Configuring the Monitor Location

To ensure the most efficient and useful results for each monitor
location, the user must activate the TRITON+ flow monitor with
the proper configuration information to satisfy the specific
monitoring needs of the project and to reflect actual site conditions.
The configuration information includes critical details such as the
monitor name, series, pipe size and shape, sensor assignment and
parameters, and data sample rate.
Users input the configuration details for each monitor into
XML
Qstart
information file (XML) on the user's local directory or network
drive. After the monitor configuration process is completed, users
must then perform a monitor activation to download the specific
elements of the XML to the monitor memory in order to initiate
monitor operations. Following is the general process for creating a
new monitor location.
Create and configure a monitor location in Qstart
Configure the monitoring point(s) for the monitor location
Select and edit devices for the monitor location
Note: If remote communication already has been
established for the location, these activities can be
performed in cooperation between field and office
personnel. If remote communication is not available,
perform configuration and activation on site through direct
communication with the monitor.

Create and Configure the Monitor Location

Entering the monitor information is the first step to creating a new
monitor location. The following steps describe the process for
entering the information and designating the parameters for an
existing location:
Configuration and Activation
. The configuration details for each are stored in an
4-7
XML
