ADS TRITON+ Installation, Operation And Maintenance Manual

Table of Contents

Quick Links

ADS Intrinsically-Safe TRITON+

Installation, Operation, and

Maintenance Manual

July 2022

QR 775027 A15

340 The Bridge Street, Suite 204

Huntsville, Alabama 35806

(256) 430-3366

www.adsenv.com

Table of Contents

Troubleshooting

Need help?

Do you have a question about the TRITON+ and is the answer not in the manual?

Questions and answers

Summary of Contents for ADS TRITON+

Page 1 ® ADS Intrinsically-Safe TRITON+ Installation, Operation, and Maintenance Manual July 2022 QR 775027 A15 340 The Bridge Street, Suite 204 Huntsville, Alabama 35806 (256) 430-3366 www.adsenv.com...
Page 2 Notice of Proprietary Information The information contained herein represents the latest information available at the time of publication. ADS LLC reserves the right to make any changes or modifications to the content of this document, without notice, to reflect the latest changes to the equipment. No...
Page 3 Table of Contents part of this document may be reproduced in any form without the written consent of ADS LLC.
Page 4: Table Of Contents
ADS TRITON+ Manual Table of Contents C H A P T E R 1 Introduction ..... 1-1 Intrinsic Safety ............... 1-2 TRITON+ System Certification ......1-3 Installation and IS Considerations ......1-6 Specific Conditions of Use........1-6 Other Conditions for Safe Use ........ 1-8 Maintenance Restrictions ..........
Page 5 Table of Contents Ultrasonic Depth Sensor ........2-30 Surface Combo Sensor .......... 2-31 Inclinometer Sensor ..........2-34 I/O and Modbus Capability .......... 2-35 Analog Inputs and Outputs........2-35 Digital Inputs and Outputs ........2-36 Modbus ..............2-36 Project Organization Checklist ........2-37 C H A P T E R 3 Communication ....
Page 6 ADS TRITON+ Manual Upgrading the Monitor Firmware ......4-103 Viewing Diagnostic and Data Logs......4-104 C H A P T E R 5 Sensor Installation and Connection ..... 5-1 Investigating Site Characteristics ........5-4 Flow Hydraulics ............5-4 Pipe and Manhole Characteristics ......5-5 Installing the Sensors in the Pipe ........
Page 7 Table of Contents C H A P T E R 8 Inclinometer ..... 8-1 Installing the Inclinometer ........8-2 Inclinometer Data ............ 8-6 C H A P T E R 9 Analog and Digital Inputs and Outputs ..... 9-1 Analog Inputs ..............9-3 Connecting a Third-Party Instrument to an Analog Input on the XIO .............
Page 8 Temperature Subsystem ........11-69 External Power, I/O, and Modbus Subsystems ... 11-71 A P P E N D I X A Specifications ....A-1 TRITON+ Flow Monitor (ADS p/n 8000-FST-IM) A-1 Intrinsically-Safe Sensors ........A-6 USB Serial Interface (ADS p/n 8000-0337)..A-20 ExPAC (ADS p/n 8000-0377) ......
Page 9: Chapter 1 Introduction
C H A P T E R 1 Introduction ® The Intrinsically-Safe ADS TRITON+ flow monitor measures open channel flow in sanitary sewers, storm sewers, combined sewers, and other environments to assist municipalities and other industry in addressing the following issues:...
Page 10: Intrinsic Safety
1-2 ADS TRITON+ Manual Intrinsic Safety Intrinsic safety is an electronic hardware protection concept that ensures there are no conditions under which the equipment can operate that could cause a release of energy sufficient to ignite a hazardous gas or dust mixture. Devices that meet the low power, current-limited design criteria are deemed Intrinsically Safe (IS).
Page 11: Triton+ System Certification
FST-IM-GL, and 8000-FST-IM-EP-GL. TRITON+ System Certification The TRITON+ unit and associated telemetry equipment are certified for use only with approved ADS battery packs, sensors, communication cables, and telemetry equipment. Connection of any non-approved devices could result in unsafe operation and will immediately void the warranty and IS certification.
Page 12 (or crown) of the pipe above the flow (ADS p/n 8K-CS8-D1-00- 30-IS). It can also be mounted in the manhole using the ADS Topside Retrieval System (ADS p/n 8000-0597, 8000-0598, 8000-0654).
Page 13 Appendix A, Specifications Power The TRITON+ flow monitor is powered by an internal 12-volt IS battery pack (ADS p/n 8000-0043) or an external DC power source through an external power and communications unit (ExPAC, ADS p/n 8000-0377), external Modbus interface unit (XBUS ™...
Page 14: Installation And Is Considerations
1-6 ADS TRITON+ Manual ADS’ 9000-0080 antenna is the recommended antenna for use with the TRITON+ monitor. Customers also may obtain their own antennas to accommodate specific project needs or requirements. However, when assessing a third-party antenna, please consult an ADS representative prior to installing the antenna to verify the antenna can adequately support monitor communications.
Page 15 USB Serial Interface to an appropriately low level, in accordance with Overvoltage Category I (IEC 60664-1). This equipment (ADS Model 8000-FST-IM) shall only be used in the hazardous area when it has been fully assembled; no maintenance of internal parts or battery changes shall be undertaken unless the unit is located in a safe area.
Page 16: Other Conditions For Safe Use
4 mm , to achieve a resistance ≤1 Ω. Other Conditions for Safe Use The ADS Model 8000-FST-IM shall use only the 12-volt IS Battery Pack (ADS p/n 8000-0043) for internal power. Only ADS-approved sensors shall be connected to the ADS Model 8000-FST-IM: ADS sensor types CSX series.
Page 17: Maintenance Restrictions
XBUS or XIO), XBUS, or XIO Cleaning sensors Confirming sensors Note: Please note that, in all applications, only ADS IS- certified Service Technicians are authorized to perform component-level service on the TRITON+. If you have any questions about the procedures, warranty...
Page 18: Warnings, Certifications, Cellular Modem Compliance, And Conformity
1-10 ADS TRITON+ Manual Warnings, Certifications, Cellular Modem Compliance, and Conformity Manhole and sewer system work involves confined space entry and is inherently dangerous. Therefore, installers and technicians should comply with all federal, state, and municipal regulations concerning confined space entry.
Page 19: Control Drawing
Introduction 1-11 Control Drawing This drawing depicts the interconnections allowed for the TRITON+. It is intended for use by inspection professionals for audit certificate compliance; however, it is a good tool for understanding the structure of the TRITON+ flow monitoring system.
Page 20 1-12 ADS TRITON+ Manual Control Drawing...
Page 21: European Atex Hazardous Area Compliance
Note: This is an excerpt from an agency-controlled document for illustration purposes only. Changes to the base controlled document require agency approval. For a full-size copy of this drawing, please contact ADS and request drawing number 8000BK0009-CERT. Note: The Telog Ru-33 and Ru-35 can be connected to...
Page 22 1-14 ADS TRITON+ Manual The equipment may be used with flammable gases and vapors with apparatus groups IIA and IIB and with temperature classes T3 (152 C), T4, T5, and T6. The equipment is only certified for use in ambient temperatures...
Page 23 Introduction 1-15 TRITON+ ATEX, IECEx, CSA, UKCA Certification Label Combo Sensor ATEX, IECEx, CSA, UKCA CSX Series Certification Label...
Page 24 1-16 ADS TRITON+ Manual Long Range Depth (CS6) ATEX, IECEx, CSA, UKCA Certification Label Inclinometer ATEX, IECEx, CSA, UKCA Certification Label Sampler Cable ATEX, IECEx, CSA, UKCA Certification Label...
Page 25 Introduction 1-17 USB Serial Interface ATEX, IECEx, CSA, UKCA Certification Label ExPAC ATEX, IECEx, CSA, UKCA Certification Label Direct Connect Interface Cable ATEX, IECEx, CSA, UKCA Certification Label...
Page 26: Iecex (International Electrotechnical Commission Explosive) Hazardous Area Compliance
1-18 ADS TRITON+ Manual Battery ATEX, IECEx, CSA, UKCA Certification Label EC Type Examination Certificate Sira 09ATEX2027X can also be used to substantiate conformance to applicable EU laws for IS equipment. Note: To access the latest version of the certificate, please contact ADS.
Page 27 Introduction 1-19 CS6 (LRD Sensor) Certificate of Conformity...
Page 28: Csa Hazardous Area Compliance
The following CSA certificate can also be used to substantiate conformance to applicable Canadian standards for IS equipment: Note: The certificate displayed on the following pages was current at the time of publication of this manual. To access the latest certificates, please contact ADS.
Page 29 Introduction 1-21 CSA Certificate of Compliance Page 1 of 7...
Page 30 1-22 ADS TRITON+ Manual CSA Certificate of Compliance – Page 2 of 7...
Page 31 Introduction 1-23 CSA Certificate of Compliance – Page 3 of 7...
Page 32 1-24 ADS TRITON+ Manual CSA Certificate of Compliance – Page 4 of 7...
Page 33 Introduction 1-25 CSA Certificate of Compliance – Page 5 of 7...
Page 34 1-26 ADS TRITON+ Manual CSA Certificate of Compliance – Page 6 of 7...
Page 35 Introduction 1-27 CSA Certificate of Compliance – Page 7 of 7...
Page 36: Declaration Of Conformity
A copy of the relevant DoC also must be shipped with each product. If you have any questions about the DoC, please contact ADS LLC by telephone at 1-877-237-9585 or email at adssupportcenter@idexcorp.com.
Page 37 Introduction 1-29 Sample TRITON+ Declaration of Conformity – Page 2...
Page 38: Product Warranty
TRITON+ flow monitor. New Product Warranty All new products manufactured by ADS will be free from defects in material and workmanship for up to one (1) year following the delivery date to the customer with one exception; the Long Range Depth Sensor is under warranty for up to two (2) years.
Page 39: Troubleshooting Fee
Shipping All repaired products will be returned via transportation prepaid by ADS. Import duties, fees, taxes, and other related charges are the responsibility of the owner. THIS IS THE ONLY WARRANTY FOR ADS PRODUCTS. NO...
Page 40: Service
1-32 ADS TRITON+ Manual Service For service or warranty issues, please contact ADS customer support: Telephone: 1-877-237-9585 Email: adssupportcenter@idexcorp.com.
Page 41: Chapter 2 System Overview
C H A P T E R 2 System Overview ® The ADS TRITON+ flow monitor supports nine (9) flow measurement devices for gathering flow data: AV|Gated Sensor This sensor, which mounts at the bottom of the pipe, contains an upward-looking ultrasonic depth sensor, a...
Page 42 2-2 ADS TRITON+ Manual ParaDepth Sensor This sensor can be mounted at the crown (top) of the pipe or in the manhole structure using the ADS Topside Retrieval System. It contains a downward looking ultrasonic depth sensor and air temperature sensor. It differs from the standard...
Page 43 System Overview information that can assist municipalities and other industries in planning improvements and additions to sewer systems, improving the accuracy of billing information, and providing overall management of sewer systems. The TRITON+ monitor and sensors are primarily designed for monitoring flow in sanitary and storm sewers.
Page 44 RTU (remote terminal unit) or another comparable instrument. The XIO also serves as an analog and digital I/O (input/output) interface that can support non-ADS sensors, switches, and various third-party equipment. The ADS Qstart software application enables the user to configure and communicate with the monitor for activation, data collection, and diagnostic purposes.
Page 45: Triton+ Flow Monitor
IS 12 VOLT BATTERY Exploded view of TRITON+ (processor board resides between the monitor top and protective regulator dome) Communications ADS offers remote (wireless) and on-site (direct) communication options for the TRITON+ monitor. Wireless Communication Wireless communication occurs over the 3G/4G UMTS/HSPA+ ®...
Page 46: Processor Board
Direct Communication On-site (or direct) communication with all monitors is available through an IS USB serial interface (direct connect) cable (ADS p/n 8000-0337) for battery-powered units or through a standard A-to-B USB cable when using external power.
Page 47 System Overview Storing the parameters required to accomplish the associated system operations Transmitting the stored and current data to the user's PC or FTP site Outputting a discrete signal pulse to a water quality sampler Displaying system power and operational status and diagnostic codes Initiating event notification through alarms Transmits readings and signals through analog and digital outputs...
Page 48: Connector Ports
2-8 ADS TRITON+ Manual Connector Ports Monitor top with sensor and communication/power/sampler connector ports (no SIM card enclosure) (ADS Model 8000-FST-IM-4WW-ATT)
Page 49 System Overview Monitor top with sensor and communication/power/sampler connector ports (no SIM card enclosure) (ADS Model 8000-FST-IM-4WW-VZW) The connector ports located on top of the monitor can receive up to two sensors, a communication device and/or power cable, and an...
Page 50 2-10 ADS TRITON+ Manual CHANNEL 1 and CHANNEL 2 Ports These ports can receive up to two of the following sensors: AV|Gated sensor AV|Max sensor Long Range Depth sensor ParaDepth sensor ParaFlow sensor Peak Combo sensor Surface Combo sensor Ultrasonic Depth sensor...
Page 51: Power
Internal Power Power is supplied to the TRITON+ flow monitor by an internal 12- volt IS battery pack (ADS p/n 8000-0043-02/04). The battery pack resides within the TRITON+ enclosure and powers monitor operations. A battery fuse board is attached to the battery pack to achieve intrinsic safety.
Page 52 (ExPAC, ADS p/n 8000-0377), external Modbus interface unit (XBUS, ADS p/n 8000-0427), or external input/output device (XIO, ADS p/n 8000-0400) located outside the manhole near the power source. These units regulate the power coming to the monitor and can provide Modbus (ExPAC or XBUS) and analog and digital input and output interfaces (XIO) between the monitor and third-party equipment.
Page 53 System Overview 2-13 ExPAC XBUS...
Page 54 AC power must first come through a power supply for DC conversion prior to entering the ExPAC. ADS recommends using a 24-VDC module (ADS, p/n 508293). DC power can come directly from the power supply, a solar source, or rechargeable battery to the ExPAC.
Page 55: Sensors
If the purpose of the installation is to monitor for manhole surcharging or overflow, and not accurate flow-rate, the sensor can be mounted in the manhole structure. ADS recommends using the Long Range Depth sensor for this application.
Page 56: Av|Gated Sensor
2-16 ADS TRITON+ Manual AV|Gated Sensor The AV|Gated sensor (ADS p/n 8K-CS7-10-35) mounts at the bottom center of the pipe and measures ultrasonic depth, average velocity, pressure depth, and water temperature. The sensor leverages dual depth technology and provides ultrasonic depth measurements to full pipe and pressure depth measurements during surcharge conditions.
Page 57 System Overview 2-17 Ultrasonic Depth Sensor The AV|Gated sensor leverages dual depth technology and provides ultrasonic depth measurements to full pipe and pressure depth measurements during surcharge conditions. To provide the depth of the flow, the sensor sends an ultrasonic signal upward that bounces off the water surface –...
Page 58: Av|Max Sensor
0 - 10 PSI (0 - 0.68 Bar). AV|Max Sensor The AV|Max sensor with a standard 35-foot (10.6 m) (ADS p/n 8K- CS9-10-35) mounts at the bottom center of the pipe and measures ultrasonic depth, peak velocity, pressure depth, and water temperature.
Page 59 System Overview 2-19 The AV|Max sensor measures peak velocity by sending an ultrasonic signal at an angle up through the velocity layers in the oncoming flow. It emits a wide, omni-directional sound wave at a specific frequency upward into the flow. The sound wave bounces off particles in the flow and returns to the sensor.
Page 60: Long Range Depth Sensor
The pressure transducers used in the AV|Max sensor is a 0 - 10 PSI (0 - 0.68 Bar). Long Range Depth Sensor The Long Range Depth sensor (ADS p/n 8K-CS6-C1-10) with a standard adjustable Mounting Bar (ADS p/n 8000-0450) attaches beneath the manhole cover and measures ultrasonic depth.
Page 61 System Overview 2-21 Long Range Depth Sensor This sensor has an ultrasonic transducer with a glass reinforced epoxy acoustic window and is located inside the integral parabolic reflector. It first transmits an ultrasonic signal horizontally from the transducer to the optimized reflector, focusing a very narrow beam downwards.
Page 62: Paradepth Sensor
The ParaDepth sensor with a standard 30-foot (9.1-m) cable (ADS p/n 8K-CS8-D1-00-30-IS) mounts at the crown of the pipe and measures ultrasonic depth and air temperature (Patent Number: 10648847). It can also be mounted in the manhole using the ADS Topside Retrieval System.
Page 63 System Overview 2-23 ParaDepth Sensor The ultrasonic depth sensor is located in the parabolic reflector of the sensor body. This sensor transmits an ultrasonic signal horizontally from the transducer that is reflected off the parabolic mirror vertically towards the surface of the flow and returns along the same path.
Page 64: Paraflow Sensor
ParaDepth sensor sending signals to flow surface to determine range ParaFlow Sensor The ParaFlow sensor with a standard 30-foot (9.1-m) cable (ADS p/n 8K-CS8-V2-10 -30-IS) mounts at the top of the pipe. It can also be mounted in the manhole using the ADS Topside Retrieval System.
Page 65 System Overview 2-25 ParaFlow Sensor Ultrasonic Depth Sensor The Ultrasonic Depth sensor is located in the front parabolic reflector of the sensor body. It transmits an ultrasonic signal horizontally from the transducer that is reflected off the parabolic mirror vertically towards the surface of the flow and returns along the same path.
Page 66 (0.3 m/s). It is also recommended that the ParaFlow Sensor be installed in the manhole structure when pipe diameters are less than or equal to 10” (254 mm). Use an ADS Topside Bracket System for an in-manhole installation of the ParaFlow...
Page 67: Peak Combo Sensor
ParaFlow Sensor supports pressure measurement of 0 - 10 PSI (0 - 0.68 Bar. Peak Combo Sensor The Peak Combo Sensor with a standard 35-foot (10.6-m) or 100- foot (30.5-m) cable (ADS p/n 8K-CS4-XX-35/1H) typically mounts at the bottom of the pipe and measures ultrasonic depth, pressure...
Page 68 2-28 ADS TRITON+ Manual depth, peak velocity and water temperature using four independent sensors. Peak Combo Sensor Ultrasonic Depth Sensor To provide the depth of the flow, the sensor sends an ultrasonic signal upward that bounces off the water surface – air interface.
Page 69 System Overview 2-29 board and the value is sent to the monitor processor board. A vent tube on the back of the diaphragm equalizes for atmospheric pressure. Three versions of pressure transducers are available with this combo sensor: 0 - 5 PSI (0 - 0.34 Bar), 0 - 15 PSI (0 - 1.03 Bar), and 0 - 30 PSI (0 - 2.07 Bar).
Page 70: Ultrasonic Depth Sensor
Ultrasonic Depth Sensor The Ultrasonic Depth Sensor with a standard 30-foot (9.1-m) cable (ADS p/n 8K-CS5-D1-00-30) mounts at the crown of the pipe and measures ultrasonic depth and air temperature. Ultrasonic Depth Sensor This sensor first transmits an ultrasonic signal downward from one of the crystals on the sensor face that bounces off the flow surface and returns to the other crystal.
Page 71: Surface Combo Sensor
Surface Combo Sensor The Surface Combo sensor with a standard 30-foot (9.1-m) cable (ADS p/n 8K-CS5-V2-XX-30/1H) mounts at the top of the pipe and measures ultrasonic depth, surcharge pressure depth, surface velocity, surcharge peak velocity and air temperature using five (5)
Page 72 2-32 ADS TRITON+ Manual Surface Combo Sensor Ultrasonic Depth Sensor This sensor first transmits an ultrasonic signal downward from one of the crystals on the sensor face that bounces off the flow surface and returns to the other crystal. The monitor measures the travel time elapsed between transmission and reception of the reflected sound signal.
Page 73 The surface velocity sensor crystals reside in the two descended portions toward the rear end of the sensor. ADS does not recommend using this sensor for measuring velocity at locations with smooth flow surfaces or velocities of less than 1 foot per second (0.3 m/s).
Page 74: Inclinometer Sensor
