Standard Cable Pinouts

Figure 7 and Table 22 provide standard pinout information for the reader's
cable.
Figure 7. Standard Cable Pinouts
The signal descriptions in Table 22 apply to the connector on the reader and
are for reference only.
Table 22. Standard Cable Pinouts - Reader Side
262
Cable
Cable Strain Relief
To Host
Pin RS-232
1
2
3
4
5
6
7
8
9
10
Pin 1
Cable Clip (Latch)
USB
RTS (out)
D+
GND GND
RX
TX
VCC VCC
CTS (in)
Bottom of Imager
Interface Cable Port
Pin 10
Keyboard Wedge
CLKIN (KBD side)
D- DATAIN (KBD side)
GND
VCC
CLKOUT (PC side)
DATAOUT (PC side)
