Table 2-8. Output Signals of Microchip GPIO Expander
(U38 Port A)
Bit Signal Name Description
0 Enables
CAN0_TX_EN
1 Enables
CAN1_TX_EN
2 Enables
CAN0_RX_EN
3 Enables
CAN1_RX_EN
4 Enables
UART0_EN
5 Enables
UART0RTS_EN
ADSP-BF707 EZ-KIT Lite Evaluation System Manual
ADSP-BF707 EZ-KIT Lite Hardware Reference
FET/
SWITCH
CAN0 TX U10
CAN1 TX U7
CAN0 RX U11
CAN1 RX U8
UART0 U12/U13
UART0 RTS U51
Processor Signal Component
(if applicable) Connected
PC_03/UART0_CTS/ U46
CAN0_TX/
EPPI0_D12/
SMC0_A11/TM0_ACI0
PA_13/EPPI0_FS2/ U47
CAN1_TX/SMC0_ARE/
CNT0_ZM
PC_02/UART0_RTS/ U46
CAN0_RX/
EPPI0_D13/
SMC0_A10/
TM0_ACI5/
SYS_WAKE3
PA_12/EPPI0_FS1/ U47
CAN1_RX/SMC0_AOE/
TM0_ACI6/
SYS_WAKE4
PB_09/UART0_RX/ U45
EPPI0_D17/
SPI2_SEL3/
SMC0_D09/
TM0_ACI3 and
PB_08/UART0_TX/
EPPI0_D16/
SPI2_SEL2/
SMC0_D08/
SYS_WAKE1
PC_02/UART0_RTS/ U45
CAN0_RX/
EPPI0_D13/
SMC0_A10/
TM0_ACI5/
SYS_WAKE3
2-13
Default
High
Low
High
Low
Low
Low
