Figure 3-11-1 Connection of J4 expansion header
Figure 3-11-2 is the header of J4 on AX7102 board, the Pin1, Pin2 of connector
is marked on PCB board.
Pin Assignment of J4 Expansion Header.
J4 Pin
1
3
5
7
9
11
52 / 59
Figure 3-11-2 Header of J4 Onboard
FPGA Pin
GND
K14
H14
H15
G13
J21
AX7102 User Manual
J4 Pin FPGA Pin
2
4
6
8
10
12
Http://www.alinx.com.cn
+5V
K13
J14
J15
H13
J20
