Ref. Qty. Description
22 1 FT232RQ
QFN50P500X500-33
NA
23 1 24MHZ OSC-
CC200X250
24 1 USB-MICRO 5PIN
HIROSE_ZX-
62D-AB-5P8
25 1 30A GSOT05
SOT23-3
26 2 RED LED_0603
27 3 YELLOW LED_0603 LED3-LED5
28 2 15KV ESDA5V3SC6
SOT95P280-6N
29 1 MIC2025-1 SOIC8
30 1 32.768KHZ
OSC_ABS07L
31 1 INA3221
QFN65P400X400-17
N
32 1 INA230
QFN50P300X300-17
N
33 5 IDC 2PIN_-
JUMPER_SHORT
34 1 PWR .65MM
CON045
35 1 150UF 10V 10% D
TANT-LOW-ESR
36 2 4700PF 16V 10%
0603 X7R
ADSP-BF707 EZ-KIT Lite Evaluation System Manual
ADSP-BF707 EZ-KIT Lite Bill Of Materials
Reference
Designator Manufacturer
U45 DIGI-KEY
U35 DIGI-KEY
P5 DIGI-KEY
D2 DIGI-KEY
LED1,LED6 DIGI-KEY
DIGI-KEY
D3,D4 DIGI-KEY
U40 DIGI-KEY
Y3 DIGI-KEY
U48 DIGI-KEY
U31 DIGI-KEY
SJ1-SJ5 DIGI-KEY
P13 DIGI-KEY
CT1 DIGI-KEY
C64,C72 DIGI-KEY
Part Number
768-1008-1-ND
478-4778-1-ND
H11494CT-ND
GSOT05-E3-08TR-ND
475-2512-2-ND
475-2558-1-ND
497-6633-1-ND
576-1057-ND
535-9542-2-ND
296-30459-1-ND
296-30346-2-ND
S9001-ND
CP1-023-ND
478-3321-2-ND
311-1083-2-ND
A-3
