature descriptions and bar codes which allow you to reconfigure your scanner. Some programming bar code labels, like Resetting the Product Configuration to Defaults, require only the scan of that single label to enact the change.

  • Page 24: Interface Settings

    Customizing Configuration Settings Interface Settings The scanner is typically factory-configured with a set of default features standard "Interface Selection" to the interface type you ordered. See Global Interface Features provides settings configurable by all interface types. If your installation requires you to further customize your scanner, you can select other options through use of the instructions and programming bar codes available in the appropriate section for your interface.

  • Page 25: Chapter 3 Configuration Using Bar Codes

    Chapter 3 Configuration Using Bar Codes This and following sections provide programming bar codes to configure your scanner by changing the default settings. For details about additional methods of programming, see "Customizing Configuration Settings". You must first enable your scanner to read bar codes in order to use this section.
  • Page 26 Enter/Exit Programming Mode To program features: 1. Scan the ENTER/EXIT PROGRAMMING bar code, available at the top of each programming page, when applicable. 2. Scan the bar code to set the desired programming feature. You may need to cover unused bar codes on the page, and possibly the facing page, to ensure that the scanner reads only the bar code you intend to scan.

  • Page 27: Global Interface Features

    Enter/Exit Programming Mode Global Interface Features The following interface features are configurable by all interface types. To set features specific to your interface, turn to that section of this manual. — O OMMANDS GNORE USB S USPEND Host Commands — Obey/Ignore This option specifies whether the scanner will obey or ignore host commands.

  • Page 28: Standard Factory Settings

    RS-232 Interface Enter/Exit Programming Mode RS-232 Interface Use the programming bar codes in this chapter if modifications to the standard RS-232 interface settings are necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB interfaces are available RS-232/USB-COM Interfaces.
  • Page 29 Enter/Exit Programming Mode Baud Rate Baud Rate (continued) $CR2BA04 Baud Rate = 19,200 $CR2BA05 Baud Rate = 38,400 $CR2BA06 Baud Rate = 57,600 $CR2BA07 Baud Rate = 115,200...
  • Page 30 RS-232 Interface Enter/Exit Programming Mode Data Bits This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and receiving data. $CR2ST00 $CR2ST01 DEFAULT Handheld and Cradle models support the 8-bit ASCII protocol. The 7-bit ASCII protocol sup- port is subject to specific firmware release.
  • Page 31 Enter/Exit Programming Mode Parity Parity This feature specifies parity required for sending and receiving data. A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. • Select None when no parity bit is required. •...

  • Page 32: Handshaking Control

    RS-232 Interface Enter/Exit Programming Mode Handshaking Control The data interface consists of an RS-232 port designed to operate either with or without the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS). Handshaking Control includes the following options: •...
  • Page 33 Enter/Exit Programming Mode Handshaking Control $CR2HC04 Handshaking Control = RTS/CTS Scan Control $CR2HC04 Handshaking Control = RTS Off...

  • Page 34: Rs-232/Usb-Com Interfaces

    RS-232/USB-COM Interfaces The programming bar codes in this chapter allow modifications to the standard RS-232 and USB-Com interfaces. TANDARD ACTORY ETTINGS NTERCHARACTER ELAY ASCII BEL OT ON ACK NAK O PTIONS ACK C HARACTER NAK C HARACTER ACK NAK T IMEOUT ALUE ACK NAK R...

  • Page 35: Intercharacter Delay

    Enter/Exit Programming Mode Intercharacter Delay Intercharacter Delay This parameter specifies the intercharacter delay between the end of one char- acter and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay.

  • Page 36: Beep On Ascii Bel

    RS-232/USB-COM Interfaces Enter/Exit Programming Mode Beep On ASCII BEL When this parameter is enabled, the scanner issues a beep when a <BEL> char- acter is detected on the RS-232 serial line. <BEL> is issued to gain a user's attention to an illegal entry or other important event. $CR2BB00 DEFAULT Beep On ASCII BEL = Disable...

  • Page 37: Ack Nak Options

    Enter/Exit Programming Mode ACK NAK Options ACK NAK Options This enables/disables the ability of the scanner to support the RS-232 ACK/ NAK protocol. When configured, the scanner and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error. Options are: •...

  • Page 38: Ack Character

    RS-232/USB-COM Interfaces Enter/Exit Programming Mode ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See "ACK Character" for more detailed programming instructions. Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.

  • Page 39: Ack Nak Timeout Value

    Enter/Exit Programming Mode ACK NAK Options Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL ACK NAK Timeout Value This option specifies the amount of time the scanner waits for an ACK character from the host following label transmission.

  • Page 40: Ack Nak Retry Count

    RS-232/USB-COM Interfaces Enter/Exit Programming Mode ACK NAK Retry Count This feature specifies the number of times the scanner retries a label transmis- sion due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries.

  • Page 41: Ack Nak Error Handling

    Enter/Exit Programming Mode ACK NAK Options ACK NAK Error Handling This feature specifies the method the scanner uses to handle receive errors detected while waiting for an ACK character from the host. Options are: • Ignore errors detected • Process error as valid ACK character •...

  • Page 42: Indicate Transmission Failure

    RS-232/USB-COM Interfaces Enter/Exit Programming Mode Indicate Transmission Failure This option enables/disables the scanner’s ability to sound an error beep to indicate a transmission failure while in ACK/NAK mode. $CR2TF00 Indicate Transmission Failure = Disable Indication $CR2TF01 DEFAULT Indicate Transmission Failure = Enable Indication Disable Character Specifies the value of the RS-232 host command used to disable the scanner.

  • Page 43: Enable Character

    Enter/Exit Programming Mode Enable Character Enable Character Specifies the value of the RS-232 host command used to enable the scanner. ASCII characters or any hex value from 0 to 0xFF can be selected. See "Enable Character" or more detailed programming instructions. Setting to previously defined characters such as XON, XOFF, or host commands con- flicts with normal operation of these characters.

  • Page 44: Keyboard Interface

    Keyboard Interface Use the programming bar codes in this chapter to select options for USB Key- board and Wedge Interfaces. Reference Appendix B, for a listing of standard factory settings. Information about control character emulation which applies to keyboard interfaces is listed in Appendix E, Scancode Tables.

  • Page 45: Country Mode

    Enter/Exit Programming Mode Country Mode Country Mode This feature specifies the country/language supported by the keyboard. The Country Mode setting is ignored if the interface uses alternate key encod- ing. Setup on PC to use ALT Universal 1. Open Registry Edit 2.

  • Page 46: Setting Country Mode

    Keyboard Interface Enter/Exit Programming Mode Setting Country Mode $CKBCO00 DEFAULT United States $CKBCO01 French International (Belgian French) $CKBCO02 United Kingdom $CKBCO11 Danish $CKBCO0E French (France) $CKBCO03 German $CKBCO04 Italian Product Reference Guide...
  • Page 47 Enter/Exit Programming Mode Country Mode Setting Country Mode (continued) $CKBCO0F Norwegian $CKBCO09 Portuguese Portugal $CKBCO0A Spanish $CKBCO0B Swedish $CKBCO13 Swiss French $CKBCO14 Japanese ASCII $CKBCO13 Hungarian...
  • Page 48 Keyboard Interface Enter/Exit Programming Mode Setting Country Mode (continued) $CKBCO0F Czech $CKBCO09 SlovaK $CKBCO0A Romanian $CKBCO0B Croatian $CKBCO13 Polish_214 $CKBCO14 Canadian French Win7 $CKBCO13 Lithuanian Product Reference Guide...
  • Page 49 Enter/Exit Programming Mode Country Mode Setting Country Mode (continued) $CKBCO0F Vietnamese $CKBCO09 Russian $CKBCO0A Arabic 101 $CKBCO0B Chinese ASCII $CKBCO13 Thai-Kedmanee $CKBCO14 Albanian $CKBCO13 Arabic 102...
  • Page 50 Keyboard Interface Enter/Exit Programming Mode Setting Country Mode (continued) $CKBCO0F Arabic 102 AZERTY $CKBCO09 Azeri Cyrillic $CKBCO0A Azeri Latin $CKBCO0B Belarusian $CKBCO13 Bosnian Cyrillic $CKBCO14 Bosnian Latin $CKBCO13 Bulgarian Cyrillic Product Reference Guide...
  • Page 51 Enter/Exit Programming Mode Country Mode Setting Country Mode (continued) $CKBCO0F Bulgarian Latin $CKBCO09 Canadian French (Legacy) $CKBCO0A $CKBCO0B Chinese (Simplified) $CKBCO13 Chinese (Traditional) $CKBCO14 Czech Programmers $CKBCO13 Czech QWERTY...
  • Page 52 Keyboard Interface Enter/Exit Programming Mode Setting Country Mode (continued) $CKBCO0F Dutch Netherland $CKBCO09 Estonian $CKBCO0A Faeroese $CKBCO0B Finnish $CKBCO13 French (Canada) 2000/XP $CKBCO14 French (Canada) 95/98 $CKBCO13 Galician Product Reference Guide...
  • Page 53 Enter/Exit Programming Mode Country Mode Setting Country Mode (continued) $CKBCO0F Greek $CKBCO09 Greek Latin $CKBCO0A Greek Polytonic $CKBCO0B Greek220 $CKBCO13 Greek220 Latin $CKBCO14 Greek319 $CKBCO13 Greek319 Latin...
  • Page 54 Keyboard Interface Enter/Exit Programming Mode Setting Country Mode (continued) $CKBCO0F Hebrew Israel $CKBCO09 Hungarian_101KEY $CKBCO0A Icelandic $CKBCO0B Irish $CKBCO13 Italian_142 $CKBCO14 Japanese (Shift-JIS) $CKBCO13 Kazakh Product Reference Guide...
  • Page 55 Enter/Exit Programming Mode Country Mode Setting Country Mode (continued) $CKBCO0F Korean (Hangul) $CKBCO09 Korean ASCII $CKBCO0A Kyrgyz Cyrillic $CKBCO0B Latin America $CKBCO13 Latvian $CKBCO14 Latvian QWERTY $CKBCO13 Lithuanian_IBM...
  • Page 56 Keyboard Interface Enter/Exit Programming Mode Setting Country Mode (continued) $CKBCO0F Macedonian -FYROM $CKBCO09 Maltese_47KEY $CKBCO0A Mongolian-Cyrillic $CKBCO0B $CKBCO13 $CKBCO14 $CKBCO13 Portuguese Brazilian ABNT2 Product Reference Guide...
  • Page 57 Enter/Exit Programming Mode Country Mode Setting Country Mode (continued) $CKBCO0F Romanian Legacy $CKBCO09 Romanian Programmer $CKBCO0A Romanian Standard $CKBCO0B Russian Typewriter $CKBCO13 Serbian Cyrillic $CKBCO14 Serbian Latin $CKBCO13 Slovak QWERTY...
  • Page 58 Keyboard Interface Enter/Exit Programming Mode Setting Country Mode (continued) $CKBCO0F Slovenian $CKBCO09 Spanish Variation $CKBCO0A Swiss German $CKBCO0B Tatar $CKBCO13 Turkish F $CKBCO14 Turkish Q $CKBCO13 Ukrainian Product Reference Guide...
  • Page 59 Enter/Exit Programming Mode Country Mode Setting Country Mode (continued) $CKBCO0F US Dvorak $CKBCO09 US Dvorak Left Hand $CKBCO0A US Dvorak Right Hand $CKBCO0B US English (Mac) $CKBCO13 US English (North American) US International Uzbek Cyrillic...

