Field Replaceable Units
FRU Removal and Replacement
Power Supply
Before removing the power supply, remove the Main
Tray Assembly.
1 Remove the option board support bracket by pushing in
Figure 45
Removing the Option Board Support Bracket
136
on the locking tab and sliding it toward the rear of the
main tray, as shown in Figure 45.
