Connectors

This section describes connector functionality and provides information
about mating connectors. The connector locations are shown in
Figure 2-9.
Figure 2-9. Connector Locations

Connectors on the back of the board are noted with dotted lines.
ADSP-BF707 EZ-KIT Lite Evaluation System Manual
ADSP-BF707 EZ-KIT Lite Hardware Reference
2-21