  • Page 60: Setting Encoding Type

    Keyboard Interface Enter/Exit Programming Mode Setting Encoding Type $CKBCO00 DEFAULT Don’t use encoding $CKBCO01 UTF_8 $CKBCO02 Windows 874 $CKBCO11 Windows 932 $CKBCO0E Windows 936 $CKBCO03 Windows 949 $CKBCO04 Windows 950 Product Reference Guide...
  • Page 61 Enter/Exit Programming Mode Country Mode Setting Encoding Type (continued) $CKBCO03 Windows 1250 $CKBCO09 Windows 1251 $CKBCO0A Windows 1252 $CKBCO0B Windows 1253 $CKBCO13 Windows 1254 $CKBCO14 Windows 1255 $CKBCO13 Windows 1256...
  • Page 62 Keyboard Interface Enter/Exit Programming Mode Setting Encoding Type (continued) $CKBCO0F Windows 1257 $CKBCO09 Windows 1258 $CKBCO0A Windows 20866 $CKBCO09 0x31 = Windows 54936 $CKBCO0B ISO 8859-1 $CKBCO13 ISO 8859-2 Product Reference Guide...
  • Page 63 Enter/Exit Programming Mode Country Mode Setting Encoding Type (continued) $CKBCO14 ISO 8859-3 $CKBCO13 ISO 8859-4 $CKBCO0F $CKBCO09 $CKBCO0A ISO 8859-7 $CKBCO0B ISO 8859-8 $CKBCO13 ISO 8859-9...
  • Page 64 Keyboard Interface Enter/Exit Programming Mode Setting Encoding Type (continued) $CKBCO14 ISO 8859-10 $CKBCO13 ISO 8859-11 $CKBCO0F ISO 8859-13 $CKBCO09 ISO 8859-14 $CKBCO0A ISO 8859-15 $CKBCO0B ISO 8859-16 $CKBCO13 MS-DOS 437 Product Reference Guide...
  • Page 65 Enter/Exit Programming Mode Country Mode Setting Encoding Type (continued) $CKBCO14 MS-DOS 737 $CKBCO13 MS-DOS 775 $CKBCO0F MS-DOS 850 $CKBCO09 MS-DOS 852 $CKBCO0A MS-DOS 855 $CKBCO0B MS-DOS 857 $CKBCO13 MS-DOS 860...
  • Page 66 Keyboard Interface Enter/Exit Programming Mode Setting Encoding Type (continued) $CKBCO14 MS-DOS 861 $CKBCO13 MS-DOS 862 $CKBCO0F MS-DOS 863 $CKBCO09 MS-DOS 865 $CKBCO0A MS-DOS 866 $CKBCO0B MS-DOS 869 $CKBCO13 Mac CP10000 Product Reference Guide...

  • Page 67: Setting Alt Output Type

    Enter/Exit Programming Mode Country Mode Setting ALT output type This option specifies the encode type of ALT Mode when the scanner sends Output Keyboard Data in Alt Mode. (Be aware that the scanner may switch auto- matically between ALT mode & Normal Keyboard Scancode, to correctly display some characters that are not present in the current Keyboard Country).

  • Page 68: Caps Lock State

    Keyboard Interface Enter/Exit Programming Mode Caps Lock State This option specifies the format in which the scanner sends character data. This applies to Keyboard Wedge interfaces. This does not apply when an alternate key encoding keyboard is selected. This does not apply to USB Keyboard. $CKBCL00 DEFAULT Caps Lock State = Caps Lock OFF...

  • Page 69: Keyboard Numeric Keypad

    Enter/Exit Programming Mode Keyboard Numeric Keypad Keyboard Numeric Keypad This feature specifies if numeric characters will be sent using the standard keys or the numeric keypad. $CKBKP00 DEFAULT Keyboard Numeric Keypad = Standard Keys $CKBKP01 Keyboard Numeric Keypad = Numeric Keypad...

  • Page 70: Keyboard Send Control Characters

    Keyboard Interface Enter/Exit Programming Mode Keyboard Send Control Characters This feature is used by the Keyboard Wedge and USB Keyboard interfaces. It specifies how the scanner transmits ASCII control characters to the host. Refer- ence Appendix E, Scancode Tables for more information about control charac- ters.

  • Page 71: Wedge Quiet Interval

    Enter/Exit Programming Mode Wedge Quiet Interval Wedge Quiet Interval This option specifies the amount of time to look for keyboard activity before the scanner breaks the keyboard connection in order to transmit data to host. The selectable range for this feature is from 0 to 990ms in 10ms increments. "Wedge Quiet Interval"...
  • Page 72 Keyboard Interface Enter/Exit Programming Mode Intercharacter Delay This parameter specifies the intercharacter delay between the end of one char- acter and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay.

  • Page 73: Intercode Delay

    Enter/Exit Programming Mode Intercode Delay Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is from 0 to 99 seconds. See "Intercode Delay" for more detailed programming instructions. $CKBID To configure this feature, scan the ENTER/EXIT bar code above, then the bar code at left followed by digits from the Appendix D, Keypad...

  • Page 74: Usb Keyboard Speed

    Keyboard Interface Enter/Exit Programming Mode USB Keyboard Speed This option specifies the USB poll rate for a USB Keyboard. This feature applies ONLY to the USB Keyboard interface. NOTE $CKBSP01 DEFAULT USB Keyboard Speed = 1ms $CKBSP02 USB Keyboard Speed = 2ms $CKBSP03 USB Keyboard Speed = 3ms $CKBSP05...

  • Page 75: Ibm 46Xx Interface

    Enter/Exit Programming Mode IBM 46XX Interface Use the bar codes in this section to configure programmable features for avail- able IBM 46XX interfaces. Reference Appendix B, for a listing of standard factory settings.. Interface Options This feature provides for an interface-specific control mechanism. Obey Scanner Configuration Host Commands DEFAULT Ignore Scanner Configuration Host Commands...

  • Page 76: Data Format

    Data Format LOBAL REFIX UFFIX AIM ID LOBAL GS1-128 AIM ID ABEL Label ID: Pre-loaded Sets Label ID: Set Individually Per Symbology Label ID Control Label ID Symbology Selection ONVERSION HARACTER ONVERSION The features in this chapter can be used to build specific user-defined data into a message string.

  • Page 77: Global Prefix/Suffix

    Enter/Exit Programming Mode Global Prefix/Suffix Global Prefix/Suffix Up to 20 ASCII characters may be added as a prefix (in a position before the bar code data) and/or as a suffix (in a position following the bar code data). See "Global Prefix/Suffix" for more detailed programming instructions.

  • Page 78: Global Aim Id

    Data Format Enter/Exit Programming Mode Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. NOTE AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. See "Global AIM ID"...

  • Page 79: Label Id: Pre-Loaded Sets

    Enter/Exit Programming Mode Label ID Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.

  • Page 80: Label Id: Set Individually Per Symbology

    Data Format Enter/Exit Programming Mode Label ID: Set Individually Per Symbology This feature configures a Label ID individually for a single symbology. This setting requires the scanning of bar codes from multiple sections. See "Label ID:Set Individually Per Symbology" for more detailed programming instructions. NOTE Label ID Control This option controls whether a Label ID is disabled, or sent as a prefix or suffix...

  • Page 81: Label Id Symbology Selection

    Enter/Exit Programming Mode Label ID Label ID Symbology Selection This option selects the symbology for which a Label ID is to be configured. See "Label ID: Set Individually Per Symbology" for full instructions. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string.
  • Page 82 Data Format Enter/Exit Programming Mode Label ID Symbology Selection (continued) $C3BID Set EAN 13 Label ID Character(s) $C32ID Set EAN 13/P2 Label ID Character(s) $C35ID Set EAN 13/P5 Label ID Character(s) $C8BID Set EAN 8 Label ID Character(s) $C82ID Set EAN 8/P2 Label ID Character(s) $C85ID Set EAN 8/P5 Label ID Character(s) Product Reference Guide...
  • Page 83 Enter/Exit Programming Mode Label ID Label ID Symbology Selection (continued) $C4BID Set GS1 DataBar Omnidirectional Label ID Character(s) $CXBID Set GS1 DataBar Expanded Label ID Character(s) $CLBID Set GS1 DataBar Limited Label ID Character(s) $CC3ID Set Code 39 Label ID Character(s) $CP3ID Set Code 32 Label ID Character(s) $CCCID...
  • Page 84 Data Format Enter/Exit Programming Mode Label ID Symbology Selection (continued) $CC8ID Set Code 128 Label ID Character(s) $CU8ID Set GS1-128 Label ID Character(s) $CI2ID Set Interleaved 2 of 5 Label ID Character(s) $CHRID Set Interleaved 2 of 5 CIP HR Label ID Character(s) $CD2ID Set Datalogic 2 of 5 CIP HR Label ID Character(s) $CCBID...
  • Page 85 Enter/Exit Programming Mode Label ID Label ID Symbology Selection (continued) Set Code 11 Label ID Character(s) $CS2ID Set Standard 2 of 5 Label ID Character(s) $CU2ID Set Industrial 2 of 5 Label ID Character(s) $CINID Set ISSN Label ID Character(s) $CIAID Set IATA Label ID Character(s) $CI8ID...

  • Page 86: Case Conversion

    Data Format Enter/Exit Programming Mode Label ID Symbology Selection (continued) $CC9ID Set Plessey Label ID Character(s) Set Concatenated ISBT Label ID Character(s) $CC9ID Set Anker Plessey Label ID Characters Case Conversion This feature allows conversion of the case of all alphabetic characters to upper or lower case.

  • Page 87: Character Conversion

    Enter/Exit Programming Mode Character Conversion Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to.

  • Page 88: Reading Parameters

    Reading Parameters PEAKER OLUME IBRATION OUBLE IMEOUT EADING ERFORMANCE ENGTH LED D PEAKER NDICATORS URATION HEN TO NDICATE CANNING EATURES ORDED EATURES REQUENCY ULTIPLE ABEL EADING Product Reference Guide...

  • Page 89: Double Read Timeout

    Enter/Exit Programming Mode Double Read Timeout Double Read Timeout To prevent a double read of the same label, the Double Read Timeout sets the minimum time allowed between reads of labels of the same symbology and data. If the unit reads a label and sees the same label again within the Double Read Timeout, the second read of the label will be ignored.
  • Page 90 Reading Parameters Enter/Exit Programming Mode Double Read Timeout (continued) $CSNDR32 Double Read Timeout = 0.5 Second $CSNDR3C DEFAULT Double Read Timeout = 0.6 Second $CSNDR46 Double Read Timeout = 0.7 Second $CSNDR50 Double Read Timeout = 0.8 Second $CSNDR5A Double Read Timeout = 0.9 Second $CSNDR64 Double Read Timeout = 1 Second Product Reference Guide...

  • Page 91: Reading Performance

    Enter/Exit Programming Mode Reading Performance Reading Performance When the barcode scanner's Scan Mode is set to triggerless modes (e.g. Flash- ing, Always On, Stand Mode/Object Detection, etc.) the reading capabilities can be modified according to two main goals: • Motion tolerance: increased performance for rapidly moving barcodes. •...

  • Page 92: Power On Alert

    Reading Parameters Enter/Exit Programming Mode LED and Speaker Indicators Power On Alert Disables or enables the indication (from the Speaker) that the scanner is receiv- ing power. $CBPPU00 Power On Alert = Disable (No Audible Indication) $CBPPU01 DEFAULT Power On Alert = Power-up Beep Product Reference Guide...

