BASE ASSEMBLY

Step 1: Interlock all
Base block tabs as
shown above.
Step 3: Assemble base blocks as shown in the
Illustration of completed base with all tabs
locked and Base Holders installed. Approximately
20% of actual size.
Page 4
Step 2: Press Base Holder A and
Base Holder B pieces into the Base
blocks for a more secure hold.
Seaich Corporation, LLC. All rights reserved. www.seaich.com | Spacerails, LLC. www.spacerails.com
NOTE:
Please see the included
full size drawings for the
next several steps. This will
simplify the positioning of
base, arms, shafts, and the
rail cut lengths.
BACK OF BASE
RIGHT
LEFT
OF BASE
OF BASE
FRONT OF BASE
BASE ORIENTATION
