1.2.3. Cables
The DELTA receiver package includes standard communication and power cables for configuring the
receiver and providing a power source to the receiver.
Receiver-to-computer RS232 serial cable – connects the receiver's serial port and an
external device (hand-held controller or computer)
p/n 14-578103-01
Receiver-to-SAE power cable – connects the receiver's power port and the power
supply's SAE connector or the extension cable's SAE connector
p/n 14-578101-01
SAE-to-SAE cable extension – connects SAE connectors over longer distances
p/n 14-578102-01
1.3. Option Authorization File (OAF)
JAVAD GNSS issues an Option Authorization File (OAF) to enable the specific options that customers
purchase. An Option Authorization File allows customers to customize and configure the DELTA
receiver according to particular needs, thus only purchasing those options needed. Typically, all DELTA
receivers ship with a temporary OAF that allows the receiver to be used for a predetermined period of
time. When the receiver is purchased, a new OAF activates desired, purchased options permanently.
Receiver options remain intact when clearing the NVRAM or resetting the receiver. The OAF enables the
following kinds of functions. For a complete list of available options and details, visit the JAVAD GNSS
website (http://www.javad.com) or consult your dealer.
Optional Features:
• Galileo E1/E5A (G2T, G3T, G3TAJT)
• Galileo E5B (G3T only)
• GLONASS L3 (G3T only)
• QZSS
• Compass B1
• Compass B2 (G3T only)
• WAAS/EGNOS/MSAS (SBAS)
• Update rate 5Hz, 10Hz, 20Hz, 50Hz & 100Hz
• RTK rate 1 Hz, 5Hz, 10Hz, 20Hz, 50Hz & 100Hz
• Data recording up to 2048MB
• Multi-Base Code Differential Rover
• Code Differential Base
