Specifications
Connector Specifications
GNSS Board Details
USB Connector
USB connector is a sealed receptacle, 5 pin, ODU p/n G80F2C-P05QF00-0000 (Figure A-4).
Table A-5 gives the USB connector specifications.
Ethernet Connector
The Ethernet connector is a sealed receptacle, 7 pin, ODU p/n G80F2C-P07QC00-0000 (Figure A-5).
46
Figure A-4. USB Connector
Table A-5. USB Connector Specifications
Number Signal Name
1
2 USB_PWR
3 GND
4 USB D+
5 USB D-
Figure A-5. Ethernet Connector
Table A-6. Ethernet Connector Specifications
Number Signal Name
1
2 Power_GND
2
3
1
4
5
Dir
P Bus power
- Ground
I/O Data plus
I/O Data minus
2
7
3
1
6
4
5
Dir
Not used
Signal ground
Details
Details
