BASE ASSEMBLY

Step 1: Interlock Base block tabs
as shown below.
E

SHAFT ASSEMBLY

A
264 mm
63 mm
Page 4
1
NOTE:
Illustration of Shafts are 1:2.3 or (approximately 43%) of scale.
B
159 mm
204 mm
Seaich Corporation, LLC. All rights reserved. www.seaich.com | Spacerails, LLC. www.spacerails.com
Step 2: Press Base Holder A and
2
Base Holder B pieces into the Base
blocks for a more secure hold.
2
C
261 mm
194 mm
101 mm
47 mm
D
240 mm
199 mm
129 mm
E
238 mm
