bus. The flash device is N25Q128 which uses 3.3V CMOS signaling standard.
Because of its non-volatile property, it is usually used for storing software
binaries, images, sounds or other media. Detail information of QSPI FLASH is
shown in table 2-5-1 below.
Part
U8
Connections between FPGA and Flash are shown in Figure 2-5-1.
Figure 2-5-1 Connections between FPGA and Flash
Pin Assignment of FLASH：
Net Name
QSPI_CLK
QSPI_CS
QSPI_DQ0
QSPI_DQ1
QSPI_DQ2
QSPI_DQ3
18 / 59
P/N
N25Q128
Table 2-5-1 QSPI Flash Information
FPGA PIN Name
CCLK_0
IO_L6P_T0_FCS_B_14
IO_L1P_T0_D00_MOSI_14
IO_L1N_T0_D01_DIN_14
IO_L2P_T0_D02_14
IO_L2N_T0_D03_14
AX7102 User Manual
Capacity
128M Bit
FPGA P/N
Http://www.alinx.com.cn
Vender
Numonyx
L12
T19
P22
R22
P21
R21
