A ADSP-BF707 EZ-KIT LITE BILL
OF MATERIALS
The bill of materials corresponds to
Schematic.
Ref. Qty. Description
1 3 SMC THREADED
AMPHE-
NOL_152119
2 1 ADP5024
QFN50P400X400-25
N
3 1 ADM6315 SOT143
4 1 ADSP-BF707
BGA184C80P14X14_
1200X1200_SCKT
5 1 10UF 6.3V 10% 0805
X5R
6 43 0.1UF 10V 10% 0402
X5R
ADSP-BF707 EZ-KIT Lite Evaluation System Manual
ADSP-BF707 EZ-KIT Lite
Reference
Designator Manufacturer
J7-J9 AMPHENOL
CONN
VR1 ADI
U37 ADI
U1 ADI
C124 AVX
C1,C2,C5,C20-C22,C AVX
25,C26,C28-C32,C38,
C40-C42,C47,C49,C5
0,C54,C66-C68,C74-
C76,C78-C81,C95,C9
6,C125-C128,C142-C
144,C146,C148,C152
Part Number
152119
ADP5024ACPZ-R2
ADM6315-29D2ARTZR7
ADSP-BF707BBCZ-ENG
08056D106KAT2A
0402ZD104KAT2A
A-1