  • Page 93: Good Read: When To Indicate

    Enter/Exit Programming Mode LED and Speaker Indicators Good Read: When to Indicate This feature specifies when the scanner will provide indication (beep and/or LED) upon successfully reading a bar code. Choices are: • Good Read = Indicate after decode • Good Read = Indicate after transmit •...

  • Page 94: Good Read Beep Type

    Reading Parameters Enter/Exit Programming Mode Good Read Beep Type Specifies whether the good read beep has a mono or bitonal beep sound. $CBPTY00 DEFAULT Good Read Beep Type = Mono $CBPTY01 Good Read Beep Type = Bitonal Good Read Beep Frequency Adjusts the good read beep to sound at a selectable low, medium or high fre- quency, selectable from the list below.
  • Page 95 Enter/Exit Programming Mode LED and Speaker Indicators Good Read Speaker Volume / Vibration Selects the speaker volume (loudness) upon a good read beep. There are three selectable volume levels. In addition to three selectable volume levels, the user can also activate a vibra- tion feedback for good read.

  • Page 96: Silent Mode

    Reading Parameters Enter/Exit Programming Mode Silent Mode If needed, audible indications can be disabled by scanning the labels below. Please note that some important audible notifications are not muted in silent mode and other notifications are replaced by vibration or visual indications. All changes in audible notifications are summarized here: •...

  • Page 97: Good Read Beep Length

    Enter/Exit Programming Mode LED and Speaker Indicators Good Read Beep Length Specifies the duration of a good read beep. $CBPLE06 Good Read Beep Length = 60 msec $CBPLE08 DEFAULT Good Read Beep Length = 80 msec $CBPLE0A Good Read Beep Length = 100 msec $CBPLE0C Good Read Beep Length = 120 msec $CBPLE0E...

  • Page 98: Enable/Disable Good Read Indicator

    Reading Parameters Enter/Exit Programming Mode Good Read Beep Length (continued) $CBPLE12 Good Read Beep Length = 180 msec $CBPLE14 Good Read Beep Length = 200 msec Enable/Disable Good Read Indicator Enable/Disable the good read indicator. $CRGBE00 Good Read Indicator = Disable $CRGBE01 DEFAULT Good Read Indicator = Enable...

  • Page 99: Good Read Led Duration

    Enter/Exit Programming Mode LED and Speaker Indicators Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 100 milliseconds to 25,500 milliseconds (0.1 to 25.5 seconds) in 100ms incre- ments.

  • Page 100: Scanning Features

    Reading Parameters Enter/Exit Programming Mode Scanning Features Scan Mode "Scan Mode" for more detailed programming instructions. $CSNRM00 DEFAULT Scan Mode = Trigger Single $CSNRM01 Scan Mode = Trigger Hold Multiple $CSNRM02 Scan Mode = Trigger Pulse Multiple $CSNRM03 Scan Mode = Flashing $CSNRM04 Scan Mode = Always On $CSNRM05...

  • Page 101: Flash On Time

    Enter/Exit Programming Mode Scanning Features Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. See "Flash On Time" for more detailed pro-gramming instructions.

  • Page 102: Flash Off Time

    Reading Parameters Enter/Exit Programming Mode Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. See "Flash Off Time" for more detailed pro-gramming instructions.
  • Page 103 Enter/Exit Programming Mode Scanning Features Object Detection Indication Enables/disables the LED flash when the reader is in Object Detection. $CSMFL00 DEFAULT Object Detection Flash = Disable $CSMFL01 Object Detection Flash = Enable...

  • Page 104: Stand Operation

    Reading Parameters Enter/Exit Programming Mode Stand Operation Specifies the behavior of the reader when stationary in a stand. There are two conditions which cause the reader to switch to Stand Mode/Object Detection: 1. The reader is configured to switch to Stand Mode/Object Detection when stationary.
  • Page 105 Enter/Exit Programming Mode Scanning Features Stand Mode/Object Detection Sensitivity Sets the sensitivity level for stand mode/object detection wakeup. Choices are low, medium and high. $CSMSE00 Stand Mode/Object Detection Sensitivity = Low $CSMSE01 DEFAULT Stand Mode/Object Detection Sensitivity = Medium $CSMSE02 Stand Mode/Object Detection Sensitivity = High...
  • Page 106 Reading Parameters Enter/Exit Programming Mode Stand Mode/Object Detection Illumination Off Time Specifies the amount of time reader illumination stays off after pulling the trig- ger when in Stand Mode/Object Detection. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 seconds). To configure this feature, scan the ENTER/EXIT PRO- GRAMMING MODE bar code above, then the bar code at left followed by the digits from the Alphanumeric...

  • Page 107: Scanning Active Time

    Enter/Exit Programming Mode Scanning Features Illuminator Refresh Frequency Illuminator refresh frequency can be increased if needed. In some conditions this can contribute to eye relaxation. DEFAULT Normal Refresh Frequency Increased Refresh Frequency Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered.

  • Page 108: Motion Still Timeout

    Reading Parameters Enter/Exit Programming Mode Motion Still Timeout Motion Still Timeout specifies the waiting time after which no motions is detected. When no motion is detected for period of time longer than the set Motion Still Timeout period, the scanner assumes it is in a motionless condi- tion.

  • Page 109: Pick Mode

    Enter/Exit Programming Mode Scanning Features Pick Mode Specifies the ability of the reader to decode labels only when they are close to the center of the aiming pattern. This allows the reader to accurately target labels when they are placed close together, such as on a pick sheet. The Pick Mode can be enabled only in Trigger Single Scan Mode.

  • Page 110: Aiming Duration Timer

    Reading Parameters Enter/Exit Programming Mode Use Green Spot as Aiming Pointer Aiming Duration Timer Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode.The range for this setting is from 1 to 255 seconds in 1-second increments.

  • Page 111: Green Spot Duration

    Enter/Exit Programming Mode Scanning Features Green Spot Duration Specifies the duration of the good read pointer beam after a good read. Green Spot Duration = Disable (Green Spot is Off) DEFAULT Green Spot Duration = Short (300 msec) Green Spot Duration = Medium (500 msec) Green Spot Duration = Long (800 msec)

  • Page 112: Mobile Phone Mode

    Reading Parameters Enter/Exit Programming Mode Mobile Phone Mode This mode is useful for scanning bar codes displayed on a mobile phone. Other options for this feature can be configured using the Mobile Phone Mode = Disable DEFAULT Mobile Phone Mode = Enable Mobile Phone Mode = Enhanced Product Reference Guide...
  • Page 113 Enter/Exit Programming Mode Scanning Features Mobile Phone Saturation Rate This specifies the minimum number of saturated pixels (every 1000 pixels) in the image in order to activate the Mobile Phone mode. DEFAULT Mobile Phone Saturation Rate = 00 Mobile Phone Saturation Rate = 01 Mobile Phone Saturation Rate = 02...

  • Page 114: Decode Negative Image

    Reading Parameters Enter/Exit Programming Mode Decode Negative Image Enable/Disable the ability to decode a negative image for all symbologies. When this feature is enabled, you will be unable to read normally-printed labels or programming labels in this manual. Scan the “Disable” bar code below to return the scanner to its default for this feature.

  • Page 115: Corded Only Features

    Enter/Exit Programming Mode Scanning Features CORDED ONLY FEATURES Corded Stand Mode Sets the Stand Mode Operation for Corded models This feature is available starting with firmware release 610001013. NOTE DEFAULT Corded Stand Mode = Disable Corded Stand Mode = Generic Stand Corded Stand Mode = for All-in-one and Base Corded Stand Mode = Precise Stand...
  • Page 116 Reading Parameters Enter/Exit Programming Mode Dock Detection Beep If enabled, when the Handheld reader is placed in a dock (cradle or corded stand), it will beep. Dock Detection Beep = Disable Dock Detection Beep = Enable Corded Stand Beep Enables/Disables the beep that indicates when Corded Stand position is detected.

  • Page 117: Multiple Label Reading

    Enter/Exit Programming Mode Scanning Features MULTIPLE LABEL READING In standard (default) mode, when the reader’s aiming system is activated (by a trigger pull, motion or other method depending on the mode), it then acquires and processes each image in the area in front of it (the Volume). In this case, the scanner stops processing the image once it decodes a label.

  • Page 118: Multiple Labels Ordering By Code Symbology

    Reading Parameters Enter/Exit Programming Mode Multiple Labels Ordering by Code Symbology This feature allows you to specify the order multiple labels are transmitted by symbology type, when Multiple Labels per Frame is enabled. To configure this feature, scan the ENTER/EXIT PRO- GRAMMING MODE bar code above, then the bar code at left followed by the digits From the alphanumeric characters In Appendix d, keypad representing your...
  • Page 119 Reading Parameters NOTES...

  • Page 120: Standard Factory Settings For Symbologies

    1D Symbologies Introduction The scanner supports the following 1D symbologies (bar code types). Symbol- ogy-dependent options for each symbology are included in this chapter. See "2D Symbologies" for configuration of 2D bar codes. UPC-A 5 (I 2 NTERLEAVED UPC-E 5 CIP HR NTERLEAVED EAN 13 ATALOGIC...

  • Page 121: Disable All Symbologies

    Enter/Exit Programming Mode Disable All Symbologies Disable All Symbologies Scan this label to disable all symbologies. Disable all symbologies Coupon Control This feature is used to control the method of processing coupon labels. Options are: • Allow all — allow all coupon bar codes to be decoded •...

  • Page 122: Upc-A Enable/Disable

    1D Symbologies Enter/Exit Programming Mode UPC-A The following options apply to the UPC-A symbology. UPC-A Enable/Disable When disabled, the scanner will not read UPC-A bar codes. $CABEN00 UPC-A = Disable $CABEN01 DEFAULT UPC-A = Enable UPC-A Check Character Transmission Enable this option to transmit the check character along with UPC-A bar code data.

  • Page 123: Upc-A Number System Character Transmission

    Enter/Exit Programming Mode UPC-A Expand UPC-A to EAN-13 Expands UPC-A data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CAB3B00 DEFAULT UPC-A to EAN-13 = Don’t Expand $CAB3B01 UPC-A to EAN-13 = Expand UPC-A Number System Character Transmission This feature enables/disables transmission of the UPC-A number system char- acter.

  • Page 124: Upc-A 2D Component

    1D Symbologies Enter/Exit Programming Mode UPC-A 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. DEFAULT UPC-A 2D Component = Disable (2D component not required) UPC-A 2D Component = Enabled (2D component must be decoded) Product Reference Guide...

  • Page 125: Upc-E Enable/Disable

    Enter/Exit Programming Mode UPC-E UPC-E The following options apply to the UPC-E symbology. UPC-E Enable/Disable When disabled, the scanner will not read UPC-E bar codes. $CEBEN00 UPC-E = Disable $CEBEN01 DEFAULT UPC-E = Enable UPC-E Check Character Transmission Enable this option to transmit the check character along with UPC-E bar code data.

  • Page 126: Upc-E 2D Component

    1D Symbologies Enter/Exit Programming Mode UPC-E 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded. $CEBCT00 DEFAULT UPC-E 2D Component = Disable (2D component not required) $CEBCT01 UPC-E 2D Component = 2D component must be decoded...

  • Page 127: Upc-E Number System Character Transmission

    Enter/Exit Programming Mode UPC-E Expand UPC-E to EAN-13 Expands UPC-E data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. DEFAULT UPC-E to EAN-13 = Don’t Expand UPC-E to EAN-13 = Expand Expand UPC-E to UPC-A Expands UPC-E data to the UPC-A data format.

