CAN1 Connector (J5)

Part Description
RJ11 vertical

JTAG/SWD/SWO Connector (P3)

The JTAG/SWD/SWO header (
processor. This is a 0.05" shrouded through-hole connector from SAM-
TEC (SHF-105-01-L-D-TH). This mates with ICE-1000, ICE-2000, and
any newer ADI emulators. For more information, see

TRACE and JTAG/SWD/SWO Connector (P2)

The TRACE and JTAG/SWD/SWO Connector (
ity to the microprocessor's trace interface. This is a MICTOR connector
from TYCO (2-5767004-2). There are no trace pods available at this
time. If one does become available,
installed to connect
ADSP-BF707 EZ-KIT Lite Evaluation System Manual
ADSP-BF707 EZ-KIT Lite Hardware Reference
Manufacturer
DIGIKEY
Mating Cable
RJ11 cable
) provides debug connectivity for the
P3
,
R162 R191
.
P2
Part Number
A31431-ND
Debug Interface.
) provides connectiv-
P2
, , and need to be
R192 R193
2-25
