HP Visualize b132L Service Handbook page 95

placed by the FRU
slot number where appropriate.
Code Name
8C05 PCI_PATH_ERR
8C06 PCI_BIST_TEST
test
8C07 PCI_BIST_ERR
8C08 PCI_ALLOC_ERR
ror
8C09 PCI_MEM_MANAGER_ERR
8C0A PCI_MEM_TYPE_ERR
1Mb
8C0B PCI_MAX_BUS_EXCEEDED
8C0C PCI_DEV_NOT_CONFIGURED
8C0D PDC_SYS_MAP_OVERFLOW
(during PCI bus walk)
8C0E SYS_PCI_MAP_OVERFLOW
8C0F PCI_INT_KLUDGE_WARN
for flawed labproto BP
For the following section of PCI-related chassis codes:
The "1" is the GSC bus number that DINO is at-
tached to.
Code Name
8C10 INIT_PCI
begins
8C11 TEST_PCI_COMPLETE
8C12 INIT_PCI_COMPLETE
DINO
8C13 PCI_NOT_FOUND
bus
8C14 PCI_TEST_ERR
8CCC OLD_PARISC_CODE_TYPE
ROM rev in PCI graphics
Code Name
9000 NO_SS_CONS
not found
9001 NO_CONS_FOUND
not found
Code Name
A088 NO_BOOT_NO_CONS
boot
A008 NO_BOOT_SELECTION
found
A00F RETRIEVE_PATH_FAILED
A0BD IODC_DEV_NOT_READY
8, device not ready
A0FF UNKNOWN_LAUNCH_FLT
A50F INIT_PRI_PATH_FAILED
A70F INIT_OTHR_PATH_FAILED
Code Name
C0FF CHASSIS_GSC_SLOT_WARNING Program GSC slot off-
sets to proper values
C200 RAM_CONFIG
uration
C201 BEG_DESTR_MEM_INIT
memory test
C202 BEG_NONDESTR_MEM_INIT
tive memory test
C20F RAM_CONFIG_FP
progress indicator
C210 MEM_RESET_HARD
C220 PHYSICAL_CONFIG
C230 BANK_SIZING
C240 CONFIG_FROM_EEPROM
C250 INTRLV_CONFIG
Troubleshooting
Selftest Failures
Meaning
PATH error - wrong HW ?
Start exec dev's BIST
Dev's BIST test failed
Resource allocation er-
Memory manager error
Dev wanted mem below
> max allowed bus depth
Dev not configured
PDC_SYS_MAP is full
SYS_PCI_MAP is full
Raven interrupt kludge
Meaning
DINO tests & PCI init
DINO tests completed
PCI init finished for
No DINO's found on GSC
A DINO test failed
Need to get a new STI
Meaning
Stable Storage console
Alternate console(s)
Meaning
No console, unable to
No bootable device
ENTRY_INIT returned -
Meaning
Starting memory config-
Starting detructive
Starting non-destruc-
RAM config forward
73