  • Page 128: Gtin Formatting

    1D Symbologies Enter/Exit Programming Mode GTIN Formatting This feature enables/disables the ability to convert UPC-E, UPC-A, EAN 8, and EAN 13 labels into the GTIN 14-character format. If add-on information is present on the base label prior to the conversion taking place, the add-on information will be appended to the converted GTIN label.

  • Page 129: Ean 13 Enable/Disable

    Enter/Exit Programming Mode EAN 13 EAN 13 The following options apply to the EAN 13 (Jan 13) symbology. EAN 13 Enable/Disable When disabled, the scanner will not read EAN 13/JAN 13 bar codes. $C3BEN00 EAN 13 = Disable $C3BEN01 DEFAULT EAN 13 = Enable EAN 13 Check Character Transmission Enable this option to transmit the check character along with EAN 13 bar code...

  • Page 130: Flag 1 Character

    1D Symbologies Enter/Exit Programming Mode EAN-13 Flag 1 Character Enables/disables transmission of an EAN/JAN13 Flag1 character. The Flag 1 character is the first character of the label. $C3BF100 EAN-13 Flag 1 Char= Don’t transmit $C3BF101 DEFAULT EAN-13 Flag 1 Char= Transmit EAN-13 ISBN Conversion This option enables/disables conversion of EAN 13/JAN 13 Bookland labels starting with 978 to ISBN labels.

  • Page 131: Issn Enable/Disable

    Enter/Exit Programming Mode EAN 13 EAN-13 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. DEFAULT EAN-13 2D Component = Disable (2D component not required) EAN-13 2D Component = 2D component must be decoded ISSN Enable/Disable Enables/disables conversion of EAN/JAN13 Bookland labels starting with 977 to...

  • Page 132: Ean 8 Enable/Disable

    1D Symbologies Enter/Exit Programming Mode EAN 8 The following options apply to the EAN 8 (Jan 8) symbology. EAN 8 Enable/Disable When disabled, the scanner will not read EAN 8/JAN 8 bar codes. $C8BEN00 EAN 8 = Disable $C8BEN01 DEFAULT EAN 8 = Enable EAN 8 Check Character Transmission Enable this option to transmit the check character along with EAN 8 bar code...

  • Page 133: Ean 8 2D Component

    Enter/Exit Programming Mode EAN 8 Expand EAN 8 to EAN 13 Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13. $C8B3B00 DEFAULT Expand EAN 8 to EAN 13 = Disable $C8B3B01 Expand EAN 8 to EAN 13 = Enable EAN 8 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded.

  • Page 134: Upc/Ean Global Settings

    1D Symbologies Enter/Exit Programming Mode UPC/EAN Global Settings This section provides configuration settings for UPC-A, UPC-E, EAN 13 and EAN 8 symbologies, and affects all of these unless otherwise marked for each fea- ture description. UPC/EAN Price Weight Check This feature enables/disables calculation and verification of price/weight check digits.

  • Page 135: Upc/Ean Quiet Zones

    Enter/Exit Programming Mode Add-Ons UPC/EAN Quiet Zones This feature specifies the number of quiet zones for UPC/EAN labels. Quiet zones are blank areas at the ends of a bar code, typically 10 times the width of the narrowest bar or space in the label. The property applies to all EAN-UPC symbologies globally and to the ADD-ONs.

  • Page 136: Optional Add-Ons

    1D Symbologies Enter/Exit Programming Mode Optional Add-ons The scanner can be enabled to optionally read the following add-ons (supple- mentals): • • If a UPC/EAN base label and a an add-on are both decoded, the scanner will transmit the base label and add-on. If a UPC/EAN base label is decoded without an add-on, the base label will be transmitted without an add-on.

  • Page 137: Optional Add-On Timer

    Enter/Exit Programming Mode Add-Ons Optional Add-On Timer This option sets the time the scanner will look for an add-on when an add-on fragment has been seen and optional add-ons are enabled. Optional Add-on Timer = 10ms $CADOT02 Optional Add-on Timer = 20ms $CADOT03 Optional Add-on Timer = 30ms $CADOT05...

  • Page 138: Optional Gs1-128 Add-On Timer

    1D Symbologies Enter/Exit Programming Mode Optional GS1-128 Add-On timer This option sets the timer expiration value to read the added part after reading the linear EAN/UPC part. For UPC/EAN add-ons other than those of that type, "Optional Add-On Timer". $CADO200 DEFAULT Optional GS1-128 Add-On Timer = Disable $CADO201...
  • Page 139 Enter/Exit Programming Mode Add-Ons $CADO501 Optional GS1-128 Add-On Timer = 70 ms $CADO501 Optional GS1-128 Add-On Timer = 100 ms $CADO501 Optional GS1-128 Add-On Timer = 120 ms $CADO501 Optional GS1-128 Add-On Timer = 140 ms $CADO501 Optional GS1-128 Add-On Timer = 160 ms $CADO501 Optional GS1-128 Add-On Timer = 180 ms $CADO501...

  • Page 140: Gs1 Databar Omnidirectional Enable/Disable

    1D Symbologies Enter/Exit Programming Mode $CADO501 Optional GS1-128 Add-On Timer = 240 ms $CADO501 Optional GS1-128 Add-On Timer = 260 ms $CADO501 Optional GS1-128 Add-On Timer = 280 ms $CADO501 Optional GS1-128 Add-On Timer = 300 ms ™ GS1 DataBar Omnidirectional The following options apply to the GS1 DataBar Omnidirectional (formerly RSS- 14) symbology.

  • Page 141: Gs1 Databar Omnidirectional Gs1-128 Emulation

    Enter/Exit Programming Mode GS1 DataBar Omnidirectional GS1 DataBar Omnidirectional GS1-128 Emulation When enabled, GS1 DataBar Omnidirectional bar codes will be translated to the GS1-128 label data format. $C4BU800 DEFAULT GS1 DataBar Omnidirectional GS1-128 Emulation = Disable $C4BU801 GS1 DataBar Omnidirectional GS1-128 Emulation = Enable GS1 DataBar™...

  • Page 142: Gs1 Databar Expanded Enable/Disable

    1D Symbologies Enter/Exit Programming Mode GS1 DataBar™ Expanded The following options apply to the GS1 DataBar Expanded (formerly RSS Expanded) symbology. GS1 DataBar Expanded Enable/Disable When disabled, the scanner will not read GS1 DataBar Expanded bar codes. $CXBEN00 DEFAULT GS1 DataBar Expanded = Disable $CXBEN01 GS1 DataBar Expanded = Enable GS1 DataBar Expanded GS1-128 Emulation...
  • Page 143 Enter/Exit Programming Mode GS1 DataBar™ Expanded GS1 DataBar Expaded 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. $CXBU800 DEFAULT GS1 DataBar Expanded 2D Component = Disable $CXBU801 GS1 DataBar Expanded 2D Component = Enable...

  • Page 144: Gs1 Databar Expanded Length Control

    1D Symbologies Enter/Exit Programming Mode GS1 DataBar Expanded Length Control This feature specifies either variable length decoding or fixed length decoding for the GS1 DataBar Expanded symbology. For variable-length decoding, a minimum length may be set. Variable Length: For fixed-length decoding, two different lengths may be set. Fixed Length: $CXBLC00 DEFAULT...
  • Page 145 Enter/Exit Programming Mode GS1 DataBar™ Expanded GS1 DataBar Expanded Set Length 2 This feature specifies one of the bar code lengths for GS1 DataBar Expanded Length Control. Length 2 is the maximum label length if in Vari-able Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 146: Gs1 Databar Limited Enable/Disable

    1D Symbologies Enter/Exit Programming Mode GS1 DataBar™ Limited The following options apply to the GS1 DataBar Limited (formerly RSS Limited) symbology. GS1 DataBar Limited Enable/Disable When disabled, the scanner will not read GS1 DataBar Limited bar codes. $CLBEN00 DEFAULT GS1 DataBar Limited = Disable $CLBEN01 GS1 DataBar Limited = Enable GS1 DataBar Limited GS1-128 Emulation...

  • Page 147: Gs1 Databar Limited 2D Component

    Enter/Exit Programming Mode GS1 DataBar™ Limited GS1 DataBar Limited 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded.. $CLBU800 DEFAULT GS1 DataBar Limited 2D Component = Disable (2D component non required) $CLBU801 GS1 DataBar Limited 2D Component =...

  • Page 148: Code 39 Enable/Disable

    1D Symbologies Enter/Exit Programming Mode Code 39 The following options apply to the Code 39 symbology. Code 39 Enable/Disable When disabled, the scanner will not read Code 39 bar codes. $CC3EN00 Code 39 = Disable $CC3EN01 DEFAULT Code 39 = Enable Code 39 Check Character Calculation Enable this option to enable/disable calculation and verification of an optional Code 39 check character.

  • Page 149: Code 39 Check Character Transmission

    Enter/Exit Programming Mode Code 39 Code 39 Check Character Calculation (continued) $CC3CC04 Code 39 Check Character Calculation = Enable Italian Post Check $CC3CC08 Code 39 Check Character Calculation = Enable Daimler Chrysler Check Code 39 Check Character Transmission Enable this option to transmit the check character along with Code 39 bar code data.

  • Page 150: Code 39 Start/Stop Character Transmission

    1D Symbologies Enter/Exit Programming Mode Code 39 Start/Stop Character Transmission Enable this option to enable/disable transmission of Code 39 start and stop characters. $CC3SS00 DEFAULT Code 39 Start/Stop Character Transmission = Don’t Transmit $CC3SS01 Code 39 Start/Stop Character Transmission = Transmit Code 39 Full ASCII In Code 39 decoding, this enables/disables the translation of Code 39 charac- ters to Code 39 full-ASCII characters.

  • Page 151: Code 39 Quiet Zones

    Enter/Exit Programming Mode Code 39 Code 39 Quiet Zones This feature specifies the number of quiet zones for Code 39 labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label. $CC3LO01 Code 39 Quiet Zones = Small Quiet Zones on two sides $CC3LO02...

  • Page 152: Code 39 Length Control

    1D Symbologies Enter/Exit Programming Mode Code 39 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 39 symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: $CC3LC00 DEFAULT...
  • Page 153 Enter/Exit Programming Mode Code 39 Code 39 Set Length 1 This feature specifies one of the bar code lengths for Code 39 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 154 1D Symbologies Enter/Exit Programming Mode Code 39 Set Length 2 This feature specifies one of the bar code lengths for Code 39 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 155: Trioptic Code

    Enter/Exit Programming Mode Code 39 TRIOPTIC CODE The following options apply to the Trioptic symbology. Trioptic Code Enable/Disable $CP3EN00 DEFAULT Trioptic Code = Disable $CP3EN01 Trioptic Code = Enable CODE 39 DANISH PPT The following options apply to the Code 39 Danish PPT symbology. Code 39 Danish PPT Enable/Disable Enables/Disables AIM ID for Code 39 Danish PPT Codes.

  • Page 156: Code 39 Pzn

    1D Symbologies Enter/Exit Programming Mode CODE 39 PZN The following options apply to the Code 39 PZN symbology. Code 39 PZN Enable/Disable Enables/Disables the ability of the scanner to decode Code 39 PZN labels. $CP3EN00 DEFAULT Code 39 PZN = Disable $CP3EN01 Code 39 PZN = Enable CODE 39 LAPOSTE...

