Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide

6 EEPROM.TXT format

A set of commands is defined to allow user to change EEPROM.BIN content. To update
EEPROM.BIN, user must enter –e <code> -geneep options at the command prompt. A password
must be entered to run this option. The 5704, Dual MAC, device use one single eeprom.bin to on
both MAC channel configuration. Most of the configurations are shared expect the following
commands:
PXE
PXE_SPEED
WOL
ASF
The WOL and ASF setting cannot be enabled on both channel at the same time. For example, if the
primary WOL is already enabled, and the user try to enable secondary device's WOL, the primary's
WOL setting will be disabled with the following message:
** Warning, primary device WOL is disabled
By default, all commands configure the primary channel until the command MAC is used to select
other channel.
Syntax
:
<Command> = <Argument>
xx 8-bit hex number
xxxx 16-bit hex number
xxxxxxxx 32-bit hex number
d decimal number ranges from 0 to 255
string(n) string of maximum size n.
cc 2 bytes character
n1..n2 a number ranges from n1 to n2.
For Boot Code:
MAC
MAC_PREFIX
MAC_ADDRESS
POWER_DISSIPATCHED
POWER_CONSUMED
SYSTEM_VENDOR_ID
SYSTEM_DEVICE_ID
SUBSYSTEM_VENDOR_ID
SUBSYSTEM_DEVICE_ID
PXE
PXE_SPEED
WOL
CABLE_SENSE
PRODUCT_NAME
= {0, 1}*
= xx:xx:xx
= xx:xx:xx:xx:xx:xx
= d:d:d:d
= d:d:d:d
= xxxx
= xxxx
= xxxx
= xxxx
= {enable, disable}
= {auto, 10hd, 10fd, 100hd, 100fd, 1000fd}
= {enable, disable}
= {enable, disable}
= string (48)