2-34 ADS TRITON+ Manual Surcharge Pressure Depth Sensor The surcharge pressure depth sensor in the Surface Combo sensor measures pressure depth using the same technique as the other combo sensors, except from the top of the pipe. Since it can provide an accurate depth only when submerged, the data from this sensor is useful only under full-pipe or surcharge conditions.
Page 75: I/O And Modbus Capability
I/O and Modbus Capability The TRITON+ supports several different inputs and outputs through the ADS XIO interface unit. The monitor facilitates Modbus communications through the ADS ExPAC or ADS XBUS. Inside of XIO showing I/O terminal block, power supply, and ExPAC...
Page 76: Digital Inputs And Outputs
It often is used to connect a supervisory computer with a remote terminal unit (RTU) in supervisory control and data acquisition (SCADA) systems. ADS uses Modbus to provide information directly to RTUs or SCADA systems. The ExPAC represents the interface through which Modbus...
Page 77: Project Organization Checklist
System Overview 2-37 Project Organization Checklist In order to set up the TRITON+ monitor to successfully communicate and record flow information, the following steps must be performed. Refer to the chapters identified for more detailed information. Perform these steps prior to the field installation: Activate the SIM card and get the IP address (TRITON+ 8000- FST-IM-4WW-ATT, FST-IM-EP-4WW-ATT, 8000-FST-IM- 4WW-VZW, 8000-FST-IM-EP-4WW-VZW) (Refer to Chapter3,...
Page 78: Chapter 3 Communication
C H A P T E R 3 Communication All methods of communication with the TRITON+ require a field (laptop) computer or office computer equipped with the ADS Qstart software. Wireless, remote communication occurs through a wireless antenna and an internal modem housed inside the monitor.
Page 79 ADS is not responsible for any injuries, damages, claims, or liability resulting directly or indirectly from the use of this installation guide or the installation of any ADS equipment. Warning: The TRITON+’s internal modem requires connection to an external antenna.
Page 80: Cellular-Based Wireless Communication Overview
® Verizon network services, ADS p/n 8000-FST-IM-4VZ or 8000- FST-IM-EP-4VZ) or the WorldWide 4G LTE-M modem, ADS p/n 8000-FST-IM-4WW (ATT or VZW) or 8000-FST-IM-EP-4WW (ATT or VZW) using static or dynamic IP address network services. Any location considered for wireless communication...
Page 81 Currently, dynamic IPs may be used only for uploading data wirelessly from the monitor to an FTP site or an ADS Web-based software database. Communicating directly through ADS software to set up and activate monitors equipped with dynamic IPs must occur over a direct connection using the ADS USB Serial Interface cable (ADS p/n 8000-0337).
Page 82: Activating The Sim Card
Use the following to activate the SIM card: (applicable only to global 3G wireless monitors) Order an AT&T SIM card with public or private static IP address (ADS p/n 8000-0560-ASIM) or ADS Verizon SIM card with private, static IP address (ADS p/n 8000-0561-VSIM). Once received, install the SIM card in the SIM Card Holder.
Page 83 ADS TRITON+ Manual Wait for a return email from ADS. The email will contain the IP address of the SIM card and its associated phone number. Using a permanent marker, write the IP address and its associated phone number on empty space on the card and save the card for future reference, as needed.
Page 84: Installing The Antenna
Communication Installing the Antenna Establishing remote, wireless communications with a TRITON+ monitor containing an internal modem involves installing a wireless antenna and connecting the antenna to the monitor. Depending on the TRITON+ monitor’s wireless signal strength at the install site, the antenna may be installed inside or outside the manhole.
Page 85 Tools and Equipment for Outside-of-the- Manhole Antenna Installation Obtain the following items for an outside-of-the-manhole antenna installation: ADS wireless antenna (p/n 9000-0094 or 0096) or a customer- supplied antenna verified by ADS for successful monitor communications Extension cables (16-foot (4.9-m): ADS p/n 509154; 49-foot (14.9-m): ADS p/n 509155) for antenna, as needed...
Page 86 Cable ties for securing cable coils Generator or other power source (for hammer drill) Dry sand Commercial asphalt cold patch compound (approximately 1 cup) Scotch-kote electrical sealing compound (ADS p/n 505171) Scotch 130C rubber stretch tape (ADS p/n 145-0001)
Page 87: Installing The Wireless Antenna
Use a cable tie to secure the antenna to a manhole rung or monitor mounting bracket, if available. Position the antenna as flat and parallel to the manhole lid as possible with the ADS logo facing upwards. If no manhole rung or mounting bracket exists in the manhole, install an L-bracket (using a lag bolt) to the manhole wall just below the manhole rim and secure the antenna to the L-bracket.
Page 88 These installation instructions are applicable for installing the antenna in the road, ground, or under other paving materials. ADS TRITON+ Antenna Install a wireless antenna in the road, in the dirt, or under other paving materials in the following way:...
Page 89 3-12 ADS TRITON+ Manual through ADS also include detailed installation instructions. Determine the appropriate location in the road near the manhole to install the antenna: Locate the antenna in the road between 18 and 30 inches (457 and 762 mm) from the manhole in which the monitor is installed.
Page 90 Communication 3-13 the (mastic covered version) antenna. The corbel hole should be at the end closest to the manhole cover. Drill a hole in the end of the cut closest to the manhole cover through the corbel, and into the manhole using the ½-inch (13- mm) by 36-inch (914-mm) hammer drill bit.
Page 91 The sand must be used to ensure the asphalt does not adhere to objects, such as vehicle tires, while drying. ADS recommends dusting the surface with sand once again before leaving the site.
Page 92 Communication 3-15 ANTENNA ANTENNA CABLE CABLE CHANNEL CORBEL TRITON+ MONITOR ULTRASONIC DEPTH SENSOR SURFACE COMBO SENSOR INSTALLATION RING FLOW PEAK COMBO SENSOR Installation with Antenna Cable Coiled in Manhole 11. Seal the space between the antenna cable and the corbel hole with electrical duct seal or as required to prevent infiltration into the manhole.
Page 93: Installing (Replacing) The Sim Card
Regulator/Modem bowl (or on older models of the 8000-FST-IM- 4WW monitors, a SIM card enclosure on top of the monitor canister). If a SIM card not supplied by ADS is to be used, the installed SIM card will need to be removed. The section below refers to replacing the SIM card in the Regulator/Modem bowl.
Page 94 SIM card from these monitors prior to contacting ADS Customer Support. Replacing the SIM Card in Regular/Modem Bowl Note: The only service or maintenance activities ADS permits within the monitor chassis are battery pack, battery PCB, regulator/modem unit, SIM card replacement (as applicable) and fuse replacement.
Page 95 3-18 ADS TRITON+ Manual Brush off the monitor enclosure and remove the 4 bolts securing the top to the canister using a 13-mm nut driver. Note: Make a note of the orientation of the monitor top to the canister before removing the bolts. Keeping proper orientation between the canister and the top is critical to maintaining the water and airtight seal on the monitor.
Page 96 Communication 3-19 Remove the brass thumb nut securing the dome to the monitor top. Dome-securing Nut Removing nut securing regulator dome to monitor top Carefully lift off the dome from the top (as if opening like a book). The SIM card holder in the enclosure functions based on spring action.
Page 97: Connecting The Antenna To The Monitor
Connecting the Antenna to the Monitor Note: ADS recommends installing the antenna prior to connecting the antenna to the monitor. Connect the antenna to the monitor in the following way:...
Page 98 Communication 3-21 Wrap rubber stretch tape around the entire cable connection, extending onto the cable approximately 2 inches (50 mm) beyond the connection with the antenna cable. ANTENNA CABLE COAXIAL STRETCH TAPE ANTENNA PORT TRITON+ MONITOR Antenna Cable Connected to Antenna Port on Monitor with Stretch Tape Properly Applied Carefully coil and secure the remaining slack antenna cabling as necessary.
Page 99: Connecting To The Monitor In The Field
ADS TRITON+ Manual Connecting to the Monitor in the Field ADS offers two methods for communicating with the monitor on- site or in the field: direct connection or indirect connection. Direct connection allows you to connect directly to the TRITON+ with a laptop (or office) computer for on-site communications.
Page 100: Connecting Directly To The Monitor
ExPAC/XBUS /XIO in these applications. Before you can communicate with the monitor through your computer using the ADS USB Serial Interface cable or a standard USB cable, you must install a special driver on your computer. The instructions for installing the driver are printed on the label on the bottom of the cable’s interface box or on the top, left side of the...
Page 101: Connecting To The Monitor Through The Expac
3-24 ADS TRITON+ Manual Connecting the USB Serial Interface Cable to a Laptop and Monitor Note: When using the optional extension cable (ADS p/n 8000-0044-25), run it between the monitor and the USB Serial Interface cable. Designate the appropriate local USB port on the computer for communication through the Qstart software.
Page 102 Communication 3-25 Connecting the Standard USB Cable to a Laptop and ExPAC Designate the appropriate local USB port on the computer for communication through the Qstart software. For more information, refer to the Qstart online help.
Page 103: Chapter 4 Configuration And Activation
In order to get the monitor to begin taking flow measurements and recording flow data, it is necessary to configure and activate the monitor. NOTE: ADS recommends that the initial configuration and activation of the TRITON+ occur in the office prior to the field installation. Refer to Chapter 2, Project Organization Checklist, for more information.
Page 104: Hardware And Software Compatibility
Once installed, start the Qstart software from an office or field computer by selecting Start > All Programs > ADS LLC > Qstart from the Microsoft Windows start menu or double- clicking on the Qstart icon on the Windows desktop.
Page 105: Xml Parameters
Setting Up the Qstart Parameters The Settings dialog displays the first time you run Qstart following installation and can also be accessed through the main ADS Qstart dialog. The Settings dialog allows you to designate settings corresponding to configuration and data files.
Page 106 ® ® most spreadsheet applications, such as Microsoft Excel Select Both to collect both the ADS and CSV file formats. Select the Always use monitor XML as preferred configuration checkbox to ensure Qstart automatically overwrites the local configuration with the XML stored in the monitor memory when an Upload is performed.
Page 107 Configuration and Activation Select the appropriate CSV file column break indicator from the CSV Delimiter drop-down which you want Qstart use in all CSV files. This selection should be appropriate for the current Windows regional setting on the local computer. A comma separated values (CSV) file is sometimes called a character-separated values file because the field separators used to organize the data into columns does not always have to...
Page 108 4-6 ADS TRITON+ Manual Advanced System Parameters Accelerometer Slope Tolerance This field displays the threshold beyond which the user will see a warning that the AV|Gated, AV|Max, ParaDepth or ParaFlow sensor has too much slope. This field defaults to 5.00º.
Page 109: Configuring The Monitor Location
Configuration and Activation Configuring the Monitor Location To ensure the most efficient and useful results for each monitor location, the user must activate the TRITON+ flow monitor with the proper configuration information to satisfy the specific monitoring needs of the project and to reflect actual site conditions. The configuration information includes critical details such as the monitor name, series, pipe size and shape, sensor assignment and parameters, and data sample rate.
Page 110 Settings dialog as the Data Path. A location name may be up to 19 characters in length. Note: You can click on the Default button to update the parameters for the current location on the ADS Qstart...
Page 111 Configuration and Activation dialog based on the Default Location (designated on the Settings dialog), without changing the location name. Select TRITON+ as the type of monitor the location from the Series drop-down list. If you selected an existing site from the Location Name drop-down list, this field will automatically display the monitor series corresponding to that location.
Page 112: Configure The Monitoring Point(S)
FlowHawk monitors, choose a number from 2 to 57, 59 to 96, or 98 to 247. For installations involving Telog RU-33, ADS recommends using 1 as the ID. Enter the amount of time, in milliseconds, following a request you want the monitor to wait before returning the requested data to the third-party system in the Delay Response field.
Page 113 Enter the information for each monitoring point in the following way: Select the type or shape of the pipe or channel in which the sensors are installed from the Type drop-down list on the ADS Qstart dialog. Enter the installation information in the corresponding fields based on the selected pipe or installation type.
Page 114 4-12 ADS TRITON+ Manual Length Enter the total length of the wall, from one side of the chamber to the other. Height Enter the distance from the bottom of the channel to the initial elevation on the crest wall at which the flow will begin to traverse (or flow over) the wall.
Page 115 Configuration and Activation 4-13 Lookup Table dialog Entries Enter the number of depth values you want to display. Min Depth Enter the minimum depth possible at the monitoring point. This parameter defaults to zero and does not require modification. Max Depth Enter the maximum depth possible at the monitoring point.
Page 116 Select the combo sensor containing the velocity sensor you want to use for VELOCITY entity from the Velocity drop- down list. ADS recommends using the default of AUTO. Enter the depth of the silt at the bottom of the pipe at the monitoring point in the Silt field.
Page 117: Assigning And Editing Devices
Configuration and Activation 4-15 Assigning and Editing Devices As part of entering the monitor and monitoring point information, you must assign and edit the devices for each monitoring point. Most devices should require only minimal, if any, modification to the associated parameters. Click on the browse button located to the right of the Devices list box.
Page 118 This also will occur when collecting data using other ADS software products. Therefore, assign only one of the two devices (of the same type) to a single monitoring point.
Page 119 Configuration and Activation 4-17 Edit the parameters for the selected device as necessary, and then click OK on the device dialog when complete. Repeat steps 4 and 5 for each additional device in the Devices box and then click Save to store the changes to your local directory or network.
Page 120 ® 4-18 ADS TRITON+ Manual Editing the Advanced Device - Diagnostic Tab Advanced Device – Diagnostic tab Edit the parameters of the Diagnostic tab using the following information: Battery Voltage Select the frequency in which to store the monitor battery voltage readings.
Page 121 Edit the Modem Setup device using the following information: Provider Identify the host name of your ADS supplied private static SIM or your non-ADS supplied SIM. If the host name you want is not included on the list, use the Edit button to add a new Provider.
Page 122 This information will be given to you by your wireless SIM provider. ADS recommends using the default selection, None. Edit Select Edit to edit an existing APN or Provider. Select the Edit button to modify or add an APN Highlight the corresponding row and then edit the Parameters listed at the lower portion of the screen.
Page 123 Configuration and Activation 4-21 Description Enter the name of the APN or edit the existing name as necessary. Value 1 (Username) Enter or edit the wireless carrier’s Username, if applicable Value 2 (Password) Enter or edit the wireless carrier’s Password, if applicable. Editing the Advanced Device –...
Page 124 Please contact ADS to obtain this information. SMTP Server Enter the name of the server through which the monitor sends notification to the recipient(s).
Page 125 Note: The analog device is a custom configuration. Please consult ADS prior to wiring and configuring this device. Analog Device properties dialog Configure the analog device for a TRITON+ using the following...
Page 126 ® 4-24 ADS TRITON+ Manual MaxRegister Enter the maximum scaling values corresponding to the external Modbus module. This value is typically found in the customer’s external analog module’s user guide. Entity (for analog outputs) Select the monitor data entity whose value should be output (as analog signal) to an external analog device.
Page 127 Low Level Define the depth at which the monitor will trigger a Low Level alarm to indicate that the flow depth (at the location) has fallen below a predefined threshold. ADS recommends entering a Low Level...
Page 128 High alarm. The High High value must set to zero (0) when this feature is not in use, or greater than the value entered for the High Level alarm when in use. ADS recommends setting the High High value at least 2 inches higher than the High Level value.
Page 129 Configuration and Activation 4-27 Editing the AV|Gated Sensor This section describes the parameters for the AV|Gated device. Edit the AV|Gated 1 parameters showing the Ultrasonic tab Edit the Device Parameters located at the bottom of the dialog, and then edit the individual tabs as described in the following sections.
Page 130 ® 4-28 ADS TRITON+ Manual Note: Under normal conditions, the remaining parameters corresponding to the AV|Gated device should not require modification. However, if additional adjustments are necessary, the following sections provide a detailed description of each parameter. Ultrasonic tab – AV|Gated...
Page 131 Note: Modifications made to the Advanced Parameters should be performed only by or under the guidance of trained ADS personnel. Therefore, ADS recommends leaving the default settings (Auto) in place. Modify the parameters as necessary, and then select OK once complete.
Page 132 ® 4-30 ADS TRITON+ Manual Ping Amplitude Choose the method for managing the amplification of the analog signal that is sent out, or transmitted from, the sensor. Smaller pipes typically require weaker (quieter) amplification; larger pipes typically require stronger (louder) amplification.
Page 133 Configuration and Activation 4-31 Pressure tab – AV|Gated Edit AV|Gated 1 dialog displaying the Pressure tab Edit the following parameters corresponding to the pressure depth sensor in the AV|Gated sensor: Enable Select this checkbox to ensure the monitor begins taking pressure depth readings at the designated interval once activated.
Page 134 ® 4-32 ADS TRITON+ Manual Electronic Offset Enter the difference that exists between the pressure depth sensor readings and the manually measured depth. The default value is 0. Store Data Select this checkbox to ensure the monitor logs pressure depth data to memory. This option is selected by default.
Page 135 Edit the following parameters corresponding to the Doppler velocity sensor in the AV|Gated sensor: Note: The velocity parameters corresponding to the AV|Gated sensor typically should not require editing. However, if modifications are necessary, ADS does not recommend making changes to these parameters without proper training or assistance.
Page 136 The AV|Gated sensor is typically positioned facing upstream into the flow. This is the most common, and the default, option for selection. ADS recommends using this setting for most monitoring applications. Forward is the default selection for Velocity Direction.
