- Page 2 Copyright © 1997 Intel Corporation. All rights reserved. Intel Corporation 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124-6497 Intel Corporation assumes no responsibility for errors or omissions in this guide, nor does Intel make any commitment to update the information herein.
- Page 3 The system control program (BIOS) in some computers doesn't support the higher speed of the Pentium OverDrive processor with MMX technology. You must update an incompatible BIOS before installing the processor. Failure to update your incompatible BIOS will cause your computer to lock up after installation.
- Page 4 Warning: Danger to equipment! The Pentium OverDrive processor with MMX technology can be damaged by static discharge. Before handling the Pentium OverDrive processor with MMX technology, be sure to ground yourself by touching the metal on your computer. Limiting your movements during installation reduces static electricity.
- Page 5 Step 4—Find the computer's Pentium processor. Find the Pentium processor in the computer. The Pentium processor in most computers looks like the following: Pentium processor PC-3785 Some computers have a power cable attached to the Pentium processor's fan or have a passive heat sink (which may be attached with a clip) on top of the Pentium processor .
- Page 6 (with handle) Handle If the socket in your computer doesn't have a handle, Intel strongly recommends that you have a qualified professional install the Pentium OverDrive processor with MMX technology rather than installing it yourself. Some computers use a socket without a handle, called a low insertion force (LIF) socket.
- Page 7 6 now. You do not need the fan, fan cable, or clip to install the Pentium OverDrive processor with MMX technology. After removing these parts, store them with your original processor.
- Page 8 Removing the heat sink clip If the heat sink is clipped to the socket, remove the clip by pressing down and unfastening it from the tab on the socket. Be sure to hold your hand over the clip while unfastening it to prevent it from flying loose. Heat sink clip Heat sink surrounds fan and...
- Page 9 Some manufacturers use thermal grease to attach the heat sink to the processor. Thermal grease is a conductive material and can damage your computer if it gets on socket pin holes, processor pins, or other components. Avoid getting thermal grease residue on your hands or the computer when you remove the heat sink from the processor.
- Page 10 Correctly orienting your Pentium OverDrive processor with MMX technology in the socket is crucial to the success of your installation. The Pentium OverDrive processor with MMX technology fits in the socket only one way. Incorrectly aligning your Pentium OverDrive processor with MMX technology can damage the processor and your computer.
- Page 11 Step 8—Close the socket handle. Close the socket handle to lock the OverDrive processor with MMX technology in place. Once it is locked in place, the OverDrive processor with MMX technology should fit snugly in the socket. Step 9—Replace the cover, plug in the computer, and turn it on.
- Page 12 If you don't see increased performance, or if you have difficulty getting the computer to run successfully, see the "Troubleshooting" section to determine possible problems. If you still need help, contact your dealer. Installation of your Intel Pentium OverDrive processor with MMX technology is complete.
-
Page 13: Troubleshooting
• The cables and cords are attached correctly. • Any cards you removed are reinstalled properly. • The Pentium OverDrive processor with MMX technology and the socket are correctly aligned. • Did you set the jumpers or system switches correctly, as described in your computer owner's manual? For further information on jumpers and switches, see page 20. - Page 14 PC-3787 Motherboard with two processor sockets The Pentium OverDrive processor with MMX technology feels hot. • It is normal for the Pentium OverDrive processor with MMX technology to generate heat while operating. Caution: After operating for several hours, many chips...
- Page 15 Your computer powers on and runs normally for a few minutes then hangs up or shuts down. • Is the Pentium OverDrive processor with MMX technology socket handle fully locked? • Is the Pentium OverDrive processor with MMX technology fully inserted? •...
- Page 16 BIOS update needed Here's what to do when the Intel diagnostic tells you to update your computer's BIOS before installing the OverDrive processor with MMX technology. 1. Collect this information: BIOS serial number. The BIOS serial number is usually displayed on the initial power-on screen.
- Page 17 The BIOS in many older computers cannot identify the Pentium OverDrive processor with MMX technology; however, those systems might still operate correctly with the new processor. If the processor passes the Intel diagnostic program and the system seems to be operating correctly with...
- Page 18 Your Pentium OverDrive processor with MMX technology fan is not working. • Is the fan fully seated? The Pentium OverDrive processor with MMX technology fan is powered from three power connections on the processor top. To ensure your fan is fully seated: 1.
- Page 19 Pentium OverDrive processor with MMX technology are the same. In some cases, however, you may need to specifically configure your system for a Pentium OverDrive processor with MMX technology. Your computer's owner's manual or your computer manufacturer should have the correct settings for your computer.
- Page 20 Intel Customer Support on the World Wide Web Intel Customer Support FaxBack* Service Intel Customer Support Technicians U.S. and Canada 1-800-321-4044 07:00-17:00 Swindon, UK English +44-1793-404-900 08:00-24:00 French +44-1793-404-988 08:00-17:00 German +44-1793-404-777 08:00-17:00 (Tuesday 08:00-16:00) Italian +44-1793-404-141 08:00-17:00 (Tuesday 08:00-16:00)
- Page 21 Intel is unable to repair or replace the OverDrive processor, REFUND the then-current value of the OverDrive processor. Intel does not warrant that your OverDrive processor will be free from design defects or errors known as "errata." Current characterized errata for Pentium OverDrive processors are available upon request.
