Javad DELTA Operator's Manual page 21

3. In the General tab set the parameter Antenna Input to External (Figure 1-7).
4. Open the TriPad tab and set the following parameters (Table 1-1), click Apply (Figure 1-8 on
page 22).
Parameter
Implicit Message
Output Period
Elevation mask angle
File name prefix
FN key mode
Initial dynamic mode
www.javad.com
Figure 1-7. General tab
Table 1-1. TriPad Settings
Base
15 seconds
15 degrees
Enter a unique ID, such as the last 3 digits of receiver's serial number. By deafault the
prefix is log
(starts/stops the data recording when FN button is used)
Select LED blink mode switch for Static data
-
Description and Operation
Establishing a USB Cable Connection
Rover
Select Occupation mode switch (for RTK)
Select Dynamic (for trajectory survey)
DELTA Configuration
21