Page 137 Configuration and Activation 4-35 Backward Bidirectional Choose this option when the AV|Gated Sensor is installed facing downstream and to ensure the monitor analyzes flows moving both away from and toward the face of the sensor. This option would be beneficial, for example, when using a weir to measure overflows with the potential of river intrusion.
Page 138 Note: Modifications made to the Advanced Parameters should be performed only by or under the guidance of trained ADS personnel. Therefore, ADS recommends leaving the default settings (Auto) in place. Modify the parameters as necessary, and then select OK once complete.
Page 139 Configuration and Activation 4-37 Auto Select this option to allow the monitor to automatically optimize the amplification of the signal. Manual Select this option to enter the percentage of full amplification at which to transmit the signal. Enter a percentage between 10 and 100 percent, where 100 percent represents maximum amplification.
Page 140 ® 4-38 ADS TRITON+ Manual Edit the following parameters corresponding to the temperature sensor in the AV|Gated sensor: Sensor Select the source from which to measure the temperature used when compensating for temperature in Peak Combo Sensor readings. The channels correspond to the sensors connected to those channels (ports) on the monitor.
Page 141 Editing the Data Delivery Device The Data Delivery device enables the monitor to upload flow data stored in the monitor memory to an ADS hosted system database or to an FTP site at a user-designated interval. To upload the data to...
Page 142 Normal Select the data delivery rate for non-alarm conditions Fast Select the data delivery rate to use to deliver data to the ADS database when alarm conditions exist at the monitor. Data delivery will continue at this interval until the alarm conditions return to normal.
Page 143 Data Delivery failure. CSV Format Select the desired format of the data delivery file. ADS format will show all available entities. GE format will group readings and their corresponding quality values in rows rather than displaying all stored values in column format.
Page 144 ® 4-42 ADS TRITON+ Manual Editing the Flow Device Configure the following parameters when you want the monitor to calculate and record flow rate so that it is included when you collect the data from the monitor. Edit Flow Device Properties dialog...
Page 145 Configuration and Activation 4-43 Editing the Flow Loss Device Use the following information to configure the Flow Loss device for TRITON+ Flow Loss alarms. Editing the Flow Loss device Edit the parameters of the Flow Loss device in the following way: Type Choose type of flow loss (flow or depth) alarm you want to configure for the TRITON+.
Page 146 Sensitivity Choose between Low, Medium, or High to determine the sensitivity to which the TRITON+ should trigger the Flow Loss alarm. ADS recommends leaving this setting to the default of Medium. Choosing Low has the lowest potential to trigger false Flow Loss alarms, but there is more of a potential to miss an actual alarm.
Page 147 Configuration and Activation 4-45 Store Data Choose this checkbox when you want to store data from the Inclinometer device attached to the monitor. (Selected by default.) Threshold Enter the degrees which will trigger a Tilt alarm for the TRITON+ monitor. This value defaults to 5.
Page 148 ® 4-46 ADS TRITON+ Manual Editing the Long Range Device This section describes the parameters for the Long Range Depth device. [location name] Long Range dialog Edit the parameters in the following way: Manhole Depth This is a read-only field. Manhole Depth is...
Page 149 (254 millimeters) from the face of the sensor to be ignored. Temperature Choose the method for computing the air temperature in the manhole as it relates to sensor signal. ADS recommends leaving this at the default Compensated setting. Compensated Select this option to use a normalized temperature setting to approximate the difference between the top and bottom of the manhole.
Page 150 This option is a function of the total range (manhole depth). ADS recommends using the default of Auto. This option is selected by default. 1 to 11 Select 1 for the lowest power setting, which would be most useful in short range installations with no interference.
Page 151 Configuration and Activation 4-49 Threshold – This is the percentage of the factory submerged value that will be considered a submerged sensor. The default value is 85%. Temperature Compensation – The Long Range Depth sensor compensates for the change in temperature at the top of the manhole as compared to the bottom when determining a depth measurement.
Page 152 ® 4-50 ADS TRITON+ Manual Editing the AV|Max/Peak Combo Device This section describes the parameters for the AV|Max/Peak Combo device. Edit AV|Max/Peak Combo 1 Parameters dialog showing the Ultrasonic tab Edit the Device Parameters located at the bottom of the dialog, and then edit the individual tabs as described in the following sections.
Page 153 Configuration and Activation 4-51 Pipe Height This field displays the pipe height at the monitoring point, based on the installation table. This parameter is not editable from this location. Note: Under normal conditions, the remaining parameters corresponding to the AV|Max or Peak Combo device should not require modification.
Page 154 ® 4-52 ADS TRITON+ Manual at the monitoring point, yet above the confirmed dropouts that have been detected. Store Data Select this checkbox to ensure the monitor logs the depth data to memory. This option is selected by default.
Page 155 Note: Modifications made to the Advanced Parameters should be performed only by or under the guidance of trained ADS personnel. Therefore, ADS recommends leaving the default settings (Auto) in place. Modify the parameters as necessary, and then select OK once complete.
Page 156 ® 4-54 ADS TRITON+ Manual Manual Select this option to enter the percentage of full amplification at which to transmit the signal. Enter a percentage between 10 and 100 percent, where 100 percent represents maximum amplification. Pressure tab – AV|Max/Peak Combo...
Page 157 Configuration and Activation 4-55 Store Data Select this checkbox to ensure the monitor logs pressure depth data to memory. This option is selected by default. Automatic Calibration Select this checkbox to ensure the monitor automatically calibrates questionable or erroneous pressure depth data to read consistently with the ultrasonic depth data.
Page 158 AV|Max or Peak Combo Sensor: Note: The velocity parameters corresponding to the AV|Max and Peak Combo Sensors typically should not require editing. However, if modifications are necessary, ADS does not recommend making changes to these parameters without proper training or assistance.
Page 159 Note: When using an AV|Max or Peak Combo Sensor and a Surface Combo Sensor at the same monitoring point, ADS recommends maintaining the same settings for all of the parameters corresponding to both Peak Velocity (Velocity tab on the Edit Peak Combo Parameters...
Page 160 However, if the velocity readings at the location measure at least 10 feet per second (fps) on a regular basis, ADS recommends choosing the 15 fps option for this parameter. If the location is downstream...
Page 161 Maximum Velocity setting from Auto to a setting slightly above the maximum recorded velocity. Transmit Frequency Select the frequency at which to transmit the signal. ADS recommends leaving the default setting (High) selected. Gain This value represents the factor applied to raw velocity...
Page 162 ® 4-60 ADS TRITON+ Manual DAC Gain Choose the method for managing the amplification of the analog signal that returns to the sensor: Auto Select this option to allow the monitor to automatically optimize the amplification of the signal. Manual Select this option to enter a fixed value between -12db (lower amplification) and +12db (high amplification) at which to amplify the signal.
Page 163 Configuration and Activation 4-61 Edit AV|Max/Peak Combo 1 Parameters dialog displaying the Temperature tab Edit the following parameters corresponding to the temperature sensor in the AV|Max or Peak Combo Sensor: Sensor Select the source from which to measure the temperature used when compensating for temperature in AV|Max or Peak Combo Sensor readings.
Page 164 ® 4-62 ADS TRITON+ Manual Editing the Sampler Device Use the following information when you want to edit the parameters for water quality sampling activities associated with a TRITON+. Edit the Sampler device Note: When performing water quality sampling using externally...
Page 165 Configuration and Activation 4-63 Qstart configuration screen. Choose Depth to initiate sampling based on UNIDEPTH readings from the selected depth combo sensor. Flow Rate and Flow Total are instantaneous calculations based on the selected depth and velocity sensors in the Combo Sensor to Use.
Page 166 ® 4-64 ADS TRITON+ Manual Editing the ParaDepth/Smart Depth Device Use the following information to edit the parameters of the ParaDepth/Smart Depth device. Edit ParaDepth/Smart Depth 1 Parameters dialog Edit the following parameters corresponding to the downward- looking ultrasonic (smart) depth sensor as necessary:...
Page 167 5 percent of the range from the sensor face to the bottom of the pipe. This option represents most pipe/flow conditions; therefore, ADS strongly recommends leaving this option selected for most applications. Choose one of the other options only when spikes in the data are occurring beyond 5 percent of this range and under direct consultation with an ADS representative.
Page 168 Note: Modifications made to the Advanced Parameters should be performed only by or under the guidance of trained ADS personnel. Therefore, ADS recommends leaving the default settings (Auto) in place. Modify the parameters as necessary, and then select OK once complete.
Page 169 Configuration and Activation 4-67 Surcharge Detection Select the Disable checkbox to prevent the monitor from implementing the Surcharge Detection function when processing Smart Depth data. For locations that typically do not experience surcharge, disabling Surcharge Detection eliminates the processing time required for this function and, as a result, conserves monitor power.
Page 170 ® 4-68 ADS TRITON+ Manual Store Data Select this checkbox to ensure the monitor logs the temperature data to memory. This option is selected by default.
Page 171 Configuration and Activation 4-69 Editing the ParaFlow/Surface Combo Sensor Device The following section provides descriptions for the parameters corresponding to the ParaFlow/Surface Combo Sensor device. Edit ParaFlow/Surface Combo 1 Parameters dialog (Smart Depth tab) Edit the following Device Parameters at the bottom of the dialog, and then edit the individual tabs as described in the following sections: Physical Offset Enter the physical distance from the face of...
Page 172 ® 4-70 ADS TRITON+ Manual Pipe Height This field displays the pipe height at the monitor location, based on the installation table. This parameter is not editable from this location. Note: Under normal conditions, the remaining parameters corresponding to the Surface Combo device should not require modification.
Page 173 5 percent of the range from the sensor face to the bottom of the pipe. This option typically represents the vast majority of pipe/flow conditions; therefore, ADS strongly recommends leaving this option selected for most applications. Choose one of the other options only when spikes in the data are occurring beyond 5 percent of this range and under direct consultation with an ADS representative.
Page 174 ® 4-72 ADS TRITON+ Manual DAC Gain Choose the method for managing the amplification of the analog signal that returns to the sensor: Auto Select this option to allow the monitor to automatically optimize the amplification of the signal. Manual Select this option to enter a fixed value between -12db (lower amplification) and +12db (high amplification) at which to amplify the signal.
Page 175 This option is selected by default. Transmit Frequency Select the frequency at which to transmit the signal. ADS recommends leaving the default setting (Low) for most applications. However, if hydraulic conditions at the site are resulting in questionable or erroneous...
Page 176 The ParaFlow and Surface Combo Sensor typically are positioned facing upstream toward the oncoming flow. This is the most common option for selection. ADS recommends using this setting for most monitoring applications. It also requires less processing time and conserves power.
Page 177 Note: Modifications made to the Advanced Parameters should be performed only by or under the guidance of trained ADS personnel. Therefore, ADS recommends leaving the default settings (Auto) in place. Modify the parameters as necessary, and then select OK once complete.
Page 178 ® 4-76 ADS TRITON+ Manual Auto Select this option to allow the monitor to automatically optimize the amplification of the signal. Manual Select this option to enter a fixed value between -12db (lower amplification) and +12db (high amplification) at which to amplify the signal.
Page 179 Note: When using a Peak Combo sensor and Surface Combo sensor at the same monitoring point or an AV|Max sensor and ParaFlow, ADS recommends maintaining the same settings for all the parameters corresponding to both Peak Velocity (Velocity tab on the Edit Peak Combo...
Page 180 The ParaFlow and Surface Combo Sensor typically are positioned facing upstream toward the oncoming flow. This is the most common option for selection. ADS recommends using this setting for most monitoring applications. Backward Choose this option for monitoring points at...
Page 181 However, if the velocity readings at the location measure at least 10 feet per second (fps) on a regular basis, ADS recommends choosing the 15 fps option for this parameter. Transmit Frequency Select the frequency at which to transmit the signal.
Page 182 ® 4-80 ADS TRITON+ Manual Advanced Parameters dialog Modify the parameters as necessary, and then select OK once complete. DAC Gain Choose the method for managing the amplification of the analog signal that returns to the sensor: Auto Select this option to allow the monitor to automatically optimize the amplification of the signal.
Page 183 This option is selected by default. Electronic Offset Enter the difference that exists between the pressure depth readings and the value equal to the pipe height minus the physical offset of the ParaFlow or Surface Combo Sensor. However, ADS recommends leaving this value at zero.
Page 184 Pipe Height minus the Physical Offset when the manhole is not surcharged. Note: Do not reactivate the ADS TRITON+ monitor when the manhole is surcharged. The Pressure sensor will not work properly if this is done. If it is imperative that the monitor be reactivated, disable Automatic Calibration before reactivating.
Page 185 Configuration and Activation 4-83 Editing the Time Zone Device The following section provides descriptions for the parameters corresponding to the Time Zone device. Edit the Time Zone device parameters Select the Time Zone of the monitor, not the Qstart host computer.
Page 186 ® 4-84 ADS TRITON+ Manual Editing the XIO Device Use the following information to configure the externally powered ™ device for the TRITON+ monitor for up to two analog inputs, two analog outputs, two digital inputs and two digital outputs: XIO Device properties dialog Note: There is a single XIO device limit per TRITON+.
Page 187 Configuration and Activation 4-85 Min Value Input the minimum value for the incoming analog signal which will be used to scale the data values. This value represents the weakest signal corresponding to the incoming 4mA signal. For example, enter the value corresponding to the lowest depth reading for a DEPTH_A1 input.
Page 188 ® 4-86 ADS TRITON+ Manual Entity Select the data entity whose value you want the XIO device to output as an analog signal. While the list contains all entities, choose only those entities which the monitor is currently generating. Min Value Enter the data value (for the selected entity) which will correspond to the weakest analog output signal.
Page 189 Configuration and Activation 4-87 Entity Choose the corresponding MLI event to which you want to relay (output) the current status to a digital device. The current event status will be updated and output at each monitor sample interval.
Page 190: Activating The Monitor
Activate the monitor in the following way: Attach the wireless antenna to the monitor. Select the monitor you want to activate from the Location Name drop-down list in the Monitor section on the ADS Qstart dialog. Verify that the configuration parameters and Connect type for the monitor and monitoring point are correct and make modifications, as necessary.
Page 191 Configuration and Activation 4-89 Continue with other activities that require communication with the monitor or disconnect from the monitor by clicking on the green Hangup button in the Functions section. If applicable to the connection type, consider checking the monitor status to verify the monitor is active and the data storage interval reflects the sample rate selected for the monitor.
Page 192: Setting Up The Rtu To Retrieve The Current Data Through Modbus
Modbus register addresses corresponding to the current entity and monitor data you want to retrieve from the monitor. ADS also recommends verifying that the RTU is retrieving the desired output data shortly following monitor activation. Note: The Telog Ru-33/Ru-35 does not require programming with the Modbus register addresses to ensure it retrieves the correct data.
Page 193 Configuration and Activation 4-91 note the interval at which the monitor takes readings for Modbus output is based on the Scan rate. Collect the data from the monitor. Refer to Collecting Data from the Monitor on page 4-100 for detailed instructions. Compare the data collected from the monitor to the output values obtained through Modbus.
Page 194: Running Sensor Diagnostics
Perform diagnostics on a device in the following way: Select the monitor for which you want to run diagnostics on a sensor from the Location Name field in the Monitor section on the ADS Qstart dialog. Click on the Connect button in the Functions section.
Page 195 Configuration and Activation 4-93 The monitor takes the sensor measurements and displays the readings in the Results window. The results may include the specific reading (e.g., depth or velocity), the quality of the reading, the maximum signal strength, and the temperature. When taking depth measurements, the dialog also displays a cross section of the pipe, offering a visual perspective of the depth of the flow.
Page 196 ® 4-94 ADS TRITON+ Manual Review the ParaDepth or ParaFlow Sensor Slope and Sensor Rotation values Verify the accuracy, consistency, and quality of the readings, and then edit the corresponding device parameters as necessary. (optional) Repeat steps 3 through 10 for every other sensor on the device dialog on which you want to run diagnostics.
Page 197 Configuration and Activation 4-95 12. Once activation is complete, the status bar displays Activate successful. 13. Click on the Hangup button in the Functions section when you are finished running diagnostics on sensors associated with the current monitor. 14. Click on the Save button to save any changes in the device parameters to the local directory or network.
Page 198: Performing Confirmations
® 4-96 ADS TRITON+ Manual Performing Confirmations Confirmations allow you to compare measurements taken by the sensors to measurements taken manually in the field. These comparisons help to verify that the sensors are functioning properly and determine whether specific device parameters may require modification.
Page 199 Configuration and Activation 4-97 Select the monitor for which you want to perform confirmations from the Location Name field in the Monitor section on the ADS Qstart dialog. Select the device with the sensor(s) you want to confirm from the Devices list.
Page 200 ® 4-98 ADS TRITON+ Manual 10. Click on the Read button to prompt the monitor to take depth and velocity measurements. The Monitor Measurement section displays the depth and velocity readings taken by the monitor. 11. Compare the manual field measurements to the sensor readings.
