TMCM-1290-EVAL Evaluation Board • Hardware Version V1.00 | Rev 0, 01/24

3 Hardware Information

All design les for TRINAMIC evaluation boards are available for free. The original ECAD les, Gerber data,
the BOM, and PDF copies are available. Typically, the ECAD les are in KiCAD format. Check the schemat-
ics for jumper settings and input/output connector descriptions.
Download the les from the
Note

3.1 Connectors

The TMCM-1290-EVAL has six on-board connectors. The following table contains information on the con-
nector type and mating connectors.
The connector pinning and signal names can be derived from the board design and schematic les avail-
able here: TRINAMIC TMCM-1290-EVAL homepage
# Connects to...
1 Power Supply
2 Motor
3 Encoder
4 Ref Switches
5 I/O
6 RS485,
7 UART
6 Brake
TRINAMIC evaluation boards home
To locate les or for other concerns, contact
Connector Type
METZ CONNECT 31330102
METZ CONNECT 31330103
Standard 5x 2.54mm
header
Standard 4x 2.54mm
header
Multipin connector,
2.54mm header
JST_PH_B2B-PH-
K_1x02_P2.00mm_Vertical
3x 2.54mm header
METZ CONNECT 31182102
Table 3: TMCM-1290-EVAL Connectors
page.
Customer
Description
Power supply to the evaluation board. Mating
connector: METZ CONNECT 31349102
Connects the motor to the TMCM-1290 output.
Mating connector:
Use to connect ABN encoder to board.
Use to connect reference switches to board.
14x Use to connect I/O to board.
CAN interface. Mating connector: JST PHR-
2 Crimp contacts: BPH-002T-P0.5S (0.5mm to
0.22mm)
Use to connect UART to board.
Use to connect a brake resistor or a motor
brake to the TMCM-1290. Mating connector:
METZ CONNECT 31169102
Service.
METZ CONNECT 31349103
6/18