  • Page 157: Code 32 (Italian Pharmaceutical)

    Enter/Exit Programming Mode Code 32 (Italian Pharmaceutical) Code 32 (Italian Pharmaceutical) The following options apply to the Code 32 symbology. Code 32 Enable/Disable When disabled, the scanner will not read Code 32 bar codes. $CP3EN00 DEFAULT Code 32 = Disable $CP3EN01 Code 32 = Enable Code 32 Feature Setting Exceptions...

  • Page 158: Code 32 Start/Stop Character Transmission

    1D Symbologies Enter/Exit Programming Mode Code 32 Start/Stop Character Transmission This option enables/disable transmission of Code 32 start and stop characters. $CP3SS00 DEFAULT Code 32 Start/Stop Character Transmission = Don’t Transmit $CP3SS01 Code 32 Start/Stop Character Transmission = Transmit Code 39 CIP (French Pharmaceutical) The following options apply to the Code 39 CIP symbology.

  • Page 159: Code 128 Enable/Disable

    Enter/Exit Programming Mode Code 128 Code 128 The following options apply to the Code 128 symbology. Code 128 Enable/Disable When disabled, the scanner will not read Code 128 bar codes. $CC8EN00 Code 128 = Disable $CC8EN01 DEFAULT Code 128 = Enable Expand Code 128 to Code 39 This feature enables/disables expansion of Code 128 labels to Code 39 labels.

  • Page 160: Code 128 Check Character Transmission

    1D Symbologies Enter/Exit Programming Mode Code 128 Check Character Transmission Enable this option to transmit the check character along with Code 128 bar code data. $CC8CT00 DEFAULT Code 128 Check Character Transmission = Don’t Send $CC8CT01 Code 128 Check Character Transmission = Send Code 128 Function Character Transmission Enables/disables transmission of Code128 function characters 1, 2, 3, and 4.

  • Page 161: Code 128 Quiet Zones

    Enter/Exit Programming Mode Code 128 Code 128 Quiet Zones This feature specifies the number of quiet zones for Code 128 labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label. $CC8LO00 Code 128 Quiet Zones = No Quiet Zones $CC8LO01...

  • Page 162: Code 128 Length Control

    1D Symbologies Enter/Exit Programming Mode Code 128 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 128 symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: $CC8LC00 DEFAULT...
  • Page 163 Enter/Exit Programming Mode Code 128 Code 128 Set Length 2 This feature specifies one of the bar code lengths for Code 128 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
  • Page 164 1D Symbologies Enter/Exit Programming Mode GS1-128 The following options apply to the GS1-128 symbology. (Also known as USS- 128, GTIN-128, UCC-128.) GS1-128 Enable This option enables/disables the ability of the scanner to translate GS1-128 labels to the GS1-128 data format. Options are: •...
  • Page 165 Enter/Exit Programming Mode Interleaved 2 of 5 (I 2 of 5) Interleaved 2 of 5 (I 2 of 5) The following options apply to the I 2 of 5 symbology. When reading this symbology, the settings for I 2 of 5 Length Control AND I 2 of 5 Check Character Calculation MUST be enabled to increase decoding safety.

  • Page 166: I 2 Of 5 Check Character Calculation

    1D Symbologies Enter/Exit Programming Mode I 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional I 2 of 5 check character. DEFAULT I 2 of 5 Check Char Calc = Disable $CI2CC01 I 2 of 5 Check Char Calc = Check Standard (Modulo 10) I 2 of 5 Check Char Calc = Check German Parcel $CI2CC04...

  • Page 167: I 2 Of 5 Check Character Transmission

    Enter/Exit Programming Mode Interleaved 2 of 5 (I 2 of 5) I 2 of 5 Check Character Transmission Enable this option to transmit the check character along with I 2 of 5 bar code data. This feature is valid only when I 2 of 5 Check Character Calculation is enabled. NOTE $CI2CT00 I 2 of 5 Check Character Transmission = Don’t Send...
  • Page 168 1D Symbologies Enter/Exit Programming Mode I 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for I 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 169 Enter/Exit Programming Mode Interleaved 2 of 5 (I 2 of 5) I 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for I 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in...

  • Page 170: Interleaved 2 Of 5 Cip Hr Enable/Disable

    1D Symbologies Enter/Exit Programming Mode Interleaved 2 of 5 CIP HR The following options apply to the Interleaved 2 of 5 CIP HR symbology. Interleaved 2 of 5 CIP HR Enable/Disable Enables/Disables ability of scanner to decode Interleaved 2 of 5 CIP HR labels. $CCHEN00 DEFAULT Interleaved 2 of 5 CIP HR = Disable...
  • Page 171 Enter/Exit Programming Mode Matrix 2 of 5 Matrix 2 of 5 Matrix 2 of 5 Enable/Disable Enables/Disables ability of scanner to decode Matrix 2 of 5 labels. $CCHEN00 DEFAULT Matrix 2 of 5 = Disable $CCHEN01 Matrix 2 of 5 = Enable Matrix 2 of 5 Check Character Calculation Enables/Disables calculation and verification of Matrix 2 of 5 check character.
  • Page 172 1D Symbologies Enter/Exit Programming Mode Matrix 2 of 5 Check Character Transmission Enables/Disables transmission of Matrix 2 of 5 check character. $CCHEN00 DEFAULT Matrix 2 of 5 Check Character Transmission = Disable $CCHEN01 Matrix 2 of 5 Check Character Transmission = Enable Matrix 2 of 5 Length Control This feature specifies variable length decoding or fixed length decoding for the Matrix 2 of 5 symbology.
  • Page 173 Enter/Exit Programming Mode Matrix 2 of 5 Matrix 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Matrix 2 of 5 Length Con- trol. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 174 1D Symbologies Enter/Exit Programming Mode Matrix 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Matrix 2 of 5 Length Con- trol. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 175: Datalogic 2 Of 5 Enable/Disable

    Enter/Exit Programming Mode Datalogic 2 of 5 Datalogic 2 of 5 The following options apply to the Datalogic 2 of 5 symbology. Datalogic 2 of 5 Enable/Disable When disabled, the scanner will not read Datalogic 2 of 5 bar codes. $CD2EN00 DEFAULT Datalogic 2 of 5 = Disable...

  • Page 176: Datalogic 2 Of 5 Check Character Transmission

    1D Symbologies Enter/Exit Programming Mode Datalogic 2 of 5 Check Character Transmission This option enables/disables transmission of an optional Datalogic 2 of 5 char- acter. $CD2CT00 Datalogic 2 of 5 Check Character Transmission = Don’t Send $CD2CT01 DEFAULT Datalogic 2 of 5 Check Character Transmission = Send Product Reference Guide...

  • Page 177: Datalogic 2 Of 5 Length Control

    Enter/Exit Programming Mode Datalogic 2 of 5 Datalogic 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Datalogic 2 of 5 symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set.
  • Page 178 1D Symbologies Enter/Exit Programming Mode Datalogic 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Datalogic 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
  • Page 179 Enter/Exit Programming Mode Compressed 2 of 5 Compressed 2 of 5 Compressed 2 of 5 Enable/Disable Enables/Disables ability of scanner to decode Compressed 2 of 5 labels. DEFAULT Compressed 2 of 5 = Disable Compressed 2 of 5 = Enable Compressed 2 of 5 Check Character Calculation Enables/Disables calculation and verification of Compressed 2 of 5 check char- acter.
  • Page 180 1D Symbologies Enter/Exit Programming Mode Compressed 2 of 5 Check Character Transmission Enables/disables transmission of optional Compressed 2 of 5 check character. DEFAULT Compressed 2 of 5 Check Character Transmission = Disable Compressed 2 of 5 Check Character Transmission = Enable Compressed 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Compressed 2 of 5 symbology.
  • Page 181 Enter/Exit Programming Mode Compressed 2 of 5 Compressed 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Compressed 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 182 1D Symbologies Enter/Exit Programming Mode Compressed 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Compressed 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 183: Codabar Enable/Disable

    Enter/Exit Programming Mode Codabar Codabar The following options apply to the Codabar symbology. Codabar Enable/Disable When disabled, the scanner will not read Codabar bar codes. $CCBEN00 DEFAULT Codabar = Disable $CCBEN01 Codabar = Enable Codabar Check Character Calculation Enable this option to enable/disable calculation and verification of an optional Codabar check character.

  • Page 184: Codabar Check Character Transmission

    1D Symbologies Enter/Exit Programming Mode Codabar Check Character Calculation = Enable Modulo 10 check char. Codabar Check Character Calculation = Enable NW-7 Codabar Check Character Transmission Enable this option to transmit the check character along with Codabar bar code data. This feature is valid only when Codabar Check Character Calculation is enabled.

  • Page 185: Codabar Start/Stop Character Transmission

    Enter/Exit Programming Mode Codabar Codabar Start/Stop Character Transmission Enable this option to enable/disable transmission of Codabar start and stop characters. $CCBSS00 Codabar Start/Stop Character Transmission = Don’t Transmit $CCBSS01 DEFAULT Codabar Start/Stop Character Transmission = Transmit...

  • Page 186: Codabar Start/Stop Character Set

    1D Symbologies Enter/Exit Programming Mode Codabar Start/Stop Character Set This option specifies the format of transmitted Codabar start/stop characters. Codabar Check Character Set = ABCD/TN*E Codabar Check Character Set = ABCD/ABCD Codabar Check Character Set = abcd/tn*e DEFAULT Codabar Check Character Set = abcd/abcd Codabar Start/Stop Character Match When enabled, this option requires that start and stop characters match.

  • Page 187: Codabar Quiet Zones

    Enter/Exit Programming Mode Codabar Codabar Quiet Zones This feature specifies the number of quiet zones for Codabar labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label. $CCBLO01 Codabar Quiet Zones = Quiet Zone on one side $CCBLO02...

  • Page 188: Codabar Length Control

    1D Symbologies Enter/Exit Programming Mode Codabar Length Control This feature specifies either variable length decoding or fixed length decoding for the Codabar symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: DEFAULT Codabar Length Control = Variable Length...
  • Page 189 Enter/Exit Programming Mode Codabar Codabar Set Length 2 This feature specifies one of the bar code lengths for Codabar Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 190: Abc Codabar Enable/Disable

    1D Symbologies Enter/Exit Programming Mode ABC Codabar The following options apply to the ABC Codabar symbology. ABC Codabar Enable/Disable Enables/Disables ability of scanner to decode ABC Codabar labels. $CCBAB00 DEFAULT ABC Codabar = Disable $CCBAB01 ABC Codabar = Enable ABC Codabar Concatenation Mode Specifies the concatenation mode between Static and Dynamic.

  • Page 191: Abc Codabar Dynamic Concatenation Timeout

    Enter/Exit Programming Mode ABC Codabar ABC Codabar Dynamic Concatenation Timeout This parameter specifies the timeout in 10-millisecond ticks used by the ABC Codabar Dynamic Concatenation Mode. The timeout can be set within a range of 05 to 255 in 10ms increments. A setting of zero specifies no delay. $CCBDT To configure this feature, scan the ENTER/EXIT bar code above, then the bar code at left followed by digits...

  • Page 192: Code 11 Enable/Disable

    1D Symbologies Enter/Exit Programming Mode Code 11 The following options apply to the Code 11 symbology. Code 11 Enable/Disable When disabled, the scanner will not read Code 11 bar codes. $CC1EN00 DEFAULT Code 11 = Disable $CC1EN01 Code 11 = Enable Code 11 Check Character Calculation This option enables/disables calculation and verification of optional Code 11 check character.