Page 201 Configuration and Activation 4-99 16. Repeat steps 2 through 12 for each additional device that includes a sensor(s) you want to confirm. Note: If the location supports a second monitoring point, remember to confirm the devices assigned to that monitoring point, as necessary. 17.
Page 202: Collecting Data From The Monitor
® 4-100 ADS TRITON+ Manual Collecting Data from the Monitor Collect data from a monitor in the following way: Select the monitor from which you want to collect data from the Location Name drop-down list in the Monitor section on the ADS Qstart dialog.
Page 203 Configuration and Activation 4-101 View the data in tabular and graphical format on the View Data dialog. Modify the graph based on the time period and entities in the following ways: Select the amount of data you want to display on the graph at one time by selecting the appropriate option from the Report Type drop-down list (All, Day, Week, or Month).
Page 204 ® 4-102 ADS TRITON+ Manual information at the time of the collect. You can view the contents of the entry through the log viewer in Qstart...
Page 205: Upgrading The Monitor Firmware
Upgrade the firmware in the monitor in the following way: Note: ADS recommends collecting the monitor data before performing a firmware upgrade. Select the monitor for which you want to upgrade the firmware...
Page 206: Viewing Diagnostic And Data Logs
® 4-104 ADS TRITON+ Manual Viewing Diagnostic and Data Logs The local directory or network contains detailed diagnostic, status, and data logs corresponding to many activities performed involving the monitor and sensors such as activation, data collection, firmware downloads, sensor diagnostics and confirmations. These logs are available immediately following the activity and for future access to historical information.
Page 207: Chapter 5 Sensor Installation And Connection
C H A P T E R 5 Sensor Installation and Connection ® The ADS TRITON+ flow monitor and sensors are primarily designed for monitoring flow in sanitary, storm, and combined sewers. The monitor mounts to the manhole rim or wall slightly below the manhole cover or to a rung in the manhole.
Page 208 Sensor to the Mounting Bar, and affixing the Submersion Sensor to the manhole frame. Install the ParaDepth or ParaFlow Sensor in the Manhole using the ADS Topside Retrieval System This process involves installing a Mounting Bracket in the manhole, installing the sensor on the Sensor Bracket, seating the Sensor Bracket on the Mounting Bracket.
Page 209 ADS is not responsible for any injuries, damages, claims, or liability resulting directly or indirectly from the use of this installation guide or the installation of any ADS equipment.
Page 210: Investigating Site Characteristics
5-4 ADS TRITON+ Manual Investigating Site Characteristics Before beginning installation activities, conduct a thorough investigation of hydraulic and site conditions. Flow Hydraulics The hydraulics of a site directly affect the monitor's ability to accurately measure flow depth and velocity. The following...
Page 211: Pipe And Manhole Characteristics
Sensor Installation and Connection Flow Traveling at Least One Foot Per Second Slower flows enable debris to settle in the pipe, limiting the accuracy of flow measurements. Higher Elevation than High Water Level that Occurs in Wet Well at Downstream Pump Station Pipes that are below the high water level of the pump station wet well could experience frequent backup and surcharging.
Page 212 5-6 ADS TRITON+ Manual bracket positioned above the crown of the pipe on the manhole wall. Pipe Height and Width Measure and record the horizontal and vertical pipe dimensions carefully. Inaccurate pipe measurements—even slightly inaccurate measurements--can skew and misrepresent flow data.
Page 213: Installing The Sensors In The Pipe
Sensor Installation and Connection Installing the Sensors in the Pipe This section includes the procedures for performing sensor installations using one of the following methods: Standard Installations Special Installations Note: When installing a monitor with wireless communications, it is very important to test the TRITON+ with the SIM card installed to ensure the entire system functions and to verify network quality of service before installation.
Page 214 Monitor mounting bracket washer, split lock, SS 517-8001274-00 1 as 8000-0021 Hook, SS, 2-piece w/ hardware needed (for hanging monitor on manhole rung; Alternative to ADS p/n I40-0009) 1 as 8000-0307-02 Bracket, mounting, sliding, for ParaDepth, needed ParaFlow, Surface Combo or Ultrasonic Depth Sensors (mounting plate)
Page 215 Sensor Installation and Connection Quantity Description ADS P/N Up to 2 AV|Max Sensor – upward ultrasonic depth, 8K-CS9-10-35 (1 per sensor, pressure depth sensor, peak velocity (35-ft./10.6-m or monitoring sensor, and water temperature sensor 100-ft./30.5-m point) cable) 1 as Inclinometer - Angle/Tilt sensor installed on...
Page 216 5-10 ADS TRITON+ Manual Quantity Description ADS P/N Replacement dryer tube 3704–0032 IS PC communication USB Serial Cable 8000-0337 Antenna for wireless communication 3800-0162 or 3800-0163 1 as Magnet (for activating diagnostic codes in the 8000-0460 needed monitor through the LED STATUS window)
Page 217 Sensor Installation and Connection 5-11 Quantity Description ADS P/N ¼-in. (7mm x 400mm) anchor cable ties 18-inch (457-mm) stainless steel crank handle I10–0012 Models 8000-FST-IM-4WW-XXX include the 12-volt battery pack; Models 8000- FST-IM-EP-4WW-XXX (for external power) do not include the battery pack.
Page 218 (3/8-in. standard) Diagonal wire cutters Folding carpenter’s rule with a brass slide Mastic tape (ADS p/n 507193) or rubber coaxial stretch tape Assembling the Ring The flow sensors mount to a stainless steel ring for installation in the pipe. Several different ring sizes exist, and each ring is adjustable within about 3 inches (76 mm) to fit pipes of different diameters.
Page 219 Sensor Installation and Connection 5-13 Ring stabilizer with spreader mechanism screw Slide the open end of the ring (end without the welded metal band) through the flanges in the ring stabilizer, making sure the flanges face the outside of the ring and the spreader mechanism screw faces the inside of the ring.
Page 220 5-14 ADS TRITON+ Manual Moving the ring stabilizer into position Position the ring with the downstream edge (edge with the holes) facing you.
Page 221 Sensor Installation and Connection 5-15 Slide the ParaDepth/ParaFlow/Surface Combo/Ultrasonic Depth Sensor mounting plate onto the open end of the ring with the back of the mounting plate (side with the slots) facing the outside of the ring. The side with the keyholes should face the inside of the ring.
Page 222 5-16 ADS TRITON+ Manual Spread the ring sections apart so that you can slide the ring stabilizer with the spreader mechanism screw into the gap. Moving the ring stabilizer into position Perform the following based on the ring type: Overlapping Insert the spreader mechanism screw completely through the hole at the open end of the ring.
Page 223 Sensor Installation and Connection 5-17 10. Place the ring on a flat surface with the spreader mechanism screw facing up. 11. Orient the ring with the downstream edge (edge with small holes) facing you. 12. Lay the spreader mechanism across the inside of the ring with the downstream end of the mechanism (end with the large welded nut) facing you, the four spreader bars facing toward the inside of the ring, and the shoulder bolts pointed outside the...
Page 224 5-18 ADS TRITON+ Manual Attaching the spreader bars 16. Turn the ring until the spreader mechanism is in the 12:00 position. 17. Align the spreader mechanism screw so that the head is visible through one of the ring size adjustment holes.
Page 225 Sensor Installation and Connection 5-19 18. Tighten the screw through the hole using a Phillips-head screwdriver while holding the hex nut with a 0.5-inch (12-mm) nut driver. Tightening the spreader mechanism screw and hex nut 19. Insert the second spreader mechanism screw through the following hole based on the ring type: Overlapping Appropriate ring size adjustment hole on the outside of the ring...
Page 226 5-20 ADS TRITON+ Manual Place the washers onto the second spreader mechanism screw 21. Place the spreader bars over the screw, and tighten a hex nut on the screw. Spreader mechanism attached to the ring (view from inside the ring)
Page 227 Sensor Installation and Connection 5-21 Although the spreader mechanism fits snugly against the inside of the ring, the spreader mechanism may seem loose on the hex nuts. Do not be concerned. The spreader mechanism will tighten once the ring is installed and tightened inside the pipe. The following picture displays how a properly assembled ring with the ultrasonic depth sensor mounting plate should look.
Page 228 5-22 ADS TRITON+ Manual AV|Gated Sensor Mount the sensor as close as possible to the six o’clock position (bottom). The sensor must be within +/- 5 degrees of the bottom center of the pipe. AV|Gated sensors should not be installed in pipes with silt. If necessary, a...
Page 229 Sensor Installation and Connection 5-23 Proper positioning of sensors on the ring Surface Combo, ParaDepth, or ParaFlow sensor at top and AV|Gated, AV|Max or Peak Combo sensor at the bottom) ParaDepth, ParaFlow, Surface Combo Sensor or Ultrasonic Depth Sensor Mount the sensor at the twelve o’clock position (top of the pipe) with the spreader mechanism in the ten or two o’clock position.
Page 230 (opposite from the ParaDepth, ParaFlow or Surface Combo Sensor/Ultrasonic Depth Sensor). ADS recommends installing AV|Gated, AV|Max and the □ Peak Combo sensors within 5 degrees of the pipe centerline.
Page 231 5-25 Mounting the AV|Gated, AV|Max or Peak Combo sensors to the ring If the sensors require the use of a Silt Mount Adapter (ADS p/n 8000-0271) to install the sensor further up the left side of the pipe (up to 30 degrees) attach the AV|Gated, AV|Max or Peak...
Page 232 5-26 ADS TRITON+ Manual Properly seating and securing the AV|Gated/AV|Max/Peak Combo to the Silt Mount Adapter Use two M3 X 10mm stainless steel flathead screws (do not substitute any other screws) to secure the adapter to the ring at the appropriate location on the ring to ensure the sensor will be positioned at 30 degrees up the left side of the pipe and below the flow surface once installed.
Page 233 Sensor Installation and Connection 5-27 directly at the top. If no ParaDepth, ParaFlow, Surface Combo sensor or Ultrasonic Depth sensor will be used at the top of the pipe, make sure the spreader assembly is at the 2:00 or 10:00 position so as not to interfere with the underwater ultrasonic depth sensor reading in full pipe conditions.
Page 234 5-28 ADS TRITON+ Manual Warning: Do not over-tighten the cable ties or kink the sensor cables! The sensor cable sheathes two components: the electrical cables that operate the sensor and an air tube that ventilates the pressure sensor (when applicable). Over-tightening the ties or kinking the cable can damage or restrict the air tube, causing erroneous pressure depth readings.
Page 235 Sensor Installation and Connection 5-29 Place the ring in the input pipe at least 12 inches (305 mm) upstream from the manhole or edge of the pipe with the sensors facing upstream toward the oncoming flow. It must be located far enough upstream from the manhole to minimize the effect of the draw-down caused by a possible drop in the manhole invert.
Page 236 30 degrees up the left side of the pipe with the Silt Mount Adapter. For best performance, ADS recommends sensor rotation of less than 5 degrees when no adapter is used. After activating...
Page 237 Sensor Installation and Connection 5-31 Rotating the AV|Max/Peak Combo sensor no more than 15 degrees up either side of the pipe or 30 degrees up the left side of the pipe using the Silt Mount Adaptor If necessary, temporarily clear away silt to install the ring. Restore the silt after fully securing the ring (step 7).
Page 238 5-32 ADS TRITON+ Manual An elevated sensor provides a gap in which debris can collect Deterioration in the pipe surface creates a space for debris to collect under the sensor Expand the ring by turning the spreader mechanism nut counter-clockwise with the crank handle or socket. However, do not tighten the ring against the pipe completely at this point.
Page 239 Sensor Installation and Connection 5-33 Mounting the ParaDepth/ParaFlow/Surface Combo/Ultrasonic Depth sensor to the mounting plate on the ring Note: Handle the ParaDepth/ParaFlow/Surface Combo/Ultrasonic Depth sensors with care, and do not expose it to extreme temperatures for an extended period of time. Keep the sensor in its protective packaging until it is time for installation.
Page 240 5-34 ADS TRITON+ Manual SURFACE COMBO/ULTRASONIC DEPTH SENSOR RING MANHOLE WOOD BLOCK SPACER PIPE LEVEL Leveling the Surface Combo/Ultrasonic Depth sensor If necessary, adjust the level in either sensor in the following way: Remove the sensor from the mounting plate.
Page 241 Sensor Installation and Connection 5-35 Fully tighten the ring until it fits securely and completely flush against the pipe wall. Warning: Avoid over-tightening the ring. This could bend the crank assembly. Install an anchor bolt in the manhole wall just above the pipe crown.
Page 242 5-36 ADS TRITON+ Manual DISTANCE FROM SENSOR NOSE TO SURFACE WATER SURFACE CENTER PIPE DEPTH SILT PHYSICAL OFFSET Illustrating the method for determining the physical offset for a rotated AV|Max/Peak Combo sensor ParaDepth/ParaFlow Physical Offset Measure the distance from the crown (top) of the pipe to the face of the sensor to determine the physical offset.
Page 243 Sensor Installation and Connection 5-37 Surface Combo Sensor/Ultrasonic Depth Sensor Physical Offset Measure the distance from the crown (top) of the pipe to the face of the sensor (horizontal surface with the two depth crystals) to determine the physical offset. Typical offsets range from 1.25 to 1.50 inches (32 to 38 mm).
Page 244: Special Installations For Av|Gated, Av|Max, Peak Combo, Surface Combo, Or Ultrasonic Depth Sensors
5-38 ADS TRITON+ Manual Special Installations for AV|Gated, AV|Max, Peak Combo, Surface Combo, or Ultrasonic Depth Sensors A special installation requires two independent installations: one for the Surface Combo Sensor or Ultrasonic Depth Sensor and one for the Peak Combo or AV|Gated sensor.
Page 245 Sensor Installation and Connection 5-39 Gathering Parts and Supplies Be sure to obtain the following supplies before performing a special installation to prevent any costly delays. When ordering, specify the TRITON+ monitor special installation hardware. In addition, please indicate the type of mounting hardware desired for mounting the monitor: mounting bracket (wall/rim mount) or hook (rung mount).
Page 246 5-40 ADS TRITON+ Manual Quantity Description ADS P/N TRITON+ flow monitor (battery or externally- 8000-FST-IM- powered) 4WW(-XXX), 8000- FST-IM-EP-4WW(- XXX) Monitor mounting bracket/flange (for mounting I40–0009 monitor to manhole rim or wall) Monitor mounting bracket bolt, hex, SS, M8 X...
Page 247 Sensor Installation and Connection 5-41 Quantity Description ADS P/N point) cable) Up to 2 Surface Combo Sensor – downward ultrasonic 8K-CS5-V2-xx- (1 per depth sensor, surcharge pressure depth 30/1H (30-ft./9.1-m monitoring sensor, surface velocity sensor, surcharge or 100-ft./30.5-m point) velocity sensor and air temperature sensor...
Page 248 5-42 ADS TRITON+ Manual Quantity Description ADS P/N 1 as External Modbus Interface Unit (XBUS) 8000-0427 needed 1 as External Input and Output Device (XIO) 8000-0400 needed 1 as External power/communications cable (from 8000-0388-xxx needed ExPAC to monitor) 1 as...
Page 249 Screwdrivers (flathead and Phillips head of assorted sizes) Threads tap compatible with the thread spec on the monitor mounting stud Diagonal wire cutters Folding carpenter’s rule with a brass slide Mastic tape (ADS p/n 507193) or rubber coaxial stretch tape...
Page 250 5-44 ADS TRITON+ Manual Mounting AV|Gated, AV|Max or Peak Combo Sensors Note: Regardless of which band is used to install the AV|Gated sensor, it must be installed no more than +/- 5 degrees from the bottom center of the pipe. If further...
Page 251 5-45 Note: When positioning the special mounting metal, ADS recommends reserving the left side of the pipe for the long end of the ¾-band (end extending almost completely up one side of the pipe) and the ¼-band for routing the sensor cable and accommodating the Silt Mount Adapter (when necessary).
Page 252 5-46 ADS TRITON+ Manual (Left) AV|Gated, AV|Max or Peak Combo sensor mounted using a ¾-band mount in the pipe without silt. (Right) AV|Gated, AV|Max or Peak Combo sensor only mounted in pipe with silt. (applies only when mounting the AV|Gated, AV|Max, or Peak Combo sensor within +/- 5 degrees of the 6:00 position.)
Page 253 Sensor Installation and Connection 5-47 the pipe) Use the Silt Mount Adapter (ADS p/n 8000-0271) to attach the sensor to the band in the following way: Seat the AV|Gated, AV|Max or Peak Combo sensor onto the slightly elevated portion of the top of the Silt Mount Adapter.
Page 254 5-48 ADS TRITON+ Manual mounting holes do not exist on the band at or near the desired mounting location for the adapter/sensor, drill holes in the band using a 7/32-inch (3-mm) drill bit. ADAPTER/SENSOR ASSEMBLY INNER SURFACE OF RING OR BAND...
Page 255 Sensor Installation and Connection 5-49 12. Install ¼-inch x 2 ¼-inch (M6 x 55-mm) anchor bolts, nuts and washers at the pre-drilled hole at the short end of the band and at the pre-drilled holes along the long end of the band (above the flow surface) approximately every 12 to 24 inches (305 to 610 mm) to the top end of the band.
Page 256 (applies only to AV|Gated, AV|Max orPeak Combo when mounting the sensor between 15 and 30 degrees up the side of the pipe) Use the Silt Mount Adapter (ADS p/n 8000-0271) to attach the sensor to the band in the following way:...
Page 257 Sensor Installation and Connection 5-51 Spot drill the pipe wall through the hole, install a ¼-inch x 2 ¼-inch (M6 x 55-mm) anchor bolt, and secure the band to the anchor bolt with a washer and nut. Note: Make sure the submerged portion of the band is flush with the pipe wall.
Page 258 5-52 ADS TRITON+ Manual Note: This value will be necessary when configuring the monitor using the Qstart software. 12. Run the sensor cables from the sensor location in the pipe to the monitor location in the manhole according to the instructions in Securing the Sensor Cables in the Pipe and Manhole on page 5-80.
Page 259 Sensor Installation and Connection 5-53 Pull the ties until they are taut. Warning: Do not over-tighten the cable ties or kink the sensor cables! The depth cable sheathes two components: the electrical cables that operate the sensor and an air tube that ventilates the sensor (when applicable).
Page 260 5-54 ADS TRITON+ Manual Standard Mount Mount the ParaDepth, ParaFlow, Surface Combo or Ultrasonic Depth sensor using this method in the following way: Note: Handle the sensor with care, and do not expose it to extreme temperatures for an extended period of time.
Page 261 Sensor Installation and Connection 5-55 Securing one end of the sensor mounting band Slide the sensor mounting plate (ADS p/n 8000-0307-02) onto the band with the end of the plate with the keyholes facing upstream and the two band slots facing up.
Page 262 5-56 ADS TRITON+ Manual Spot drill to mark an anchor bolt location, and mount another ¼-inch x 2 ¼-inch (M6 x 55-mm) anchor bolt to the pipe. Hand-tighten a nut with washer to secure the other end of the band.
Page 263 Sensor Installation and Connection 5-57 Fastening the downward looking sensor to the mounting plate on the band 12. Confirm the sensor is still level. For the ParaDepth or ParaFlow sensor refer to Chapter 4 Running Sensor Diagnostics for more information on determing how level the sensor is.
Page 264 5-58 ADS TRITON+ Manual Measureing the Physical Offset of the Surface Combo or Ultrasonic Depth Sensor 14. Determine the Physical Offset for the ParaDepth/ParaFlow sensor by measuring the distance from the crown (top) of the pipe to the face of the sensor as shown in the picture below.
