Javad DELTA Operator's Manual page 40

Specifications
Receiver Specifications
General Details
Storage temperature
Humidity
External power input
Input voltage
DELTA-G2T, G3T, G3TAJT,
DELTAD-G2, G2D
DELTAD-G3D, DELTAQ
Communication Ports
Connectors
TriPad
Up to 100 Hz update rate for real time position and raw data (code and carrier)
10 cm code phase and 1 mm carrier phase precision
Hardware Viterbi decoder
RTCM SC104 versions 2.x and 3.x Input/Output
NMEA 0183 versions 2.x and 3.0 Output
Multi-Base Code Differential Rover
Code Differential Base
Geoid and Magnetic Variation models
RAIM
Different DATUMs support
Output of grid coordinates
Low signal tracking
Advanced Multipath mitigation
KFK WAAS/EGNOS (SBAS)
Adjustable PLL and DLL parameters
In-Band Interference Rejection
NMEA version
Messages
Output interval
Correction format
RTCM 2.x message type
RTCM 3.0 message type
Process interval
40
-45° C to +85° C
95% non-condensing
External power
1 port
+4.5 to +35 V DC
+6.0 to +35 V DC
I/O
- 3x serial RS232 up to 460.8 kbps
- serial RS422/RS232 up to 460.8 kbps
- High speed USB 2.0 device port (480 Mbps)
- Full-duplex 10BASE-T/100BASE-TX Ethernet port
- External GNSS Antenna
- External power (PWR)
- CAN (optional)
- up to two 1PPS output (optional)
- up to two Event Marker input (optional)
- IEEE1588 Master Clock (Delta-G3TAJT)
- Two LEDs (STAT, REC)
- Two function buttons (ON/OFF, FN)
Data Features
Technology
2
(IBIR) (DELTAS-G3TAJ only)
NMEA
Ver. 2.1, 2.2, 2.3, 3.0
GGA, GLL, GNS, GRS, GSA, GST, GSV, HDT, RMC, VTG, ZDA, ROT, GMP
1, 5, 10, 20, 50, 100 Hz optional
DGPS
RTCM SC104 Ver 2.1, 2.2, 2.3, and 3.0
1, 3, 9, 31, 32, 34; user selectable
1003, 1004, 1005, 1006, 1007, 1008, 1011, 1012, 1019, 1020; user selectable
1, 5, 10, 20, 50, 100 Hz optional
1
