PREPARE COMPONENTS

A
Arms
Rotation Arm A: Attach 2 Arm
Holder B on each side of 1 Arm
Sheath, and insert 1 Arm Lock.
Rotation Arm B: Attach 1 Arm
Holder B and 1 Arm Holder A
to 1 Arm Sheath. Then insert 1
Arm Clip into Arm Holder A, and
attach 1 Arm Lock.
Rotation Arm C: Attach 1 Arm
Holder B and 1 Arm Holder A to
1 Arm Sheath. Then insert 1 Arm
Clip into Arm Holder A and attach
1 Arm Lock, and turn the lock
clockwise. Don't turn the lock too
tightly to avoid marring.
B

BASE ASSEMBLY

Seaich Corporation, LLC. All rights reserved. www.seaich.com | Spacerails, LLC. www.spacerails.com
Arm Holder B
Shaft Installation Side
Arm Holder B
Shaft Installation Side
Step 1: Interlock Base and Double
Base in the 3 configurations as
shown on the following page.
Arm Sheath
Arm Wrench
Arm
Arm Sheath
Arm Wrench
Step 2: Press Big Base Holders
and Small Base Holders onto the
base configurations as shown on
the following page.
Arm Holder B
Shaft Installation Side
Arm Holder A
Arm Installation Side