  • Page 193: Code 11 Check Character Transmission

    Enter/Exit Programming Mode Code 11 Code 11 Check Character Transmission This feature enables/disables transmission of an optional Code 11 check char- acter. $CC1CT00 Code 11 Check Character Transmission = Don’t Send $CC1CT01 DEFAULT Code 11 Check Character Transmission = Send Code 11 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 11 symbology.
  • Page 194 1D Symbologies Enter/Exit Programming Mode Code 11 Set Length 1 This feature specifies one of the bar code lengths for Code 11 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 195 Enter/Exit Programming Mode Code 11 Code 11 Set Length 2 This feature specifies one of the bar code lengths for Code 11 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 196: Standard 2 Of 5 Enable/Disable

    1D Symbologies Enter/Exit Programming Mode Standard 2 of 5 The following options apply to the Standard 2 of 5 symbology. Standard 2 of 5 Enable/Disable When disabled, the scanner will not read Standard 2 of 5 bar codes. $CS2EN00 DEFAULT Standard 2 of 5 = Disable $CS2EN01 Standard 2 of 5 = Enable...

  • Page 197: Standard 2 Of 5 Check Character Transmission

    Enter/Exit Programming Mode Standard 2 of 5 Standard 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Standard 2 of 5 check character. $CS2CT00 Standard 2 of 5 Check Character Transmission = Don’t Send $CS2CT01 DEFAULT Standard 2 of 5 Check Character Transmission = Send Standard 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding...
  • Page 198 1D Symbologies Enter/Exit Programming Mode Standard 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Standard 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 199 Enter/Exit Programming Mode Standard 2 of 5 Standard 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Standard 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length...

  • Page 200: Industrial 2 Of 5 Enable/Disable

    1D Symbologies Enter/Exit Programming Mode Industrial 2 of 5 The following options apply to the Industrial 2 of 5 symbology. Industrial 2 of 5 Enable/Disable Enables/Disables ability of scanner to decode Industrial 2 of 5 labels. $CU2EN00 DEFAULT Industrial 2 of 5 = Disable $CU2EN01 Industrial 2 of 5 = Enable Industrial 2 of 5 Check Character Calculation...

  • Page 201: Industrial 2 Of 5 Check Character Transmission

    Enter/Exit Programming Mode Industrial 2 of 5 Industrial 2 of 5 Check Character Transmission Enables/disables transmission of an Industrial 2 of 5 check character. $CU2CT00 Industrial 2 of 5 Check Character Transmission = Disable $CU2CT01 DEFAULT Industrial 2 of 5 Check Character Transmission = Enable Industrial 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Industrial 2 of 5 symbology.
  • Page 202 1D Symbologies Enter/Exit Programming Mode Industrial 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Industrial 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 203 Enter/Exit Programming Mode Industrial 2 of 5 Industrial 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Industrial 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length...

  • Page 204: Iata Enable/Disable

    1D Symbologies Enter/Exit Programming Mode IATA The following options apply to the IATA symbology. IATA Enable/Disable Enables/Disables the ability of the scanner to decode IATA labels. $CIAEN00 DEFAULT IATA = Disable $CIAEN01 IATA = Enable IATA Check Character Transmission Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character.

  • Page 205: Isbt 128 Concatenation Mode

    Enter/Exit Programming Mode ISBT 128 ISBT 128 The following options apply to the ISBT 128 symbology. ISBT 128 Concatenation Enables/disables ISBT128 concatenation of 2 labels. $CI8CE00 DEFAULT ISBT 128 Concatenation = Disable $CI8CE01 ISBT 128 Concatenation = Enable ISBT 128 Concatenation Mode Specifies the concatenation mode between Static and Dynamic.

  • Page 206: Isbt 128 Dynamic Concatenation Timeout

    1D Symbologies Enter/Exit Programming Mode ISBT 128 Dynamic Concatenation Timeout Specifies the timeout used by the ISBT 128 Dynamic Concatenation Mode. $CI8DT05 ISBT 128 Dynamic Concatenation Timeout = 50 msec $CI8DT0A ISBT 128 Dynamic Concatenation Timeout = 100 msec $CI8DT14 DEFAULT ISBT 128 Dynamic Concatenation Timeout = 200 msec $CI8DT32...

  • Page 207: Isbt 128 Force Concatenation

    Enter/Exit Programming Mode ISBT 128 ISBT 128 Force Concatenation When enabled, this feature forces all ISBT 128 labels to be concatenated. This option is only valid when ISBT 128 Concatenation is enabled. NOTE $CI8FC00 DEFAULT ISBT 128 Force Concatenation = Disable $CI8FC01 ISBT 128 Force Concatenation = Enable ISBT 128 Advanced Concatenation Options...

  • Page 208: Msi Enable/Disable

    1D Symbologies Enter/Exit Programming Mode The following options apply to the MSI symbology. MSI Enable/Disable Enables/Disables ability of scanner to decode MSI labels. DEFAULT MSI = Disable $CMSEN01 MSI = Enable MSI Check Character Calculation Enables/Disables calculation and verification of an optional MSI check charac- ter.

  • Page 209: Msi Check Character Transmission

    Enter/Exit Programming Mode MSI Check Character Transmission Enables/disables transmission of an MSI check character. $CMSCT00 MSI Check Character Transmission = Disable $CMSCT01 DEFAULT MSI Check Character Transmission = Enable MSI Length Control This feature specifies either variable length decoding or fixed length decoding for the MSI symbology.
  • Page 210 1D Symbologies Enter/Exit Programming Mode MSI Set Length 1 This feature specifies one of the bar code lengths for MSI Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 211 Enter/Exit Programming Mode MSI Set Length 2 This feature specifies one of the bar code lengths for MSI Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 212: Plessey Enable/Disable

    1D Symbologies Enter/Exit Programming Mode PLESSEY The following options apply to the Plessey symbology. Plessey Enable/Disable Enables/Disables ability of scanner to decode Plessey labels. $CCHEN00 DEFAULT Plessey = Disable $CCHEN01 Plessey = Enable Product Reference Guide...

  • Page 213: Plessey Check Character Calculation

    Enter/Exit Programming Mode Plessey Check Character Calculation Enables/Disables calculation and verification of Plessey check character. $CCHEN00 Plessey Check Character Calculation = Disable $CCHEN01 DEFAULT Plessey Check Character Calculation = Enable Plessey std. check char. verification $CCHEN00 Plessey Check Character Calculation = Enable Anker check char.

  • Page 214: Plessey Length Control

    1D Symbologies Enter/Exit Programming Mode Plessey Length Control This feature specifies variable length decoding or fixed length decoding for the Plessey symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: $CCHEN00 DEFAULT...
  • Page 215 Enter/Exit Programming Mode Plessey Set Length 1 This feature specifies one of the bar code lengths for Plessey Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data char- acters only.
  • Page 216 1D Symbologies Enter/Exit Programming Mode Plessey Set Length 2 This feature specifies one of the bar code lengths for Plessey Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters.

  • Page 217: Code 93 Enable/Disable

    Enter/Exit Programming Mode Code 93 Code 93 The following options apply to the Code 93 symbology. Code 93 Enable/Disable Enables/Disables ability of scanner to decode Code 93 labels. DEFAULT Code 93 = Disable Code 93 = Enable Code 93 Check Character Calculation Enables/disables calculation and verification of an optional Code 93 check character.

  • Page 218: Code 93 Check Character Transmission

    1D Symbologies Enter/Exit Programming Mode Code 93 Check Character Transmission Enables/disables transmission of an optional Code 93 check character. DEFAULT Code 93 Check Character Transmission = Disable Code 93 Check Character Transmission = Enable Code 93 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 93 symbology.
  • Page 219 Enter/Exit Programming Mode Code 93 Code 93 Set Length 1 This feature specifies one of the bar code lengths for Code 93 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length.
  • Page 220 1D Symbologies Enter/Exit Programming Mode Code 93 Set Length 2 This feature specifies one of the bar code lengths for Code 93 Length Control Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 221: Code 93 Quiet Zones

    Enter/Exit Programming Mode Code 93 Code 93 Quiet Zones Enables/disables fixed length stitching for Code 93. This feature is available only on the TD1130 model. NOTE $CC9LO00 Code 93 Quiet Zones = No Quiet Zones $CC9LO01 Code 93 Quiet Zones = Quiet Zone on one side $CC9LO02 Code 93 Quiet Zones = Quiet Zones on two sides $CC9LO03...

  • Page 222: Follett 2 Of 5 Enable/Disable

    1D Symbologies Enter/Exit Programming Mode Follett 2 of 5 The following options apply to the Follett 2 of 5 symbology. Follett 2 of 5 Enable/Disable Enables/Disables ability of scanner to decode Follett 2 of 5 labels. $CF2EN00 DEFAULT Follett 2 of 5 = Disable $CF2EN01 Follett 2 of 5 = Enable BC412...

  • Page 223: Bc412 Check Character Calculation

    Enter/Exit Programming Mode BC412 BC412 Check Character Calculation Enable this option to enable/disable calculation and verification of an optional BC412 check character. When disabled, any check character in the label is treated as a data character. $CBCCC00 BC412 Check Character Calculation = Don’t Calculate $CBCCC01 DEFAULT BC412 Check Character Calculation = Calculate Check Character...

  • Page 224: Bc412 Length Control

    1D Symbologies Enter/Exit Programming Mode BC412 Length Control This feature specifies either variable length decoding or fixed length decoding for the BC412 symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: $CBCLC00 DEFAULT...
  • Page 225 Enter/Exit Programming Mode BC412 BC412 Set Length 1 This feature specifies one of the bar code lengths for BC412 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 226 1D Symbologies Enter/Exit Programming Mode BC412 Set Length 2 This feature specifies one of the bar code lengths for BC412 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
  • Page 227 1D Symbologies NOTES...

  • Page 228: Global Features

    2D Symbologies 2D Global Features 2D M 2D N AXIMUM ECODING ORMAL NVERSE YMBOL ONTROL • • 2D S TRUCTURED PPEND • The reader supports the following 2D symbologies (bar code types). Symbol- ogy-dependent options for each symbology are included in this chapter. See "1D Symbologies"...

  • Page 229: Maximum Decoding Time

    Enter/Exit Programming Mode 2D Global Features 2D Maximum Decoding Time This feature specifies the maximum amount of time the software will spend attempting to decode a 2D label. The selectable range is 10 milliseconds to 2.55 milliseconds. 2D Maximum Decoding Time = 100 msec 2D Maximum Decoding Time = 200 msec DEFAULT 2D Maximum Decoding Time = 350 msec...

  • Page 230: Structured Append

    2D Symbologies Enter/Exit Programming Mode 2D Structured Append Enables/disables ability of reader to append multiple 2D Codes labels in a structured format. The structured append property is globally applied to the following symbologies, if these are enabled: • Data Matrix •...

  • Page 231: Symbology Selection

    Enter/Exit Programming Mode Aztec Code Symbology Selection Aztec Code Aztec Code Enable / Disable Enables/disables the ability of the reader to decode Aztec Code labels. Aztec Code = Disable DEFAULT Aztec Code = Enable Aztec Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
  • Page 232 Symbology Selection Enter/Exit Programming Mode Aztec Code Set Length 1 Specifies one of the bar code lengths for Aztec Code Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Characters can be set from 0001 to 3,832 characters in increments of 0001 (pad with zeroes).
  • Page 233 Enter/Exit Programming Mode Aztec Code Aztec Code Set Length 2 This feature specifies one of the bar code lengths for Aztec Code Length Con- trol. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Characters can be set from 0001 to 3,832 characters in increments of 0001 (pad with zeroes).

