Security Loop

The security loop provides a means of locking the
storage tray, with a padlock or other locking device, to
prevent unauthorized removal from the system.

Audio Connectors

Your workstation has audio input and output capability
through external input and output connectors on the
rear panel and through an internal speaker. The rear
panel contains the Audio IN (stereo line-in) and Audio
OUT (stereo line-out) connectors.
NOTICE: To maintain compliance with FCC/CISPR B you
must use fully shielded, unbalanced audio cables
and plugs.
The audio connectors are standard stereo audio mini-
jacks. Hewlett-Packard recommends using gold-plated
plugs available through audio retailers for best quality
recording and playback through the external connec-
tors. The following is a summary of the workstation
audio features:
•

System Unit Rear Panel Connectors

Audio Features
Programmable sample rates:
8kHz, 16kHz, 32kHz, 48kHz, 11.025kHz,
22.05kHz, and 44.1kHz.
Programmable output attenuation:
0 to -96dB in -1.5dB steps
Programmable input gain:
0 to 22.5dB in 1.5dB steps
Input monitoring:
16-bit linear, 8-bit u-law, or A-law coding