Page 265: Installing The Sensors In The Manhole Structure
Sensor Installation and Connection 5-59 Installing the Sensors in the Manhole Structure This section includes the procedures for performing installations in the manhole structure for the following ADS TRITON+ sensors: Long Range Depth Sensor ParaDepth Sensor ParaFlow Sensor Surface Combo Sensor...
Page 266 5-60 ADS TRITON+ Manual Installing the Submersion Sensor Measuring the physical offset...
Page 267 ® 5-61 ADS TRITON+ Manual Selecting an Installation Location Manhole structures with the following characteristics facilitate the installation of Long Range Depth Sensor: Manhole depth between 3 and 21 feet (914 – 6400 mm) Note: The maximum range of the Long Range Depth Sensor is 20 feet (6096 mm).
Page 268 J-Hook Folding Carpenter’s Rule with a brass slide 36-inch (914-mm) Carpenter’s Level Obtain the following supplies from ADS before performing the Long Range Depth Sensor installation to prevent any costly delays. When ordering, specify the TRITON+ monitor Long Range Depth Sensor installation hardware.
Page 269 Sensor Installation and Connection 5-63 Models 8000-FST-IM-4WW-XXX include the 12-volt battery pack; Models 8000- FST-IM-EP-4WW-XXX (for external power) do not include the battery pack. Extension cables can be ordered to specific lengths up to 300 ft. (91m). Note the desired length (in feet) in the -xxx-- portion of the part number. Standard lengths are 10 ft.
Page 270 5-64 ADS TRITON+ Manual Extending Grade Pole to absolute bottom surface of invert 6. Read Grade Pole measurement from point where the Grade Pole crosses the bottom of level or other flat, rigid item. Record measurement. Recording measurement for manhole depth...
Page 271 Sensor Installation and Connection 5-65 Note: For installations within wider manhole frames, refer to Adding Extension Rods to the Mounting Bar information on extending the mounting bar before proceeding with the installation. If the manhole or manhole frame will not accommodate a Mounting Bar with or without extensions, a Wall Mount Bar must be installed.
Page 272 5-66 ADS TRITON+ Manual Passing un-tethered end through large loop Cinching the tether to the top rung Position the bar in the manhole frame so the sensor has a clear view of the manhole invert. Perform the following adjustments to ensure proper sensor...
Page 273 Sensor Installation and Connection 5-67 If the invert runs through the center of the manhole, the Mounting Bar should be installed parallel to the flow. Parallel Mount If the invert is offset from the center, rotate the Mounting Bar appropriately so the sensor housing can be pointed directly at the invert.
Page 274 5-68 ADS TRITON+ Manual Mount Rotation to Accommodate Bend With the Mounting Bar in proper invert-orientation, turn knob to extend rod to just short of manhole frame walls. Position the bar so that the distance between it and the street surface is 8 inches (200 mm) to 12 inches (305 mm) and is mounted within the manhole frame.
Page 275 Sensor Installation and Connection 5-69 Reference the bubble level as you tighten the knob on the Mounting Bar in the manhole frame to ensure that the bar will provide a level sensor mounting surface. Ensuring Mounting Bar is level Twist the locking nut counterclockwise to extend the mounting bar, spanning the diameter of the frame.
Page 276 Extension Rod If the manhole is larger than standard-sized openings, utilize one Mounting Bar Extension Rod (ADS p/n 8000-0481) for frames extending 28 inches (711 mm) to 36 inches (914 mm) and two Mounting Bar Extension Rods for frames 36 inches (914 mm) to 44 inches (1118 mm).
Page 277 Installing Wall Mount Bar Wall Mount Bar with bracket If the manhole or manhole frame will not accommodate a standard Mounting Bar with or without extensions, utilize the Wall Mount Bar (ADS p/n 8000-0484) for installation. Install the Wall Mount Bar as follows:...
Page 278 5-72 ADS TRITON+ Manual Select location of Wall Mount Bar installation. Make sure the sensor will have a clear view of the invert. Refer to Step 4 of Installing the Mounting Bar to ensure proper sensor positioning. Place the Wall Mount Bar bracket on selected location, ensuring bar will be level, and mark screw holes for drilling or screwing anchor points.
Page 279 Sensor Installation and Connection 5-73 Unscrewing and opening shroud bracket Position sensor under Mounting Bar and bring hinge over bar and tighten thumb screw. Positioning and tightening sensor bracket to Mounting Bar Ensure that the bar remains level and the bubble on the sensor is centered.
Page 280 5-74 ADS TRITON+ Manual Double-check that the bar is suspended tightly at anchor points. Long Range Sensor Fully Installed Installing the Submersion Sensor on Manhole Frame Attach the Submersion Sensor to the manhole frame as close to the top of the rim as possible. The Submersion Sensor senses when flow depths reach it and will cause the TRITON+ to send out a Submerged alarm when the sensor goes under water.
Page 281 Sensor Installation and Connection 5-75 Warning: The Submersion Sensor has a strong magnet for adherence to the manhole frame. Keep the sensor away from metal objects as it may potentially cause damage! Additionally, do not place the Submersion Sensor near a computerized device with a magnetic hard drive like PCs and laptops! Measuring the Physical Offset...
Page 282 This method of mounting the sensor requires a special surcharge bracket (ADS p/n I40-0010) and sliding adapter bracket (ADS p/n 8000-0299). Mount the sensor in...
Page 283 Ultrasonic Depth Sensor portion of the surcharge bracket (ADS p/n I40-0010). The sensor attaches to the sliding adapter bracket (ADS p/n 8000-0299) that slides into the groves of the mounting plate at the lower portion of the surcharge bracket. When making this determination, keep in mind that the maximum range of the sensor is 10 feet (3.05 m).
Page 284 Rotate the bracket 90 , and drill and mount a ¼-inch x 2 ¼- inch (M6 x 55-mm) anchor bolt. 10. Secure the bottom of the bracket with a washer and nut. 11. Slide the sliding adaptor bracket (ADS p/n 8000-0299) into the mounting plate on the surcharge bracket. ANGLED SURCHARGE BRACKET...
Page 285 Sensor Installation and Connection 5-79 ANGLED SURCHARGE BRACKET ULTRASONIC DEPTH SENSOR SLIDING ADAPTER BRACKET ULTRASONIC DEPTH SENSOR Attaching the Ultrasonic Depth Sensor to the Sliding Adapter Bracket Note: Secure the sensor cable with cable ties to keep the sensor in place. 13.
Page 286: Topside Retrieval System (Applies To Paradepth And Paraflow Sensors)
Topside Retrieval System (applies to ParaDepth and ParaFlow Sensors) This section includes the procedure for installation of the ParaDepth and ParaFlow sensors using the ADS Topside Retrieval System. The installation involves: Installing the Topside Wall Mount Bracket in the manhole...
Page 287 5-81 Gathering Parts and Supplies Gather the following parts and supplies before heading to the field to install the ADS Topside Retrieval System along with either the ParaDepth or ParaFlow sensor. Gather the following equipment for the installation: Battery powered hammer drill ”...
Page 288 5-82 ADS TRITON+ Manual Topside Wall Mount Bracket Topside Sensor Bracket...
Page 289 ADS finds that often the output side of the invert best meets this criteria.
Page 290 ADS is not responsible for any injuries, damages, claims, or liability resulting directly or indirectly from the use of this installation guide or the installation of any ADS equipment. Determine which wall, upstream or downstream the Wall Mount Bracket will be installed on.
Page 291 Sensor Installation and Connection 5-85 Place Lower Tab of Bracket on Lag Bolt and Finger-Tightening Bolt Use the level to confirm that the bracket is level side to side. Confirm Level Side to Side Drill a hole through the upper tab using the hammer drill and hammer the Lag Bolt into place.
Page 292 5-86 ADS TRITON+ Manual Confirm Level Front to Back Installed ParaDepth/ParaFlow Wall Mount Bracket...
Page 293 Sensor Installation and Connection 5-87 Stainless Steel Nuts and Washers Behind Mounting Bracket Tab for Leveling Purposes NOTE: In situations where the manhole wall surface is inconsistent/uneven, run stainless steel nuts onto the top and bottom Lag Bolts followed by stainless steel washers before placing the bracket on the bolts.
Page 294 5-88 ADS TRITON+ Manual Attach ParaDepth/ParaFlow Sensor to Sensor Bracket 11. Cable tie the sensor cable to the Sensor Bracket threading the cable ties through the holes along the edge of the Sensor Bracket. Cable Tie Sensor Cable to Sensor Bracket...
Page 295 Sensor Installation and Connection 5-89 Installed Sensor Bracket on Wall Mount Bracket 13. Lock the Sensor Bracket into place by turning the Sensor Bracket Loop clockwise. Measuring the Physical Offset of the Sensor Prior to Exiting the Manhole Once the sensor is positioned on the Topside Wall Mount, measure the Physical Offset of the sensor;...
Page 296 5-90 ADS TRITON+ Manual Directly Measure the Physical Offset Sensor Face to Crown of Pipe = Physical Offset Indirectly Measure the Physical Offset Sensor Face to Invert – Pipe Height = Physical Offset...
Page 297 Sensor Installation and Connection 5-91 Securing Sensor Cable To prevent debris from collecting on the cable during a surcharge vent, ensure the cable is relatively taut so that there is only a small amount of slack in the cable. Coil any extra ParaDepth or ParaFlow cable and use a cable tie secure it to a manhole rung or the monitor handle.
Page 298 5-92 ADS TRITON+ Manual overhead obstructions. Be especially aware of any overhead power lines. Run the Topside Extendable Retrieval Tool down the manhole to the Sensor Bracket; extending the pole as necessary. Run the Topside Extendable Retrieval Tool Down the Manhole...
Page 299 Sensor Installation and Connection 5-93 Position the Hook Through the Loop on the Sensor Bracket Turn the Hook Counter-Clockwise to Loosen and Raise Sensor Bracket As a safeguard, as the sensor is being raised out of the manhole, simultanesouly retreive the sensor cable to minimize the distance the sensor could fall if it comes off the pole hook.
Page 300 5-94 ADS TRITON+ Manual To reinstall, make sure the Sensor Bracket is securely looped on the pole hook, lower the Sensor Bracket down the manhole and seat the Sensor Bracket on the Wall Mount Bracket. Twist the Sensor Bracket loop clockwise to lock the bracket back in place.
Page 301: Securing The Sensor Cables In The Pipe And Manhole
Sensor Installation and Connection 5-95 Securing the Sensor Cables in the Pipe and Manhole Securing the sensor cables from the ring (or band, when applicable), along the pipe crown, and up the manhole helps prevent debris from collecting on sagging cables or between the cables and the pipe crown.
Page 302 5-96 ADS TRITON+ Manual restrict the air tube, causing incorrect pressure depth readings. Secure the cables with a cable tie and plastic anchor every 18 to 24 inches (457 to 610 mm) along the pipe crown (when necessary) from the ring to the manhole. If plastic anchors will not serve as adequate anchors based on the structure of the pipe, install M6 x 55-mm anchor bolts instead.
Page 303: Connecting The Sensors And Sampler To The Monitor
However, to simplify the installation and configuration process, ADS recommends developing a system or convention to ensure consistency when attaching the sensors to the channel ports and assigning the corresponding channels to the sensor devices in...
Page 304 5-98 ADS TRITON+ Manual Place the monitor in an upright position to view the monitor connector ports. Cable connector ports Visually inspect each sensor connector and monitor connector port for damaged or broken pins. Replace a monitor or sensor with defective ports or connectors.
Page 305: Securing The Dryer Tube To The Monitor
Seal any unused connectors with protective caps. If necessary, obtain additional caps from ADS. Note: An air valve is present in the monitor top. This valve exists only for testing purposes during the manufacturing process.
Page 306 5-100 ADS TRITON+ Manual Securing the dryer tube to the monitor using cable ties Make sure the black end cap on the dryer tube is removed before installing the monitor in the manhole. (applies only when a second dryer tube is present) Repeat...
Page 307: Chapter 6 External Power
(XIO , ADS p/n 800-0400) for compliance with IS certification. Note: When installing an ExPAC, XBUS, or XIO, ADS recommends locating the unit in close proximity to the DC power source to maximize the net power available to the unit.
Page 308: Installation
An earth ground rod installed next to the pole/post bonded to the AC distribution device An AC to 24-volt DC converter (i.e., power supply). ADS recommends a power supply available through ADS (p/n 508293), which works with worldwide AC power (94 – 240 VAC, 50 –...
Page 309: Dc Power Requirements And Consumption
9 and 36 volts and a minimum of 15 watts as measured/available at the ExPAC (not at the power source output). ADS offers a power supply (ADS p/n 508293) for this application. However, if you choose not to use this...
Page 310: Mounting The Xio Or Xbus
ADS TRITON+ Manual Monitor Firing Sensors during Measurement Cycle without Wireless Communications 110 mA Monitor Firing Sensors during Measurement Cycle with Wireless Communications Idle 140 mA Monitor Firing Sensors during Measurement Cycle with Wireless Communications Active (<10 milliseconds) 360 mA...
Page 311 External Power mount the XIO/XBUS in a location that prevents tampering or potential damage from occurring. Turn over the XIO/XBUS, and locate the four holes on the back of the unit. Attach the four mounting brackets to the back of the XIO/XBUS using the mounting bracket screws.
Page 312: Mounting The Recommended Power Supply
ADS TRITON+ Manual Mounting the XIO/XBUS to the designated surface or structure Mounting the Recommended Power Supply Note: For applications involving an XIO or XBUS, you can disregard these instructions for mounting the power supply because both the XIO and XBUS come from the factory with the power supply pre-mounted to a DIN rail in the XIO/XBUS enclosure.
Page 313 Note: ADS recommends mounting the power supply and the ExPAC in the same enclosure or in close proximity. The power supply is designed for mounting on a 35- x 7.5-mm DIN...
Page 314 ADS TRITON+ Manual notch at the bottom of the inset from blocking bottom of the DIN rail. Pressing down the sliding tab from the top Push the bottom edge of the rail into the inset on the back of the power supply and release the sliding tab. The spring mechanism will allow the notch to return to its original position, completely securing the power supply to the DIN rail.
Page 315 External Power Power supply firmly secured to the DIN rail Front view of power supply mounted to DIN rail...
Page 316: Mounting The Expac
6-10 ADS TRITON+ Manual Mounting the ExPAC Note: For applications involving an XIO or XBUS, you can disregard these instructions for mounting the ExPAC because both the XIO and XBUS come from the factory with the ExPAC pre-mounted to a DIN rail inside the XIO/XBUS enclosure.
Page 317 External Power 6-11 ExPAC with red mounting tabs – left tab displayed in closed (locked) position; right tab displayed in open (released) position Using a screwdriver to open (release) the red tabs Notice the horizontal inset across the back of the ExPAC. Slide the lower edge of the DIN rail down into the small groove at the bottom of the inset on the back of the ExPAC.
Page 318 6-12 ADS TRITON+ Manual Inserting the lower edge of the DIN rail into the bottom groove on the back of the ExPAC Press the top edge of the DIN rail flush against the back of the ExPAC completely into the inset.
Page 319 External Power 6-13 Press down the red tabs (using your finger or a screwdriver) until they click into place, securing the ExPAC to the DIN rail. Tabs in closed (locked) position, securing the ExPAC to the DIN rail Front view of ExPAC mounted to DIN rail...
Page 320 6-14 ADS TRITON+ Manual Securing the ExPAC using Fasteners If a DIN rail is not available, secure the ExPAC to a solid surface or structure using suitable fasteners (i.e., screws) through the four predrilled holes on the outer edges of the unit.
Page 321: Wiring The Ac Power Source To The Recommended Power Supply
Recommended Power Supply Note: The following instructions apply only when using the ADS XIO, ADS XBUS, or the XP Power power supply recommended by ADS (p/n 508293). This power supply is also used in the XIO and XBUS. When using another third-party power supply, refer to the vendor’s...
Page 322 6-16 ADS TRITON+ Manual XIO/XBUS AC POWER CABLE CABLE GLAND Feeding AC power cable through XIO/XBUS cable gland Note: When positioning the cable inside the XIO, XBUS, or other enclosure, maintain a small space between the cable and the right side of the ExPAC.
Page 323 External Power 6-17 POWER SUPPLY AC TERMINAL BLOCK Location of AC input terminal block on power supply Connect the power cable wires to the terminals on the power supply by running each wire through the appropriate terminal hole in the bottom of the power supply and tightening the corresponding terminal screw: Connect the hot (typically black or red) wire from the power cable to the line (L) terminal on the power supply.
Page 324: Wiring The Power Supply To The Expac
XIO or XBUS. The next step in connecting the monitor to external power involves running two wires between the power supply and the ExPAC. ADS recommends using 18- to 22-gauge stranded wire. However, for runs longer than 20 feet, use 14-gauge wire.
Page 325 External Power 6-19 Connect the wires to the power supply and the ExPAC in the following way: Strip the individual wires on both ends to prepare for connecting to the terminals on the hardware. Loosen the screws on one of the –V and one of the +V DC output terminals (front, top corner) on the power supply.
Page 326 6-20 ADS TRITON+ Manual Loosen the screws on the +, -, and DC INPUT terminal connector on the ExPAC (top, right). Refer also to the wiring label on top of the ExPAC. DC input terminals on ExPAC Insert the end of one wire into the hole corresponding to the –V DC output terminal on the power supply, and tighten the associated terminal screw.
Page 327 External Power 6-21 Wires exiting DC output terminal on power supply...
Page 328: Running The Ground Wires
6-22 ADS TRITON+ Manual Positive and negative wires entering DC input terminal connector on ExPAC Running the Ground Wires Ground wires are required for all external power applications: one running from the ExPAC to the earth ground and one running from the ExPAC to the monitor.
Page 329 For the ground wire that runs between a ground terminal block and the existing earth ground, ADS recommends using at least a 12-gauge ground wire. For applications that do not include the XIO or XBUS, you must...
Page 330 6-24 ADS TRITON+ Manual Loosen the screw corresponding to the earth ground ( terminal on the DC INPUT terminal connector on the ExPAC. Insert one end of the 18-gauge ground wire into the terminal, and tighten the screw. 18-gauge ground wire inserted into DC input terminal on ExPAC Loosen the terminal screw corresponding to the top terminal of one of the new ground terminal blocks.
Page 331 External Power 6-25 Inserting the 18-gauge ground wire into the top terminal of one of the ground terminal blocks Loosen the terminal screw corresponding to the bottom terminal of one of the ground terminal blocks next to the ExPAC, and insert one end of the 12-gauge ground wire into the terminal and tighten the screw.
Page 332 6-26 ADS TRITON+ Manual Securing the 12-gauge ground wire into one of the ground terminal blocks Run the free end of the 12-gauge ground wire through the cable gland on the right (for the XIO/XBUS) or through an available cable exit route from the inside of the existing enclosure. The cable gland referenced for the XIO/XBUS is the same gland through which the AC power cable enters the unit.
Page 333 Run the free end (without the ring terminal) of the 10-gauge ground wire (from the external power grounding kit, ADS p/n 8000-0434-xxx) up through the cable gland on the right (on the XIO/XBUS) or up through an available cable route from the outside of the existing enclosure.