  • Page 234: China Sensible Code Enable / Disable

    Symbology Selection Enter/Exit Programming Mode China Sensible Code China Sensible Code Enable / Disable Enables/disables the ability of the reader to decode China Sensible Code labels. DEFAULT China Sensible Code = Disable China Sensible Code = Enable China Sensible Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.

  • Page 235: Set Length

    Enter/Exit Programming Mode China Sensible Code China Sensible Code Set Length 1 Specifies one of the bar code lengths for China Sensible Code Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 236 Symbology Selection Enter/Exit Programming Mode China Sensible Code Set Length 2 This feature specifies one of the bar code lengths for China Sensible Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Characters can be set from 0001 to 7,827 characters in increments of 0001 (pad with zeroes).

  • Page 237: Data Matrix Enable / Disable

    Enter/Exit Programming Mode Data Matrix Data Matrix Data Matrix Enable / Disable Enables/disables ability of reader to decode Data Matrix labels Data Matrix = Disable DEFAULT Data Matrix = Enable Data Matrix Square/Rectangular Style Specifies the options available when reading Data Matrix with different form factors.

  • Page 238: Data Matrix Length Control

    Symbology Selection Enter/Exit Programming Mode Data Matrix Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: DEFAULT Data Matrix Length Control = Variable Length...
  • Page 239 Enter/Exit Programming Mode Data Matrix Data Matrix Set Length 2 This feature specifies one of the bar code lengths for Data Matrix Length Con- trol. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Characters can be set from 0001 to 3,116 characters in increments of 0001 (pad with zeroes).
  • Page 240 Symbology Selection Enter/Exit Programming Mode GS1 DotCode The following options apply for the DotCode barcode decoding. DotCode Enable This options enables/disables the ability of the scanner to decode DotCode barcodes. DotCode = Enable DEFAULT DotCode = Disable DotCode High Resolution Enable This options improves the decoding performance for very small module size barcodes, e.g.

  • Page 241: Additional Options

    Symbology Selection DotCode Position-based Decoding This option can improve the decoding performance when the next barcode to be decoded is approximately shown in the same position as the previous one. DotCode Position-based Decoding = Enable DEFAULT DotCode Position-based Decoding = Disable Additional Options To improve performances the following additional settings are available using...

  • Page 242: Maxicode Primary Message Transmission

    Symbology Selection Enter/Exit Programming Mode Maxicode Primary Message Transmission Enables/disables the transmission of only the Primary Message when the Secondary Message is not readable. DEFAULT Maxicode Primary Message Transmission = Disable Maxicode Primary Message Transmission = Enable Product Reference Guide...

  • Page 243: Maxicode Length Control

    Enter/Exit Programming Mode Maxicode Maxicode Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: DEFAULT Maxicode Length Control = Variable Length...
  • Page 244 Symbology Selection Enter/Exit Programming Mode Maxicode Set Length 2 This feature specifies one of the bar code lengths for Maxicode Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Characters can be set from 0001 to 0145 characters in increments of 0001 (pad with zeroes).

  • Page 245: Pdf417 Enable / Disable

    Enter/Exit Programming Mode PDF417 PDF417 PDF417 Enable / Disable Enables/disables the ability of the reader to decode PDF417 labels. PDF417 = Disable DEFAULT PDF417 = Enable PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
  • Page 246 Symbology Selection Enter/Exit Programming Mode PDF417 Set Length 1 Specifies one of the bar code lengths for PDF417 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. Characters can be set from 0001 to 2,710 characters (pad with zeroes) in increments of 01.
  • Page 247 Enter/Exit Programming Mode PDF417 PDF417 Set Length 2 This feature specifies one of the bar code lengths for PDF417 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters.

  • Page 248: Micro Pdf417 Enable / Disable

    Symbology Selection Enter/Exit Programming Mode Micro PDF417 Micro PDF417 Enable / Disable Enables/disables the ability of the reader to decode Micro PDF417 labels. DEFAULT Micro PDF417 = Disable Micro PDF417 = Enable Micro PDF417 Code 128 GS1-128 Emulation Specifies which AIM ID to use for MicroPDF labels when doing Code 128 or GS1- 128 emulation.

  • Page 249: Micro Pdf417 Length Control

    Enter/Exit Programming Mode Micro PDF417 Micro PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: DEFAULT Micro PDF417 Length Control = Variable Length...
  • Page 250 Symbology Selection Enter/Exit Programming Mode Micro PDF417 Set Length 2 This feature specifies one of the bar code lengths for Micro PDF417 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length includes the bar code’s data characters only.

  • Page 251: Qr Code Enable / Disable

    Enter/Exit Programming Mode QR Code QR Code QR Code Enable / Disable Enables/disables the ability of the reader to decode QR Code labels. QR Code = Disable DEFAULT QR Code = Enable QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
  • Page 252 Symbology Selection Enter/Exit Programming Mode QR Code Set Length 1 Specifies one of the bar code lengths for QR Code Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Characters can be set from 0001 to 7,089 characters in increments of 0001 (pad with zeroes).
  • Page 253 Enter/Exit Programming Mode QR Code QR Code Set Length 2 This feature specifies one of the bar code lengths for QR Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Characters can be set from 0001 to 7,089 characters in increments of 0001 (pad with zeroes).

  • Page 254: Micro Qr Code Enable/Disable

    Symbology Selection Enter/Exit Programming Mode Micro QR Code Micro QR Code Enable/Disable Enables/disables the ability of the reader to decode Micro QR Code labels. DEFAULT Micro QR Code = Disable Micro QR Code = Enable Micro QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.

  • Page 255: Micro Qr Code

    Enter/Exit Programming Mode Micro QR Code Micro QR Code Set Length 1 Specifies one of the bar code lengths for Micro QR Code Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
  • Page 256 Symbology Selection Enter/Exit Programming Mode Micro QR Code Set Length 2 This feature specifies one of the bar code lengths for Micro QR Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Characters can be set from 0001 to 0035 characters in increments of 0001 (pad with zeroes).

  • Page 257: Ucc Optional Composite Timer

    Enter/Exit Programming Mode UCC Composite UCC Composite UCC Optional Composite Timer Specifies the amount of time the system will wait for the stacked part of a UCC Composite label before transmitting the linear label without an add-on. UCC Optional Composite Timer = Timer Disabled UCC Optional Composite Timer = 70msec UCC Optional Composite Timer = 100msec UCC Optional Composite Timer = 200msec...

  • Page 258: Postal Code Selection

    Postal Code Selection Postal Code Selection Enables/disables the ability of the scanner to decode labels of a specific postal symbology. • Disable All Postal Codes • Australia Post • Postnet • Japan Post • Planet • IMB • Royal Mail •...

  • Page 259: Postnet Bb Control

    Symbology Selection Postal Code Selection (continued) $CPOEN06(CR) Postal Code Selection = Enable Japan Post $CPOEN07(CR) Postal Code Selection = Enable IMB $CPOEN08(CR) Postal Code Selection = Enable Sweden Post $CPOEN09(CR) Postal Code Selection = Enable Portugal Post Postnet BB Control Controls the ability of the scanner to decode B and B' fields of Postnet labels.
  • Page 260 OCR Decoding family is equipped with an Optical Character Recognition feature. This section describes how to configure the barcode scanner to enable OCR decoding. support the following OCR font types: • OCR-A • OCR-B • MICR E13B • US Currency Serial Number. In most OCR applications a suitable usage of check digits and the addition of constraints on sub-strings types (e.g.
  • Page 261 OCR Decoding OCR predefined template: EU ID Card OCR Format EU Identity Card OCR OCR predefined template: IATA Passport IATA Passport OCR OCR predefined template: Italian Post payment form Italian Post OCR Payment OCR predefined template: Italian Bank payment form Enable Italian Bank Freccia Bank Payment form OCR predefined template: Swiss Driving License Enable Swiss Driving License OCR...
  • Page 262 OCR Decoding Disable Use the following label to turn off the OCR decoding feature: DEFAULT Disable OCR function Product Reference Guide...
  • Page 263 OCR Decoding NOTES...

  • Page 264: Motion Features

    Motion Features Enter/Exit Programming Mode Motion Features OTION IMING ONTROL OTION ENSITIVITY OTIONLESS IMEOUT Use this chapter to configure motion settings for the handheld. Reference Appendix B, for a listing of standard factory settings. Motion Aiming Control Configures the ability of the scanner to Enable/Disable the Aiming system when motion is detected.

  • Page 265: Motionless Timeout

    Motion Features Motionless Timeout Specifies the waiting time in 100 millisecond ticks to assume that the reader is in a motionless condition. The selectable range is 500 msec to 25.5 Seconds. When no motion event is detected for a period of time longer than this timeout, the software assumes the reader is in a motionless condition.
  • Page 266 Chapter 4 References This section contains explanations and examples of selected bar code features. "Configuration Using Bar Codes" for the actual bar code labels used to configure the scanner. RS-232 P ARAMETERS RS-232 Only • RS-232/USB COM Parameters • EYBOARD NTERFACE Wedge Quiet Interval •...
  • Page 267 References RS-232 Parameters RS-232 Only Baud Rate Baud rate is the number of bits of data transmitted per second. Set the scan- ner's baud rate to match the baud rate setting of the host device. With an improper baud rate setting, data may not reach the host correctly. Data Bits This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and receiving data.

  • Page 268: Rs-232/Usb Com Parameters

    RS-232 Parameters RS-232/USB COM Parameters Intercharacter Delay This parameter specifies the intercharacter delay between the end of one char- acter and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay.
  • Page 269 References ACK NAK Options This enables/disables the ability of the scanner to support the RS-232 ACK/ NAK protocol. When configured, the scanner and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error. Options are: •...
  • Page 270 RS-232 Parameters NAK Character This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
  • Page 271 References ACK NAK Timeout Value This option specifies the amount of time the scanner waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout.
  • Page 272 RS-232 Parameters ACK NAK Retry Count This feature specifies the number of times the scanner retries a label transmis- sion due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries.
  • Page 273 References Disable Character Specifies the value of the RS-232 host command used to disable the scanner. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.
  • Page 274 RS-232 Parameters Enable Character Specifies the value of the RS-232 host command used to enable the scanner. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.
  • Page 275 References Keyboard Interface Wedge Quiet Interval Specifies the amount of time the scanner looks for keyboard activity before it breaks the keyboard connection in order to transmit data to host. The range is from 0 to 990ms in 10ms increments. This feature applies ONLY to the Keyboard Wedge interface.
  • Page 276 Keyboard Interface Intercharacter Delay This parameter specifies the intercharacter delay between the end of one char- acter and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay.
  • Page 277 References Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is from 0 to 99 seconds. Follow these instructions to set this feature: 1. Determine the desired setting. 2. Pad the number with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc can the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming Mode.

  • Page 278: Data Editing

    Data Format Data Format Data Editing When a bar code is scanned, additional information can be sent to the host computer along with the bar code data. This combination of bar code data and supplementary user-defined data is called a “message string.” The Data Editing features can be used to build specific user-defined data into a message string.

  • Page 279: Example: Setting A Prefix

    References Global Prefix/Suffix Up to 20 ASCII characters may be added as a prefix (in a position before the bar code data) and/or as a suffix (in a position following the bar code data) as indi- cated. Figure 18. Prefix and Suffix Positions OR...
  • Page 280 Data Format Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. NOTE AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. AIM label identifiers consist of three characters as follows: •...
  • Page 281 References Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.
  • Page 282 Data Format Symbology USA Label ID set EU Label ID set I2OF5 690000 4E0000 IATA 494100 & 260000 Industrial 2 of 5 570000 570000 Interleaved 2 of 5 650000 650000 ISBN 490000 400000 ISBT128 660000 660000 ISSN 6E0000 6E0000 400000 5A0000 730000 500000...
  • Page 283 References Label ID: Set Individually Per Symbology To configure a Label ID individually for a single symbology: 1. Scan the ENTER/EXIT bar code. 2. Select Label ID position as either BEFORE (Enable as Prefix) or AFTER (Enable as suffix) by scanning the appropriate bar code in the section "Label ID Control".
  • Page 284 Data Format Label ID: Set Individually Per Symbology — continued Table 22. Label ID Examples STEP ACTION EXAMPLES Scan the ENTER/EXIT bar (Scanner enters Programming Mode) code Determine placement of the Label ID characters BEFORE or AFTER with regard to Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix scanned data using "Label...
  • Page 285 References Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to.
  • Page 286 Scanning Features Scanning Features Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 milliseconds (0.001 to 2.55 seconds) in 100ms incre- ments.
  • Page 287 Enter/Exit Programming Mode Scanning Features RGB Good Read Color Set the Good Read LED color. $CPOBB00(CR) RGB Good Read Color = RED $CPOBB01(CR) DEFAULT RGB Good Read Color = GREEN $CPOBB01(CR) RGB Good Read Color = BLUE Scan Mode Selects the scan operating mode for the reader. Selections are: When the trigger is pulled, scanning is activated until one of the Trigger Single: following occurs:...
  • Page 288 References Enter/Exit Programming Mode No trigger pull is required to read a bar code. Scanning is continually Always On: Double Read Timeout prevents undesired multiple reads of the same label while in this mode. No trigger pull is required to read a bar code. Stand Mode/Object Detection: Scanning turns on automatically when an item is placed in reader's field of view.
  • Page 289 References Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.

  • Page 290: Aiming Duration Time

    Scanning Features Aiming Duration Time Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.
  • Page 291 References Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1.
  • Page 292 Scanning Features Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1.

  • Page 293: Rf Address Stamping

    References RF Features Automatic Configuration Update When this feature is enabled, the base station and reader will keep their config- urations synchronized. If a reader's configuration is altered by reading pro- gramming labels, this change is automatically transferred and updated in a linked base station.
  • Page 294 References Symbologies Set Length Length Control allows you to select either variable length decoding or fixed length decoding for the specified symbology. For variable length decoding, a minimum and maximum length Variable Length: may be set. For fixed length decoding, two different lengths may be set. Fixed Length: Set Length 1 This feature specifies one of the bar code lengths for a given symbology.
  • Page 295 Symbologies Set Length 2 This feature specifies one of the bar code lengths for a given symbology. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Reference the 1D Symbologies section to view the selectable range (number of characters) for the symbology being set.

  • Page 296: Technical Specifications

    Appendix A Technical Specifications Table 32. Technical Specifications Electrical Features 5 VDC 4.5 - 14.0 VDCGBT/GM4500: 5V to 14V +/-5% in the Communication Port Power Supply 5V to 14V +/-5% in the Aux Power Port NOTE: Aux Power Port is recommended when long cables are connected to Communication Port Operating: <400 mA @ 5V <200 mA @ 12V...

  • Page 297: Optical Features

    Technical Specifications Optical Features Optical Format 1/4" Active Imager Size 3896 um (H) x 2453 um (V) Active Pixels 1280 H x 800 V LED source Warm White Emission (wavelength = 350 - 770 nm) Illumination System Hyper Red Emission (wavelength = 660 nm, DGM model only) IEC 62471 Exempt Risk Group RED laser source...
  • Page 298 DOF - Depth of Field (Typical) Symbology 3 mil: 5.0 - 15.0 cm 5 mil: 7.0 - 38.0 cm (2.7" - 14.9") (2.0" - 5.9") 10 mil: 2.2 - 58.0 cm (0.8" - 22.8") 5 mil: 0.5 - 25.0 cm Code 39 20 mil: FOV lim.

  • Page 299: Environmental Features

    Technical Specifications Environmental Features Operating Temperature 0 C to + 50 C (+32° F to +122 °F) Storage Temperature -40 C to + 70 C (-40 ° F to +158 °F) Humidity 95% non condensing IEC 68-2-32 Tested Drop Resistance 1.8 m (6 ft) ESD Protection 16 KV...

  • Page 300: Led And Beeper Indications

    Technical Specifications LED and Beeper Indications The imager’s beeper sounds and its illumination flashes or changes color to indicate various functions or errors on the reader. A “Green Spot” also lights to indicate a good read. The tables below list these indications. Table 33.

  • Page 301: Programming Mode

    Technical Specifications Programming Mode The following indications ONLY occur when the scanner is in Programming Mode. INDICATION DESCRIPTION SPEAKER Label Program- A valid programming label has Scanner sounds four low fre- ming Mode LED blinks continuously been scanned. quency beeps. Entry Label Program- Scanner sounds three times at...

  • Page 302: Standard Cable Pinouts

    Standard Cable Pinouts Standard Cable Pinouts Figure 21 and provide standard pinout information for the scanner’s Table 34 cable. Figure 21. Standard Cable Pinouts Interface Cable Port Pin 10 Pin 1 Cable To Host Cable Strain Relief Cable Clip (Latch) The signal descriptions in apply to the connector on the scanner and Table 34...
  • Page 303 NOTES...

  • Page 304: Standard Defaults

    Standard Defaults Appendix B Standard Defaults The most common configuration settings are listed in the “Default” column of the table below. rogramming bar codes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features. Table 35.
  • Page 305 Standard Defaults Parameter Default Your Setting Disable Character ‘D’ Enable Character ‘E’ KEYBOARD WEDGE Country Mode U.S. Keyboard Keyboard Send Control Characters Wedge Quiet Interval 100 ms Intercode Delay No Delay Caps Lock State Caps Lock OFF Numlock NumLock Key Unchanged USB Keyboard Speed 1 ms Keyboard Numeric Keypad...
  • Page 306 Standard Defaults Parameter Default Your Setting Good Read Beep Length 80 ms Good Read Speaker Volume / Vibration High Enable/Disable Good Read Indicator 300 ms SCANNING FEATURES Scan Mode Trigger Single Stand Mode/Object Detection Sensitiv- Medium Stand Mode Indication 5 Seconds Flash On Time 10 = Flash is ON for 1 Sec- Flash On Time...
  • Page 307 Standard Defaults Parameter Default Your Setting EAN 13 (Jan 13) EAN 13 Enable/Disable Enable EAN 13 Check Character Transmission Send EAN-13 Flag 1 Character Transmit EAN-13 ISBN Conversion Disable ISSN Disable EAN 8 EAN 8 Enable/Disable Enable EAN 8 Check Character Transmission Send Expand EAN 8 to EAN 13 Disable...
  • Page 308 Standard Defaults Parameter Default Your Setting Code 39 CIP (French Pharmaceutical Code) Code 39 CIP Enable/Disable Disable Special Codes Code 128 Code 128 Enable/Disable Enable Expand Code 128 to Code 39 Don’t Expand Code 128 Check Character Transmis- Don’t Send sion Code 128 Function Character Trans- Don’t Send...
  • Page 309 Standard Defaults Parameter Default Your Setting Follett 2 of 5 Follett 2 of 5 Enable/Disable Disable Standard 2 of 5 Standard 2 of 5 Enable/Disable Disable Standard 2 of 5 Check Character Calcu- Disable lation Standard 2 of 5 Check Character Send Transmission Standard 2 of 5 Length Control...
  • Page 310 Standard Defaults Parameter Default Your Setting Codabar Codabar Enable/Disable Disable Codabar Check Character Calculation Don’t Calculate Codabar Check Character Transmission Send Codabar Start/Stop Character Trans- Transmit mission Codabar Start/Stop Character Set abcd/abcd Codabar Start/Stop Character Match Don’t Require Match Codabar Quiet Zones Small Quiet Zones on two sides Codabar Length Control Variable...
  • Page 311 Standard Defaults Parameter Default Your Setting GS1 DataBar™ Expanded GS1 DataBar Expanded Enable/Disable Disable GS1 DataBar Expanded GS1-128 Emu- Disable lation 2D component not required GS1 DataBar Expanded Length Control Variable GS1 DataBar Expanded Set Length 1 GS1 DataBar Expanded Set Length 2 GS1 DataBar™...

  • Page 312: Default Exceptions

    Standard Defaults Default Exceptions Table 36. Default Exceptions by Interface Type Default Parameter Exception Interfaces: All Keyboard Wedge, USB Keyboard No unique settings Interface: RS232-WN Expand UPC-A to EAN-13 Enable UPC-E Check Character Transmission Disable Parity Odd Parity Handshaking Control RTS/CTS Transmission Label ID Code Prefix...
  • Page 313 Standard Defaults Default Parameter Exception EAN8/P2 Label ID Character(s) EAN8/P5 Label ID Character(s) EAN8/GS1-128 Label ID Character(s) EAN13/P2 Label ID Character(s) EAN13/P5 Label ID Character(s) EAN13/GS1-128 Label ID Character(s) GS1 DataBar 14 (Omnidirectional) Label ID Character(s) GS1 DataBar Expanded Label ID Character(s) GS1 DataBar Limited Label ID Character(s) Character Conversion CR to `...
  • Page 314 Standard Defaults Default Parameter Exception UPCA/GS1-128 Label ID Character(s) UPCE P2 Label ID Character(s) UPCE/P5 Label ID Character(s) EAN8/P2 Label ID Character(s) EAN8/P5 Label ID Character(s) EAN8/GS1-128 Label ID Character(s) EAN13/P2 Label ID Character(s) EAN13/P5 Label ID Character(s) EAN13/GS1-128 Label ID Character(s) GS1 DataBar 14 (Omnidirectional) Label ID Character(s) GS1 DataBar Expanded Label ID Character(s) GS1 DataBar Limited Label ID Character(s)
  • Page 315 Standard Defaults NOTES...

  • Page 316: Sample Bar Codes

    Sample Bar Codes Appendix C Sample Bar Codes The sample bar codes in this appendix are typical representations for their symbology types. 1D Bar Codes Code 128 Product Reference Guide...
  • Page 317 Sample Bar Codes Sample Bar Codes (continued) 345678902 13579...

  • Page 318: Gs1 Databar™ (Rss)

    Sample Bar Codes GS1 DataBar™ (RSS) GS1 DataBar GS1 DataBar™ variants must be enabled to read the bar codes below (see " Omnidirectional" NOTE 10293847560192837465019283746029478450366523 1234890hjio9900mnb 08672345650916 GS1 DataBar™-14 55432198673467 90876523412674 78123465709811 Product Reference Guide...
  • Page 319 Sample Bar Codes 2D Bar Codes Test Message ABCabc 123456...
  • Page 320 Appendix D Keypad Use the bar codes in this appendix to enter numbers as you would select digits/characters from a keypad. Product Reference Guide...
  • Page 321 Keypad...

  • Page 322: Scancode Tables

    Control Character Emulation Appendix E Scancode Tables Control Character Emulation Control character emulation selects from different scancode tables as listed in this appendix. Each of the control character sets below are detailed by interface type in the tables. These apply to Wedge and USB Keyboard platforms.

  • Page 327: Microsoft Windows Codepage 1252

    Scancode Tables Microsoft Windows Codepage 1252 Windows-1252 is a character encoding of the Latin alphabet, used by default in the legacy components of Microsoft Windows in English and some other Western languages.

  • Page 328: Ascii Chart

    ASCII Chart...