Page 334 6-28 ADS TRITON+ Manual Loosen the terminal screw corresponding to the bottom terminal of the other ground terminal block next to the ExPAC, and insert the free end of the 10-gauge ground wire into the terminal and tighten the screw.
Page 335: Wiring The Expac/Xbus/Xio To The Monitor
(ADS p/n 8000-0378-xx) and ground cable (from the external power grounding kit, ADS p/n 8000-0434-xxx) between the ExPAC, XBUS, or XIO and the monitor. One end of the external power/communication cable has a metal connector for connection directly into the monitor’s communication/external power port...
Page 336 6-30 ADS TRITON+ Manual cable entry point into the other enclosure, as applicable, from the outside of the unit/enclosure. XIO/XBUS COMMUNICATIONS CABLE CABLE GLAND Communications cable coming through the middle cable gland at the bottom of the XIO/XBUS Loosen all of the COMMS and DC OUT terminal screws on the bottom of the ExPAC.
Page 337 External Power 6-31 Wiring communications cable to COMMS terminal connector on ExPAC Insert the COMMS terminal block connector back into the corresponding port on the ExPAC, when applicable. Insert the heavier gauge (i.e., larger diameter) red and black wires into the associated RED and BLK terminals on the DC OUT terminal block connector, and tighten the corresponding terminal screws.
Page 338 6-32 ADS TRITON+ Manual Wiring communications cable to DC OUT terminal connector on ExPAC Insert the remaining lighter gauge clear wire into the SHL terminal on the DC OUT terminal block connector, and tighten the corresponding terminal screw. Insert the DC OUT terminal block connector back into the corresponding port on the ExPAC, when applicable.
Page 339 External Power 6-33 Monitor communication cable running through middle cable gland with plastic nut on XIO or XBUS 11. Run the communication cable and the ground wire (with the ring terminal) to the monitor location. 12. Remove the bolt adjacent to the COMM + EXT PWR and ANTENNA ports from the monitor top using a 13-mm nut driver.
Page 340 6-34 ADS TRITON+ Manual 15. Slide the ring terminal from the ground wire onto the bolt (with the crimp barrel on the ring terminal facing the head of the bolt), and then slide the washer with the guide tabs and the internal-tooth washer back onto the bolt.
Page 341 19. Attach the other end of the communication cable to the COMM + EXT PWR port on the top of the monitor. If the monitor will be in a manhole, ADS recommends wrapping rubber stretch tape around the entire cable connection,...
Page 342: Final Instructions
6-36 ADS TRITON+ Manual COMM + EXT PWR CABLE COAXIAL Stretch Tape to XIO, XBUS, or ExPAC Enclosure 10-Gauge Ground Wire COMM + EXT PWR Port TRITON+ MONITOR External power/communication cable attached to COMM + EXT PWR port and ground wire secured to bolt on top of monitor...
Page 343 External Power 6-37 Verify that the ON LED is illuminated on the power supply (when applicable) and that both the ExPAC DC IN and DC OUT LEDs also are illuminated. For more information on locating and interpreting the LEDs on the ExPAC, refer to Chapter 10, Maintenance and Troubleshooting.
Page 344: Chapter 7 Monitor Installation
Therefore, installers and technicians must comply with all federal, state, and municipal regulations concerning confined space entry. ADS is not responsible for any injuries, damages, claims, or liability resulting directly or indirectly from the...
Page 345 ADS TRITON+ Manual use of this installation guide or the installation of any ADS equipment.
Page 346: Mounting The Monitor On Manhole Rung
Rung The simplest way to mount a monitor in a manhole is to attach it to a rung. TRITON+ monitors come with a standard hook (ADS p/n 8000-0021) for this purpose. Make sure the rungs are capable of holding the weight of the monitor and cables.
Page 347: Mounting The Monitor To The Manhole Wall
If the project will involve measuring flow over a long period of time, consider mounting the monitor permanently to the manhole wall. Using a monitor mounting bracket/flange (ADS p/n I40- 0009), you can hang the monitor more securely and out of the way to allow use of the rungs.
Page 348 Monitor Installation Twist a nut onto the anchor bolt, but do not tighten it down. Leave enough space between the nut and the wall for the thickness of the mounting bracket. Mount the bottom of the bracket onto the monitor mounting flange with two M8 x 30-mm stainless steel bolts, two M8 stainless steel lock washers, and two M8 stainless steel flat washers (supplied with the TRITON+ when shipped).
Page 349 ADS TRITON+ Manual Note: ADS strongly recommends attaching a security line to the monitor before lowering it into the manhole to prevent the monitor from accidentally dropping down the manhole during installation. Tighten and secure the bolt against the mounting bracket.
Page 350: Mounting The Monitor To The Manhole Rim
However, the manhole lid must clear the mounting hardware while it is removed or replaced. Mount the monitor bracket/flange (ADS p/n I40-0009) to the manhole rim in the following way: Determine the appropriate location to mount the monitor handle to the inside of the iron manhole rim.
Page 351 ADS TRITON+ Manual Note: Consider starting the hole using smaller bits to make pilot holes and increasing up to the final size bit. In addition, spray cutting oil or another lubricant into the hole while drilling and tapping. Drilling the hole in the manhole rim Use a 3/8-inch x 16 threads-per-inch (10-mm) tap that matches the stud thread to cut threads in the hole.
Page 352 Monitor Installation Using the tap to thread the hole Chase the threading action at intervals to clear the metal debris by backing the tap almost completely out of the hole and then screwing it back into the hole. Lubricate the hole between threading.
Page 353 7-10 ADS TRITON+ Manual Using two wrenches, turn the inner nut counter-clockwise and the outer nut clockwise simultaneously to bind the two nuts together on the stud. Binding the nuts together with the washer in between Install the stud into the tapped hole using the outer nut to engage the wrench.
Page 354 13. Carefully lower the monitor into the manhole, and place the keyhole in the bracket over the outer nut on the stud. Note: ADS strongly recommends attaching a security line to the monitor before lowering it into the manhole to prevent the monitor from accidentally dropping down the manhole during installation.
Page 355 7-12 ADS TRITON+ Manual 15. Neatly coil and secure the excess sensor and communication cables in the manhole to simplify future monitor service activities. Secure the cables to plastic anchors or ¼-inch x 2¼- inch (M6 x 55-mm) anchor bolts using 14-inch (300-mm) cable ties.
Page 356: Chapter 8 Inclinometer
(angle opening) of a flood gate in water control management systems. The sensor connects to the COMM + EXT PWR port on the ADS TRITON+ monitor. Install the Inclinometer when the flood gate is in the closed position. Once...
Page 357: Installing The Inclinometer
Follow the steps below to install the ADS Inclinometer sensor. Note: The Inclinometer sensor should not be connected to the ADS TRITON+ monitor until it is installed onto the flood gate. Note: If the default 25’ (7.6m) length of the Inclinometer cable is not sufficient for the installation, order an extension cable (ADS P/N 8000-0044-25).
Page 358 Inclinometer...
Page 359 ADS TRITON+ Manual Before securing the Inclinometer to the flood gate, ensure that the sensor is at 90º, 180º, or completely flat. Inclinometers installed in the positions shown below will not record accurate angle measurement data. Improper Inclinometer installation positions...
Page 360 Inclinometer Construction adhesive Inclinometer attached using Construction Adhesive Two #8 stainless steel screws (hole diameter = 4.67 mm (0.184 in) Inclinometer attached using Stainless Steel Screws...
Page 361: Inclinometer Data
After the Inclinometer is securely attached to the flood gate, connect the sensor cable to the COMM + EXT PWR port on the top of the ADS TRITON+ monitor. Configure the ADS TRITON+ monitor using Qstart selecting the Inclinometer as one of the devices. See...
Page 362 Inclinometer The ANGLE data will be negative values when the gate opens out to the receiving body of water. ANGLE will be positive values when the gate opens inward toward the wastewater collection system: ANGLE data will be positive values when the gate opens out to the receiving body of water.
Page 363 ADS TRITON+ Manual ANGLE data will be negative values when the gate opens out to the receiving body of water. ANGLE data will be positive values when the gate opens inward towards the wastewater collection system:...
Page 364: Chapter 9 Analog And Digital Inputs And Outputs
The interface between the monitor and this equipment is the ADS XIO (external input/output unit). The XIO can accommodate up to 2 analog inputs, 2 analog outputs, 2 digital inputs, and 2 digital outputs.
Page 365 ADS TRITON+ Manual acquiring a qualified electrician, instrumentation technician, or owner representative to connect ADS equipment to the signal source. Consider the examples and general procedures included in this chapter to ensure a successful installation.
Page 366: Analog Inputs
Analog and Digital I/O 9-3 Analog Inputs The TRITON+ (with an ADS XIO) supports the monitoring of up to two analog 4-20mA signals from other instruments. These signals typically represent measurements made by other devices, such as flow meters, pressure sensors, or level transducers. To...
Page 367 Refer to Chapter 4, Configuration and Activation, for instructions on supplying this information in Qstart Connect the analog input wires to the ADS XIO in the following way: Note: Make sure the power is turned off to the third-party device and XIO.
Page 368 Analog and Digital I/O 9-5 XIO MODULE CABLE GLAND 2 WIRES Feeding wires up through left cable gland in XIO Insert one of the stripped ends of the positive wire into the hole corresponding to terminal 1 (or 3) on the I/O terminal block in the XIO.
Page 369 Restore power to the customer’s instrument or device and the ADS XIO. Verify that adding the ADS equipment will not add too much load to the analog signal loop. The XIO input adds 22 ohms to the loop. If too much load is added, the signal...
Page 370 Analog and Digital I/O 9-7 Determine whether too much load exists on the analog signal in the following way: Activate the monitor with the appropriate analog input parameters. Request for the owner to simulate a full-scale event that generates a signal to 20mA while connected to the XIO unit.
Page 371: Analog Outputs
ADS Client Services. Perform the following procedure to connect each third-party device (up to two) to an analog output terminal on the ADS XIO: Note: Make sure external power is available, but not turned on, to the monitor before connecting the signal wiring.
Page 372 4-20mA from the TRITON+. Connect the analog output wires (from the customer- supplied cable) to the ADS XIO in the following way: Note: Make sure the power is turned off to the third-party device and XIO.
Page 373 9-10 ADS TRITON+ Manual XIO MODULE CABLE GLAND 2 WIRES Feeding wires up through left cable gland in XIO Insert one of the stripped ends of the positive wire into the hole corresponding to terminal 5 (or 7) on the I/O terminal block in the XIO.
Page 374 Close and latch the door to the XIO. Restore power to the customer’s device and the ADS XIO. Run a test to verify that the third-party instrument is receiving a correct value from the monitor in the following way:...
Page 375 9-12 ADS TRITON+ Manual Click on the OK button on the XIO Device dialog. Activate the monitor. Refer to Chapter 4, Configuration and Activation, for instructions on activating the monitor. Disconnect from the monitor. Contact the customer representative to verify the receiving instrument is producing the same value.
Page 376: Digital Inputs
Input on the XIO Perform the following procedure to connect each third-party device (up to two) to a digital input terminal on the ADS XIO: Note: Make sure external power is available, but not turned on, to the monitor before connecting the signal wiring.
Page 377 ADS TRITON+ Manual Run the wires up through the left cable gland on the XIO into the enclosure. ADS recommends using 18-gauge wiring. You may need to loosen the plastic nut on the cable gland on the outside of the XIO to feed the wires through.
Page 378 Close and latch the door to the XIO. Restore power to the customer’s device and the ADS XIO. Test the digital inputs in the following way: Make sure the monitor is activated with the appropriate digital input parameters.
Page 379: Digital Outputs
ADS TRITON+ Manual Digital Outputs The TRITON+ (with an ADS XIO) can provide the event status for to up to two third-party systems or devices via digital (relay) output signals. To configure the monitor to properly deliver the signals to...
Page 380 Analog and Digital I/O 9-17 Connect the digital output wires to the ADS XIO in the following way: Note: Make sure the power is turned off to the third-party device and XIO. Release the latches and open the clear, front door on the XIO.
Page 381 (digital output terminals) on the I/O terminal block Connect the other ends of the wires to the third-party device based on the vendor’s specifications. Close and latch the door to the XIO. Restore power to the customer’s device and the ADS XIO.
Page 382 Analog and Digital I/O 9-19 Test the digital outputs in one of the following ways, and then verify that the customer’s device received the change in relay status: Adjust your event triggers in Qstart to force an event and subsequent return-to-normal to occur over a limited period of time.
Page 383: Chapter 10 Modbus
® instruments, such as the Telog Ru-33 or Ru-35, may be ® used in place of an RTU. ADS references the RTU in this manual primarily because it is the most common type of end-point hardware used with SCADA systems.
Page 384: Establishing A Modbus Connection
The SCADA or process control system connects to the TRITON+ either through a customer-supplied serial cable connection using the ™ ADS ExPAC (which may be housed within the ADS XBUS or a customer-supplied enclosure) or through a cellular wireless modem in the monitor using Modbus TCP.
Page 385 Modbus 10-3 Connect the cable to the ExPAC in the following way: Disconnect (i.e., unplug) the green terminal connector from the RS-485 port on the top, left side of the ExPAC. RS-485 terminal connector on ExPAC (applicable only when the ExPAC is housed within an XBUS or other enclosure) Open the door of the enclosure and run the cable through the appropriate entry point into the enclosure.
Page 386 10-4 ADS TRITON+ Manual XBUS CABLE GLAND RS-485 CABLE Running RS-485 cable through left cable gland in XBUS Loosen the screws on the terminal connector. Make sure the wires from the cable are stripped and separated. Insert the negative wire (D-) from the cable into the negative (-) terminal on the connector (refer to the label adjacent to the port) and tighten the terminal screw.
Page 387 Modbus 10-5 Running the wires to the proper terminals on the RS-485 terminal connector Insert the connector back into the RS-485 port on the ExPAC. Note: Refer to the manufacturer’s documentation for the device to which you are connecting the ExPAC to determine the appropriate pin-out for the RS-485 connector on the device end of the cable.
Page 388 10-6 ADS TRITON+ Manual Connecting through the RS-232 Port When supporting an RS-232 Modbus connection to customer equipment, such as an RTU or PLC, create a custom cable or use a customer-supplied serial cable with a DB-9 connector configured to an RS-232 straight connection specification.
Page 389 Modbus 10-7 XBUS CABLE GLAND RS-232 CABLE Running RS-232 cable through left cable gland in XBUS (applicable only when using a custom cable or after removing a DB-9 connector from a pre-fabricated cable) Strip and separate the wires from the cable and attach/re-attach the DB-9 connector to the cable based on the pin-out referenced in the following table: Name...
Page 390 10-8 ADS TRITON+ Manual Name Direction Notes Unused Pin-out for RS-232 Modbus port on the ExPAC Note: A logic high is required on either DCD or DTR to enable communications. Insert the DB-9 connector from the cable into the RS-232 port on the top of the ExPAC.
Page 391: Setting Up A Wireless Connection
Modbus registers to the SCADA or process control system. Consider the following when using a wireless connection: While not required, ADS strongly recommends powering the TRITON+ for any continuous Modbus communications through an external source using an ExPAC or XBUS.
Page 392: Configuring The Monitor For Modbus Applications
10-10 ADS TRITON+ Manual Configuring the Monitor for Modbus Applications The monitor must be configured with certain information to ensure it can communicate with and provide data to the RTU, Telog Ru- 33, Ru-35, or Wavelet 4R. This includes information such as the...
Page 393: Modbus Data Registers
Modbus Read Holding Register command, use an address of 0 (zero), which will return data for register 40001. ADS uses two Modbus registers to return one little endian floating point number. Registers that are not updated by the monitor will contain a value of -99.0.
Page 394 10-12 ADS TRITON+ Manual A typical message exchange, asking for the first 10 registers, would occur as follows: 000064-Tx:3A 30 35 30 33 30 30 30 30 30 30 30 41 45 45 OD 000065-Rx:3A 30 35 30 33 31 34 30 30 30 30 43 32 43 36...
Page 395 Modbus 10-13 Description Standard Units of Registers Qstart Entity Measure Smart Depth SDEPTH_3 Inches 40019-40020 from the Surface Combo or Ultrasonic Depth Sensor Pressure Depth PDEPTH_3 Inches 40021-40022 from the Surface Comb Sensor Air Temperature AIRTEMP_3 Fahrenheit 40023-40024 from the Surface Combo Sensor Flow rate based FLOW1...
Page 396 10-14 ADS TRITON+ Manual Description Standard Units of Registers Qstart Entity Measure Unidepth, MP1/UD Inches 40045-40046 Monitoring Point Velocity with MP1/RV1 Feet per Second 40047-40048 gain applied, Monitoring Point Flow rate based MP1/FLOW1 Millions of Gallons 40049-40050 on QContinuity, per Day...
Page 397 Modbus 10-15 Description Standard Units of Registers Qstart Entity Measure Velocity with MP2/RV2 Feet per Second 40067-40068 gain applied, Monitoring Point Flow rate based Millions of Gallons MP2/FLOW2 40069-40070 on QContinuity, per Day Monitoring Point Flow volume, MP2/FLOW_TOTAL Thousands of 40071-40072 Monitoring Point Gallons...
Page 398 10-16 ADS TRITON+ Manual Register Addresses for Monitor Information The following table contains the registers corresponding to more general monitor information: Description Standard Units of Measure Registers Depth Conversion Coefficient Inches 40137-40138 Velocity Conversion Feet Per Second 40139-40140 Coefficient Volume Conversion...
Page 399: Chapter 11 Maintenance And Troubleshooting
C H A P T E R 11 Maintenance and Troubleshooting ® While the ADS TRITON+ flow monitor and sensors are designed for dependability and durability, all electronic devices are vulnerable to wear, malfunction, or failure, particularly in a harsh sewer environment.
Page 400: Maintaining The System Components
(i.e., quarterly or during battery pack replacement). Note: The only service or maintenance activities ADS permits within the monitor chassis are battery pack battery PCB, regulator/modem unit, and fuse replacement.
Page 401: Inspecting The Monitor
Maintenance and Troubleshooting 11-3 Compressed air Flat head screwdriver and assorted wrenches Rubber stretch tape Blue magnet (for troubleshooting wireless communications) Inspecting the Monitor Perform the following inspections during site visits or from a remote location (when applicable): Inspect the monitor mounting bracket to verify that the bracket and bolts are free of heavy corrosion and the bolts are tightened and secure.
Page 402 11-4 ADS TRITON+ Manual Make sure all connector ports on the monitor top are dry. Use compressed air or paper towels to dry out wet or damp connectors. Note and replace missing interfacial seals in the sensor connector ends. The connectors can be protected against moisture by wrapping with self-vulcanizing rubber stretch tape.
Page 403 Maintenance and Troubleshooting 11-5 Sample Uploaded Configuration Log Obtaining (Uploading) the Monitor Configuration Uploading the monitor’s current configuration parameters can assist in monitor troubleshooting. The uploaded monitor information shows the information currently stored in the monitor’s memory― current device configuration and installation details. This information can be useful to review prior to performing a monitor activation to verify the monitor location information matches the computer location information.
Page 404 11-6 ADS TRITON+ Manual numbers/characters which, once initialized, display in a sequence and represent current processes, identification, status, or readings associated with the system and communications. The following sections contain general descriptions and interpretations of the diagnostic information available through the LED and instructions for accessing information or prompting a message.
Page 405 Perform the following steps to initiate the LED diagnostic codes: Hold the ADS magnet against the red dot located next to the WAKE label for several seconds. Move the magnet away from the monitor once the flashing displays in the LED window.
Page 406 11-8 ADS TRITON+ Manual Codes Initiate after Removing Magnet from Contact with Monitor Top Upon activation, interpret the diagnostic codes in succession in the following way: Note: Certain diagnostic information may not be relevant or available based on the type of communication used by the monitor.
Page 407 Testing the Monitor Cryout Capability You can test the monitor’s ability to perform a cryout, representing a system event or alarm, to an ADS hosted software system (when applicable) by holding the magnet against the red dot (labeled WAKE) adjacent to the LED window on the monitor top for more than 5 seconds and then releasing the magnet from the top.
Page 408 11-10 ADS TRITON+ Manual Check the current battery voltage in the monitor through Qstart in the following way: Note: Checking the battery voltage through the monitor status in Qstart for monitors equipped with dynamic SIM cards is possible only through a serial (direct) connection.
Page 409 Hangup button in the Functions section to discontinue communication with the monitor. Replacing the Monitor Battery Pack Note: The only service or maintenance activities ADS permits within the monitor chassis are battery pack, battery PCB, regulator/modem unit, SIM card replacement (as applicable) and fuse replacement.
Page 410 Warning: The TRITON+ can receive internal power only from the ADS 12-volt IS battery pack (p/n 8000- 0043-02/04). Do not use any other battery or power source to power the monitor internally.
Page 411 Maintenance and Troubleshooting 11-13 Collect the data from the monitor (remotely or on-site). This will reduce the risk of data loss once the battery is disconnected. Remove the monitor from the manhole, and disconnect the following cables as applicable: Antenna cable from the ANTENNA port on the monitor Sensor cable(s) from the corresponding port(s) on the monitor...
Page 412 11-14 ADS TRITON+ Manual Viewing 12-volt battery pack in monitor canister from top Place the top next to the canister, and then disconnect the battery cable from the dome cable and set the top/power regulator dome assembly aside. However, do not disconnect the battery cable while the monitor is awake (e.g., taking...
Page 413 Maintenance and Troubleshooting 11-15 Placing the top next to the monitor (left) and disconnecting the cables at the plastic white connectors (right) Lift out the battery pack from the canister using the white handle (band) attached to the top of the pack. 12-volt battery pack outside canister (with retainer plug on top)
Page 414 11-16 ADS TRITON+ Manual Lift off the retainer plug from the top of the battery pack, and disconnect the PCB from the battery pack in the following way: 12-volt battery pack without retainer plug Carefully move the thick red band securing the PCB to the side of the battery pack off of the PCB.
Page 415 Maintenance and Troubleshooting 11-17 Disconnecting the PCB from the battery pack Set the PCB temporarily aside in a clean, dry location. Do not discard! This PCB will be used with the replacement battery pack. 10. Connect the PCB to the replacement battery pack and then secure the PCB to the side of the pack with the red band.
Page 416 11-18 ADS TRITON+ Manual 13. Coil the excess cabling around the inner wall of the canister, and carefully lower the top/dome assembly back onto the canister. Keeping the proper orientation between the canister and the top is critical to maintaining the watertight and airtight seal on the monitor.
Page 417 Maintenance and Troubleshooting 11-19 14. Finger-tighten the top bolts to make sure the top and gasket are seated properly. Then, tighten the bolts about halfway to full torque value by tightening the opposite bolts. Finally, tighten the bolts to approximately 30 inch-pounds (2.50 foot-pounds/ 3.39 Nm) to fully secure the top to the canister.
Page 418: Inspecting, Cleaning, And Handling The Sensors
11-20 ADS TRITON+ Manual 18. Reconnect the sensor cable(s) to the appropriate port(s) (Channel 1 and/or Channel 2) on the monitor. Inspecting, Cleaning, and Handling the Sensors Perform the following sensor inspections during regular site visits: Verify that the installation ring, bands or Mounting Bar are secure and clear of debris.
Page 419 Replacing the Dryer Tube Replace the pressure depth sensor dryer tube (ADS p/n 3704-0032) in the following way: Clip the cable ties securing the dryer tube to the monitor.
Page 420 The desiccant beads of the appropriate size for this dryer tube are available through ADS (p/n 901-11055-00). Replace the desiccant in the following way: Clip the cable ties securing the dryer tube to the monitor, when applicable.
Page 421 Maintenance and Troubleshooting 11-23 Free end of dryer tube with inset nut Warning: Do not attempt to access the desiccant in the dryer tube through the end of the tube with the brass fitting! This fitting is not designed for removal. Removing the fitting will damage the dryer tube and break the moisture seal on that end of the tube.
Page 422: Replacing The Sim Card
Replacing the SIM Card in Monitors with a SIM Card Enclosure on the Monitor Top Replace the SIM card (ADS p/n 8000-0560-ASIM (AT&T), 8000- 0561-VSIM (Verizon), or customer-supplied) in monitors with a SIM Card enclosure on the monitor top in the following way:...
Page 423 Maintenance and Troubleshooting 11-25 Remove the monitor from the manhole, and place it in a dry, clean location (i.e., an adequate distance away from the manhole). Wipe away any debris or moisture that could enter the SIM card enclosure on the monitor top once the cap is removed from the enclosure.
Page 424 Qstart software and provide the ICCID number to ADS (or customer network provided) to activate the new SIM card. The IP address is printed directly on the SIM card or on a label affixed to the card.
Page 425 Maintenance and Troubleshooting 11-27 Empty SIM card holder showing pressure valve (left); inserting the SIM card properly into the holder SIM card properly seated and secured in the holder 10. Replace the cap onto the SIM card enclosure, and snap the locks in place to secure the cap.
Page 426 (or the network service provider). Include the last four (4) digits SIM ICCID number and modem IMEI number. Wait for return email from ADS (or the network service provided) that the SIM has been activated. The email will contain the IP address (for static IPs) and its associated phone number.
Page 427 Maintenance and Troubleshooting 11-29 components inside the monitor. Such actions will void the monitor warranty agreement and the IS certification. Note: Move the monitor away from the hazardous area before opening the monitor to replace the battery. Replace the SIM card in the TRITON+ monitor with no SIM card enclosure on the monitor top in the following way: Collect the data from the monitor (remotely or on-site).
Page 428 11-30 ADS TRITON+ Manual Placing the top next to the monitor (left) and disconnecting the cables at the plastic white connectors (right) Place the top next to the canister, and then disconnect the battery cable from the dome cable and set the top/power regulator dome assembly aside.
Page 429 Maintenance and Troubleshooting 11-31 Dome-securing Nut Removing nut securing regulator dome to monitor top Carefully lift off the dome from the top (as if opening like a book). SIM Card Holder Open Regular/Modem Bowl Showing Internal SIM Card Holder 10. The SIM card holder in the enclosure functions based on spring action.
Page 430 11-32 ADS TRITON+ Manual 11. Slide the SIM card completely out of the holder. 12. (applies only when using SIM cards with static IP addresses) Record the number of the new SIM card (i.e., the IP address). You will need this address to update the XML in the Qstart software.
Page 431 Maintenance and Troubleshooting 11-33 Returning the monitor top to the proper orientation with the canister – Align COMM+EXT PWR Connector with the backside of canister and molded mounting flange. 17. Finger-tighten the top bolts to make sure the top and gasket are seated properly.
Page 432 (or the network service provider). Include the last four (4) digits SIM ICCID number and modem IMEI number. Wait for return email from ADS (or the network service provided) that the SIM has been activated. The email will contain the IP address (for static IPs) and its associated phone number.
Page 433: Replacing The Fuses In The Monitor
The regulator board has three fuses, indicated by three color-corresponding LED lights on top of the monitor, (ADS p/n 508071, 508072, and 508073) that may be replaced independently upon failure. The 5-volt blue fuse corresponds to the sensors and can be blown due to a shorted sensor.
Page 434 (i.e., not shorted) using a voltmeter. If the sensor is shorted, it also will blow the newly replaced 5-volt fuse or the existing 5-volt fuse in the other monitor. Please contact ADS Client Services for detailed instructions on determining whether a sensor has shorted.
Page 435 Maintenance and Troubleshooting 11-37 Remove the top (with the attached power regulator dome) by pulling it straight up from the canister. 10. Place the top upside down next to the canister (with the dome facing upward), and then disconnect the battery cable (when applicable) from the dome cable.
Page 436 11-38 ADS TRITON+ Manual Dome-securing Nut Removing nut securing regulator dome to monitor top 12. Carefully lift off the dome from the top (as if opening like a book). Notice the three fuses seated on the regulator board on the inside of the dome.
Page 437 Maintenance and Troubleshooting 11-39 Close up of regulator board showing the three color-coded fuses Blue fuse removed from the regulator board 14. Carefully insert the new, replacement fuse(s) into the corresponding holes in the dome without bending the fuse filaments. Verify that the color strip on the fuse matches the color on the regulator board adjacent to the holes.
Page 438 11-40 ADS TRITON+ Manual 16. (applicable only to battery-powered monitors) Reconnect the battery cable to the cable exiting from the hole in the top/dome assembly. 17. Coil the excess cabling around the inner wall of the canister (when applicable), and carefully lower the top/dome assembly back onto the canister.
Page 439 Maintenance and Troubleshooting 11-41 Returning the monitor top to the proper orientation with the canister – Align COMM+EXT PWR Connector with the backside of canister and molded mounting flange. 18. Finger-tighten the top bolts to make sure the top and gasket are seated properly.
Page 440: Interpreting The Diagnostic Led Codes On The Expac
11-42 ADS TRITON+ Manual EXT PWR port on the monitor. Restore power to the monitor from the external source. 21. Establish communication with the monitor remotely to verify communication. 22. Rewrap rubber stretch tape around the entire cable connection between the antenna and ANTENNA port, extending 1 to 2 inches (25 to 50 mm) onto the cable beyond the connection.
Page 441 Maintenance and Troubleshooting 11-43 Color State Description DC IN (D21 next to P3 Yellow Device powered, 9 to 36 Device not powered I.S. DC OUT (D20 next Yellow TRITON+ power on to P4 TRITON+ power off TX (to communication Blue Flashing Transmitting data to port)
Page 442: Troubleshooting
11-44 ADS TRITON+ Manual Troubleshooting The TRITON+ flow monitor contains several different components that perform many different functions. Since a malfunctioning component increases the risk of losing data, isolating the problem component is essential to performing troubleshooting activities efficiently. Minimizing monitor downtime is critical.
Page 443: General Monitor Problems
Then, send the monitor to ADS for repair. This section provides general guidelines for troubleshooting and correcting problems with the TRITON+ monitor and sensor subsystems.
Page 444 Qstart the Status in . If the signal strength indicated is less than -95 (for example: -99), consider re-orienting the antenna and/or installing the antenna in a pedestal above ground. Contact your regional ADS representative. Replace the modem if defective.
Page 445 Monitor firmware file may be corrupt. Check monitor time, and reset clock if necessary. Possible Solutions Attempt to collect data within the gap. Contact your regional ADS representative. Problem Data is missing at the beginning or end of the date range following data collection. Possible Monitor activation may have failed.
Page 446 Replace the 3.3-volt (yellow) fuse on the regulator. If the monitor is logging data only during monitor communications following a firmware upgrade, contact your ADS regional representative to clear the monitor memory and reactivate the monitor. Contact your regional ADS representative.
Page 447: Communication Problems
Antenna may be defective. Antenna may not be attached to the monitor. Antenna may not be installed correctly. Monitor may not be on the ADS VPN network. Monitor may be defective. Modem may be defective. 3.3-volt fuse on regulator may have blown.
Page 448 IP addresses and/or none of the wireless connections are successful, there may be a wireless network outage in your area. Contact your regional ADS representative for them to investigate a possible outage. Delete any leading zeros included before or within the IP address.
Page 449 Verify that the communication type is set to Wireless. Solutions Connect directly with the monitor using a USB Serial Interface cable (ADS p/n 8000-0337). Verify the monitor responds. If it does, the modem might be faulty. If it does not, remove the monitor from the hazardous area...
Page 450 20 feet away from the manhole), disconnect the battery pack, wait at least 1 minute, reconnect the battery pack, and then attempt to communicate. If the monitor still will not communicate, replace the 3.3-volt yellow fuse on the regulator. Contact your regional ADS representative.
Page 451: Long Range Depth Subsystem
The following tables contain general troubleshooting techniques for problems with the ultrasonic depth subsystem corresponding to the Long Range Depth Sensor. Note: Contact your ADS representative for further diagnosis prior to replacing a sensor or monitor. Problem Depth measured not matching invert flow levels Manhole depth is greater than sensor range (20 feet).
Page 452 11-54 ADS TRITON+ Manual Problem Depth measured remains a constant value. Possible Sensor may be positioned incorrectly over invert and/or incorrectly reading a stationary object (rung, bench, etc.) Causes in the manhole structure. Sensor level is incorrect and not measuring invert depth.
Page 453: Ultrasonic Depth Subsystem
ParaDepth, ParaFlow, Surface Combo Sensor and the Ultrasonic Depth Sensor. Note: Contact your ADS representative for further diagnosis prior to replacing a sensor or monitor. Problem Range from ultrasonic depth subsystem is slightly inconsistent with manually measured range.
Page 454 Make sure the sensor is level and in good condition. Check the hydraulic conditions in the pipe. Fire the sensor at a shorter distance onto a hard surface to confirm accuracy. Clean/dry the sensor. Replace the sensor. Contact your regional ADS representative.
Page 455 Verify the pipe height. Solutions Verify electronic offset and adjust if necessary. Clean the sensor. Replace the sensor. Contact your regional ADS representative. Problem Raw ultrasonic depth data shows depths greater than the pipe diameter. Possible Physical offset may be incorrect.
Page 456 Verify the physical offset and the pipe height. Possible Solutions Verify electronic offset and adjust if necessary. Clean the sensor. Contact your regional ADS representative. Replace the sensor. Replace the monitor if defective. Problem Ultrasonic depth readings are erratic. Noise may exist in the sewer pipe.
Page 457 Maintenance and Troubleshooting 11-59 Problem Individual ultrasonic depth readings (SDEPTH_3) from ParaDepth, ParaFlow, Surface Combo Sensor/Ultrasonic Depth Sensor are consistently equivalent to the value obtained from the following equation: Pipe Height – Physical Offset + 9.99. Possible Sensor may be faulty. Causes 5-volt (blue) fuse on regulator may have blown.
Page 458: Upward Depth Subsystem
The following tables contain general troubleshooting techniques for the upward depth subsystem corresponding to the AV|Gated, AV|Max and Peak Combo sensor. Note: Contact your regional ADS representative for further diagnosis prior to replacing a sensor or monitor. Problem UpDepth data periodically reads 0.88 inches (22 mm).
Page 459 Solutions Check the sensor connections. Ensure the sensor is installed as closely as possible to the 6:00 position in the pipe, silt allowing. Contact your regional ADS representative. Replace the sensor. Replace the monitor if defective. Problem UpDepth readings are abnormally low.
Page 460 11-62 ADS TRITON+ Manual Problem Individual UpDepth_1 (_2) values consistently read - 9.99. Possible Sensor may be faulty. Causes 5-volt (blue) fuse on regulator may be blown. Possible Replace the Peak Combo Sensor. Solutions Replace the 5-volt blue fuse on the regulator.
Page 461: Peak Velocity Subsystem
Since the Surface Combo sensor is mounted at the top of the pipe, potential issues involving a sensor that is out of the flow do not apply to the Surface Combo sensor. Note: Contact your regional ADS representative for further diagnosis prior to replacing a sensor or monitor. Problem Monitor often provides a velocity reading of 0.
Page 462 Peak Combo Sensor). Velocity function may be broken. Possible Clean the sensor’s transmit/receive surfaces. Solutions Verify that minimum flows are occurring outside the sensor deadband. Check the sensor connections. Check the velocity parameters. Contact your regional ADS representative. Replace the velocity sensor.
Page 463 Change the Transmit Frequency. It should be set to High for optimal performance. Reduce the maximum velocity in the device parameters to narrow the range. Check the sensor connections. Contact your regional ADS representative. Replace the sensor. Replace the monitor if defective. Problem Velocity readings are abnormally high.
Page 464: Surface Velocity Subsystem
11-66 ADS TRITON+ Manual Problem Individual PEAKVEL_1 or PEAKVEL_3 values consistently read -9.99. Possible Sensor may be faulty. Causes 5-volt (blue) fuse on regulator may have blown. Possible Replace the Peak Combo Sensor or Surface Combo Sensor. Solutions Replace the 5-volt blue fuse on the regulator.
Page 465 Maintenance and Troubleshooting 11-67 Problem Individual SURFACEVEL_3 values consistently read - 9.99. Sensor may be faulty. Possible Causes 5-volt (blue) fuse on regulator may have blown. Possible Replace the Surface Combo Sensor. Solutions Replace the 5-volt blue fuse on the regulator. Caution: Do not connect a questionable sensor to another monitor before verifying the integrity of the sensor.
Page 466: Pressure Depth Subsystem
The following tables contain general troubleshooting techniques for the pressure depth subsystem corresponding to the AV|Gated, AV|Max, ParaFlow, Peak Combo sensor or Surface Combo sensor. Note: Contact your regional ADS representative for further diagnosis before replacing a sensor. Problem Pressure depth readings are erratic.
Page 467: Temperature Subsystem
Temperature Subsystem The following table contains general troubleshooting techniques for the temperature subsystem corresponding to all sensors supporting the TRITON+. Note: Contact your ADS representative for further diagnosis prior to replacing a sensor or monitor.
Page 468 11-70 ADS TRITON+ Manual Problem Temperature readings are excessively low or incorrect. Possible Temperature sensor may be faulty. Causes Cable connecting sensor to monitor may be loose or broken. Processor board may be faulty. Possible Examine the sensor connection to the monitor, and verify that it is properly connected and secure.
Page 469: External Power, I/O, And Modbus Subsystems
DC OUT (P4 pins 1 & 2). If power is not available, replace the ExPAC/XBUS/XIO. Inspect the communication cable for proper connection at the monitor and the ExPAC/XBUS/XIO. Replace communication cable between monitor and ExPAC/XBUS/XIO. Contact your regional ADS representative.
Page 470 Verify wiring between XIO output and the external input device has been properly connected. Solutions Verify that the correct entity has been selected and that Qstart the scale has been set properly in . If necessary, adjust the configuration and reactivate the monitor. Contact your regional ADS representative.
Page 471 Qstart . If necessary, adjust the configuration and reactivate the monitor. Contact your regional ADS representative. Problem Data received at the monitor through the digital input in the XIO from the customer output device is not consistent with output.
Page 472 High-High Threshold have been selected for the Qstart Depth Alarms from the MLI Device in . If changes are required, reactivate the monitor. Contact your regional ADS representative. Problem Modbus communication is not successful. Possible Wiring to RS-485 or RS-232 port on ExPAC may be incorrect.
Page 473: Appendix A Specifications
A P P E N D I X A Specifications This appendix contains specifications for the ADS TRITON+ flow monitor and associated subassemblies, sensors, cables, and the external power, Modbus, I/O, and landline hardware. TRITON+ Flow Monitor (ADS p/n 8000-FST-IM) Enclosure Cylindrical 0.37-inch (6.39-mm) thick, seamless,...
Page 474 Power Internal: One 12-volt, 110 AH, IS alkaline battery pack External (option): External Power and Communications Unit (ExPAC) with an ADS- or customer-supplied 9- to 36-volt (minimum 15 watt) DC power supply. Battery Life 15 months at 15-minute sample rate with one Peak Combo Sensor and daily pull communications (i.e., data collects)
Page 475 Specifications Modem For monitors supporting 3G global network services: Modem: Telit HE910-D UMTS/HSPA+/GSM cellular modem using TCP/IP (Transmission Control Protocol/Internet Protocol) Bands: UTMS 800/850/AWS/1900; GSM 800/ 900/1800/1900 ® For monitors supporting Verizon network services: Modem: Telit ME910C1-NV, LTE-M, cellular modem using TCP/IP Bands: B13, 700 MHz NOTE: The Verizon LTE-M SIM is specifically linked to the modem in the monitor, therefore;...
Page 476 ADS TRITON+ Manual Approvals Certified under the ATEX European Intrinsic Safety standards for Zone 0 rated hazardous areas. Sira 09ATEX2027X Certified under IECEx (International Electrotechnical Commission Explosion Proof) Intrinsic Safety Standards for use in Zone 0 (equivalent to Class I, Division 1, Groups C & D) rated hazardous areas.
Page 477 Specifications reading is equal to one reading. Therefore, each total below represents the actual entities plus one date/time stamp. A date/time stamp must be included for each monitoring point associated with the monitor. Peak Combo AV|Gated Surface Ultrasonic Sensor Sensor Combo Depth Sensor Sensor...
Page 478: Intrinsically-Safe Sensors
ADS TRITON+ Manual Intrinsically-Safe Sensors AV|Gated Sensor (ADS p/n 8K-CS7-10-35) This sensor supports upward ultrasonic depth, average velocity, pressure depth, and measurement of water temperature. AV|Gated Sensor Housing Polycarbonate plastic shell, epoxy-filled Dimensions Enclosure: 6.76 inches (172 mm) long x 1.23 inches (31 mm) wide x 0.83 inches (21 mm) high...
Page 479 0 - 10.0 PSI (0 - 0.68 Bar): +/- 2.8 inches (70.3 Accuracy Pressure 0.01 inches (0.25 mm) Resolution AV|Max Sensor (ADS p/n 8K-CS9-10-35) This sensor supports upward ultrasonic depth, peak velocity, pressure depth and measurement of water temperature. AV|Max Sensor Housing Polycarbonate (PC)/ PEEK (Blue), epoxy-filled Enclosure: 6.28 inches (159.7 mm) long x 1.49...
Page 480 ADS TRITON+ Manual jacket Extension cables available up to 300 feet (91.4 Operating / Operating: -4° to 140° F (-20° to 60° C) Storage Storage: -4° to 167° F (-20° to 75° C) Temperature Note: This sensor will not produce accurate readings in frozen flow.
Page 481 Specifications Pressure 0.01 inches (0.25 mm) Resolution Long Range Depth Sensor (ADS p/n 8K-CS6-C1-10) This sensor supports downward ultrasonic depth at long range and detects surcharge levels near the manhole lid. Long Range Depth ABS plastic shell, polyurethane-filled Housing 9.15 inches (232.4 mm) long x 4.40 inches (111.8 Dimensions mm) wide x 4.22 inches (107.2 mm) high...
Page 482 A-10 ADS TRITON+ Manual Operating: -4 to 140 F (-20 to 60 C) Operating / Storage: -4 to 167 F (-20 to 75 C) Storage Temperature Note: The sensor will not produce accurate readings when ice is built up on the sensor.
Page 483 Specifications A-11 ParaDepth Sensor (ADS p/n 8K-CS8-D1-00-30-IS) This sensor supports downward ultrasonic and air temperature measurement only. ParaDepth Sensor Polycarbonate shell (PC)/ PEEK, epoxy-filled. Housing High visibility yellow color. Dimensions 10.9 inches (277 mm) long x 2.28 inches (57.9 mm) wide x 2.58 inches (65.5 mm) high Cable Standard size: 30.0 feet (9.14 m) long x 0.30...
Page 484 A-12 ADS TRITON+ Manual ParaFlow Sensor Polycarbonate shell (PC)/ PEEK, epoxy-filled. Housing High visibility yellow color. Dimensions 13.9 inches (353 mm) long x 2.20 inches (56 mm) wide x 2.58 inches (65.5 mm) high Cable Standard size: 30.0 feet (9.14 m) long x 0.30 inches (7.6 mm) nominal OD, polyurethane jacket...
Page 485 Specifications A-13 Surface Velocity Accuracy +/- 0.30 feet per second (0.09 m/s) or +5% of the actual reading (whichever is greater) in flow velocities from 1.00 to 15.00 ft/sec (0.3 to 4.6 m/s) Note: Flow conditions may cause the designated accuracy to vary and hinder or prevent the effective use of surface velocity technology.
Page 486 A-14 ADS TRITON+ Manual Peak Combo Sensor (ADS p/n 8K-CS4-xx-35/1H) This sensor supports upward ultrasonic depth, peak velocity, and pressure depth. Housing ABS plastic shell, epoxy-filled Dimensions Enclosure: 6.76 inches (172 mm) long x 1.23 inches (31 mm) wide x 0.83 inches (21 mm) high Cable Standard size: 35 feet (10.7 m) feet (30.5 m) long...
Page 487 Specifications A-15 Resolution 0.01 feet per second (0.003 m/sec) Accuracy +/- 0.2 ft/sec (0.06 m/sec) or 4% of actual peak velocity (whichever is greater) in flow velocities from -5 to 20 ft/sec (-1.52 to 6.10 m/sec) Pressure Depth Pressure 0.0 to 5.0 PSI (0.0 - 0.34 Bar): up to 11.5 feet (3.5 Range 0.0 to 15.0 PSI (0.0 - 1.03 Bar): up to 34.5 feet (10.5 m)
Page 488 A-16 ADS TRITON+ Manual Surface Combo Sensor (ADS p/n 8K-CS5-V2-xx- 30/1H) This sensor supports downward ultrasonic depth, surface velocity, surcharge peak velocity, and surcharge pressure depth. Surface Combo Sensor Housing ABS plastic shell, epoxy-filled Dimensions 10.61 inches (269 mm) long x 2.03 inches (52 mm) wide x 2.45 inches (62 mm) high...
Page 489 Specifications A-17 Surface Velocity Accuracy +/- 0.25 feet per second (0.08 m/s) or 5% of the actual reading (whichever is greater) in flow velocities from 1.00 to 15.00 ft/sec (0.30 to 4.57 m/s) Note: Flow conditions may cause the designated accuracy to vary and hinder or prevent the effective use of surface velocity technology.
Page 490 0 - 15.0 PSI (0 - 1.03 Bar): +/- 4.1 inches (104 0 - 30 PSI (0 - 2.07 Bar): +/- 8.3 inches (211 mm) Pressure 0.01 inches (0.25 mm) Resolution Ultrasonic Depth Sensor (ADS p/n 8K-CS5-D1-00- This sensor supports downward ultrasonic depth. Ultrasonic Depth Sensor Housing ABS plastic shell, epoxy-filled Dimensions 10.61 inches (269 mm) long x 2.03 inches (52...
Page 491 10.0 feet (3.05 m) Resolution 0.01 inches (0.25 mm) Drift 0.0 inches/mm Inclinometer Sensor (ADS p/n 8K-0528) This sensor determines tilt via an accelerometer. Inclinometer Sensor Housing Solid, molded ABS providing high impact and abrasion resistance in a fully sealed device Dimensions Height 0.865 in (2.2 cm);...
Page 492: Usb Serial Interface (Ads P/N 8000-0337
USB Serial Interface (ADS p/n 8000-0337) The USB serial interface (or direct connection) cable supports on- site communications with the ADS TRITON+ monitor. It consists of two cables: a primary cable with interface box and potted metal connector and a standard USB Type A to Type B cable.
Page 493: Expac (Ads P/N 8000-0377
Specifications A-21 ExPAC (ADS p/n 8000-0377) The ExPAC (External Power and Communication unit) enables the TRITON+ to receive power from an external DC source and supports Modbus communications. ExPAC Enclosure Rectangular, ABS Plastic, DIN rail or wall mount, IP20 Dimensions 5.7 inches (145 mm) wide x 3.6 inches (91 mm)
Page 494: Power Supply (Ads P/N 508293
A-22 ADS TRITON+ Manual Power Supply (ADS p/n 508293) This ADS-recommended power supply supports externally- powered TRITON+ monitors. ADS Power Supply Manufacturer XP Power DNR60US24 and Model Dimensions 3.60 inches (90 mm) high x 1.59 inches (41 mm) wide x 4.53 inches (115 mm) deep Weight 0.8 pounds (350 g)
Page 495: Xbus (Ads P/N 8000-0427
Power Input 85-264 VAC, 120-375 VDC; 47-63 Hz; 1.10 A @ 110 / 0.59 A @ 250 VAC External Power/ ADS ExPAC (Refer to page A-21 for Communications specifications and details on the ExPAC) Unit Connectors...
Page 496: Xio (Ads P/N 8000-0400
A-24 ADS TRITON+ Manual XIO (ADS p/n 8000-0400) ™ The XIO (External Input/Output unit) enables the TRITON+ to receive power from an AC power source and serves as a digital and analog input and output interface. Enclosure Indoor/outdoor NEMA 4X (IP 66), PBT and...
Page 497 Digital Outputs Two SPST Relays Maximum Load: 2 A @ 250 VAC, 2A @ 30 VDC Minimum Load: 5 VDC, 20 mA External ADS ExPAC (Refer to page A-21 for Power/Comm specifications and details on the ExPAC) Unit Connectors Three cable glands for power cable, monitor...
Page 498: Appendix B Part Numbers
A P P E N D I X B Part Numbers This appendix contains a parts list of the most commonly ordered and used ® parts supporting the ADS TRITON+ flow monitoring system. Monitors 8000-FST-IM-4WW- TRITON+ MONITOR, AT&T LTE-M (INCLUDES 12-...
Page 499 B-2 ADS TRITON+ Manual (10.6-m) CABLE 8K-CS4-15-35 SENSOR, CS4, UPWARD DEPTH, PEAK VELOCITY, PRESSURE SENSOR 0 – 15 PSI (0 – 1.03 Bar), 35-FT (10.6-m) CABLE 8K-CS4-30-1H SENSOR, CS4, UPWARD DEPTH, PEAK VELOCITY, PRESSURE SENSOR 0 – 30 PSI (0 – 2.07 Bar), 100-FT (30.5-m) CABLE...
Page 500 Part Numbers 8000-0044-25 USB SERIAL INTERFACE EXTENSION CABLE, 25 FT (7.6 m) – also extends the Direct Serial Interface cable (p/n 8000-0054) 8000-0054-01 ASSY,DIR CON,IS,TPL TO TELOG, RU33 8000-0054-02 ASSY,DIR CON,IS,TPL TO TELOG, RU35 8000-0054-03 ASSY,DIR CON,IS,TPL TO AYYEKA WAVELET 4 508227 STANDARD USB TYPE A TO TYPE B CABLE, 6 FT (1.8 m) (replacement for USB cable component in 8000-...
Page 501 B-4 ADS TRITON+ Manual Monitor Replacement Parts 8000-0043-04 BATTERY PACK, IS, 12V, UNPOTTED with PCB 8000-0043-02 BATTERY PACK, IS, 12V, UNPOTTED without PCB 8000-0447 BLACK FEET, MOUNTING BAR (CS6) 8000-0141 RETAINER, PLUG, URETHANE, 12-V IS BATTERY (for use with 8000-0043-01/02)
Page 502 Part Numbers I25-0090 RING, SS, 20.5 - 22.75 IN (521 - 578mm) I25-0091 RING, SS, 22.5 - 28.75 IN (572 - 730mm) I25-0092 RING, SS, 38.5 - 36.75 IN (724 - 933mm) I25-0093 RING, SS, 36.5 - 48.75 IN (927 - 1238mm) I25-0094 RING, SS, 48.75 - 60.75 IN (1238 - 1543mm) I/O and External Power Parts...
Page 503 TOOL, SPEED HANDLE, 18”, 13MM SOCKET This item is part of the mounting hardware included with the monitor for the flange handle (ADS p/n I40-0009). Note: In all applications, only ADS IS-Certified Service Technicians are authorized to perform TRITON+ board and/or component-level.
Page 504: Appendix C Monitor Activity Codes
A P P E N D I X C Monitor Activity Codes ® This appendix contains a list of the ADS TRITON+ monitor activity codes that display automatically on the LED STATUS window on the monitor top while the monitor is running. This list also includes descriptions of the monitor activities corresponding to the codes.
Page 505 ADS TRITON+ Manual Code Monitor Activity Closing the FTP connection Deep sleep (monitor going to sleep) Reading peak velocity (from the Peak Combo Sensor) Changing FTP directories Running display task Running diagnostic task Erasing files in modem Encoding CSV data for FTP delivery...
Page 506 FTP connection (remains on twice as long than off) Experiencing communication errors between the processor (ADS p/n 8000- 0338) and the regulator/modem (ADS p/n 8000-0334). Check fuse F9 on battery PCB (ADS p/n 8000-0042-3) and cable connections between...
Page 507 ADS TRITON+ Manual...
Page 508: Appendix D Third-Party Logger Support
A P P E N D I X D Third-Party Logger Support ® The TRITON+ can be configured to provide data to select third- party loggers. This appendix contains information regarding the ® Telog Ru-33 and Ru-35 Recording Telemetry Unit (RTU) and the ®...
Page 509: Telog Ru-33 Or
TRITON+. These procedures involve designating the appropriate identification information to enable recognition and data exchange between the ADS and Telog or Ayyeka units and using an interface cable to connect the monitor to the RTU. Note: The Telog Ru-33 and Ru-35 must have firmware version 3.300 or later to effectively request data from the...
Page 510 Enable This box must be checked to activate the Modbus configuration. Connecting the Monitor to the Ru-33 or Ru-35 Connecting the TRITON+ to the Ru-33 requires the ADS Triton- Telog Comm Cable (ADS p/n 8000-0054-01). Connecting the TRITON+ to the Ru-35 requires the ADS Triton Telog Comm Cable (ADS p/n 8000-0054-02).
Page 511: Ayyeka Wavelet 4R
Modbus Delay Response This represents the amount of time, in milliseconds, following the request before the monitor will return the requested Modbus output data to the Wavelet. ADS recommends maintaining the 10 ms default setting. Enable This box must be checked to activate the Modbus configuration.
Page 512 System Configuration and Setup for Telog Ru-33 D-5 Connecting the Monitor to the Wavelet 4R Connecting the Ayekka Wavelet to the TRITON+ requires the ADS Ayyeka Wavelet Comm Cable (ADS p/n 8000-0054-03). First, connect the black, metal connector (with gray, plastic boot) from the comm cable to the COMM + EXT PWR port on top of the TRITON+.
Page 513: Appendix E Sampler Cable Connections And Specifications
A P P E N D I X E Sampler Cable Connections and Specifications This appendix contains information regarding the ADS TRITON+ sampler cable connections and specifications.
Page 514: Triton+ Sampler Cable Illustrations
The TRITON+ enables the user to connect a water quality sampler to the monitor for flow proportional or level-based sampling operations. ADS offers three 25-foot (7.6-m) cable optoins for connecting the sampler to the monitor based on the type of...
Page 515 Sampler Connections and Specifications E-3 No Pre-Wired Connector (ADS p/n 8000-0348) on application (non-monitor) end of the cable Specifications for ADS Sampler Cable 8000-0348 – Raw Wires on application end of Sampler Cable...
Page 516 ADS TRITON+ Manual Flow Proportional 6-pin Pre-Wired Connector (ADS p/n 8000- 0348-01) Specifications for ADS Sampler Cable 8000-0348-01 for Flow Proportional Sampling Level Actuation 6-ping Pre-Wired Connector (ADS p/n 8000- 0348-02) Specifications for ADS Sampler Cable 8000-0348-02 for Level Actuation Sampling...
Page 517 Activating the SIM Card, 3-5 editing ultrasonic parameters, 4-28 activity codes, 11-6 editing velocity parameters, 4-33 monitor, C-1 general, 2-1 ADS hosted software system Maximum Velocity parameter, 4- receiving test cryouts from the monitor, 11-9 Minimum Velocity parameter, 4- ADS XIO, 2-35...
Page 518 In-2 ADS TRITON+ Manual upward ultrasonic depth AV|Max Sensor, 1-4 measurement, 2-17 part number, A-7 AV|Gated specifications, A-7 verifying the sensor position, 4-93 AV|Gated install information, 5-21 AV|Gated band mounting across from crank, 5-21 securing the sensor cables, 5-52 AV|Gated...
Page 519 Index In-3 Declaration of Conformity, 1-28 Telog Ru-33, D-2 IECEx, 1-18 Wavelet 4R, D-4 modem, 1-13 configuring a location, 4-7 special conditions for use, 1-6 5-84 confined space entry, 5-3, channel, 2-10, 4-27, 4-50, 4-67, 4-69 confirmations, 4-96, 11-4 checking the sensors, 11-20 confirming sensors, how to, 4-96 checklist connecting a laptop directly to...
Page 520 In-4 ADS TRITON+ Manual downward ultrasonic, 2-22, 2-30, editing (surcharge) peak 2-32 velocity parameters, 4-77 pressure, 2-28 editing pressure parameters, 4- upward ultrasonic, 2-17, 2-20, 2- editing smart depth (ultrasonic) desiccant parameters, 4-70 pressure depth sensor dryer tube, editing surface velocity...
Page 521 Index In-5 dryer tube, 5-99 monitor COMM + EXT PWR desiccant, 11-21 port, 2-10 end-cap, 5-100 requirements, 6-3 replacement, 11-21 running the ground wires, 6-22, 6- replacing the desiccant, 11-22 29, 6-34 securing to the monitor, 5-99 supplying to system, 6-36 duration, 4-75 wiring the AC power cable to the dynamic IP, 3-4...
Page 522 In-6 ADS TRITON+ Manual external power grounding kit, 6- sensors, 11-20 29, 6-34 installation ground connection facility, 6-22, 1/2-band mount 6-23, 6-29, 6-34 Peak Combo Sensor, 5-49 GSM/HSPA communication 3/4-band mount modem Peak Combo Sensor, 5-45 information, 1-13 3/4-band mount with silt mount...
Page 523 Index In-7 mounting Peak Combo Sensor lookup, 4-12 to the ring assembly using pipe, 4-11 the silt mount adapter, 5-24 weir, 4-11 mounting Surface Combo installing an inclinometer, 8-2 Sensor to the ring assembly, internal modem 5-32 replacing the SIM card, 11-24 mounting to the ring, 5-21 internal power mounting Ultrasonic Depth...
Page 524 In-8 ADS TRITON+ Manual Mounting Bar installation, 5-64 connecting through the ExPAC overview, 2-20 RS-485 port in the XBUS, 10-2 part number, A-9 output data registers, 10-11 part numbers, 2-20 SCADA, 10-1 physical offset, 5-75 setting up a wireless connection,...
Page 525 Index In-9 connecting ground wire, 6-29, 6- running sensor diagnostics, 4-92 securing the dryer tube, 5-99 connecting sensors, 5-97 shipping for warranty work, 1-31 connectors, 2-9 specifications, A-1 control drawing, 1-11 supplying external power, 6-36 diagnostic codes, 11-6 telemetry, 1-5 Telog Ru-33, D-2 direct connection, 3-22 estimated battery life, 11-9...
Page 526 In-10 ADS TRITON+ Manual AV|Gated Sensor, 2-18 specifications, A-11 pressure depth, 2-18, 2-20 ParaDepth Sensor Sensor upward ultrasonic depth, 2-17 special installation AV|Max Sensor, 2-20 5-80 Topside Retrieval System, upward ultrasonic depth, 2-20 ParaFlow sensor communication, 2-5 general, 2-2 on-site, 2-6...
Page 527 Index In-11 3/4-band mount, 5-45 connecting a water quality sampler 3/4-band mount with silt mount to the monitor, 5-97 adapter, 5-47, 5-50 connecting sensors to the monitor, silt mount adapter, 5-47, 5-50 5-97 IS certification, 1-5 power, 1-5 overview, 2-28 12-volt IS battery pack, 2-3, 2-11 peak velocity measurement, 2- battery pack, 1-5, 2-3...
Page 528 In-12 ADS TRITON+ Manual wiring the power supply to the date format, 4-3 ExPAC, 6-18 default location, 4-3 XBUS, 1-5, 2-3, 2-12 editing devices XIO, 1-5, 2-3, 2-12 AV|Gated Sensor, 4-27 power supply Peak Combo Sensor, 4-50 installation, 6-7 Surface Combo Sensor, 4-69...
Page 529 Index In-13 desiccant in dryer tube, 11-22 verifying Modbus output data, 4- dryer tube, 11-21 fuses, 11-35 wireless communication, 10-9 parts/part numbers, B-1 sensitivity, 4-57, 4-74, 4-78 regulator, 11-35 sensor extension cables, 5-42, 5-63 SIM card, 11-24 sensor temperature, 4-38, 4-61, 4-67 returns sensors, 1-4, 1-5 international, 1-31...
