Broadcom® SAS 9305-24i PCI Express® to 12Gb/s
Serial Attached SCSI (SAS) Host Bus Adapter
User Guide
Version 1.0
January 27, 2016
pub-005246
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
cerca il tuo prodotto tra le
migliori offerte di Altre Schede
Broadcom 9305-24i
o

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAS 9305-24i and is the answer not in the manual?

Questions and answers

Related Manuals for Broadcom SAS 9305-24i

Summary of Contents for Broadcom SAS 9305-24i

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Broadcom 9305-24i cerca il tuo prodotto tra le migliori offerte di Altre Schede Broadcom® SAS 9305-24i PCI Express® to 12Gb/s Serial Attached SCSI (SAS) Host Bus Adapter User Guide Version 1.0...

  • Page 2: January

    Broadcom, the pulse logo, Connecting everything, the Connecting everything logo, and Avago Technologies are among the trademarks of Broadcom Ltd. and/or its affiliates in the United States, certain other countries and/or the EU. Any other trademarks or trade names mentioned are the property of their respective owners.

  • Page 3: Table Of Contents

    Broadcom SAS 9305-24i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide Table of Contents January 27, 2016 Table of Contents SAS 9305-24i Host Bus Adapter User Guide ..................4 1 Overview .

  • Page 4: Sas 9305-24I Host Bus Adapter User Guide

    The 12Gb/s SAS HBA supports eight-lane PCIe performance up to 64Gb/s single direction and 128Gb/s dual direction. SAS-3 Interface The Broadcom SAS 3224 controller chip contains the SATA+SAS functionality for the 12Gb/s SAS HBA with SAS performance of 1200 MB/s per port in each direction.

  • Page 5: Led Management

    The 12Gb/s SAS HBA provides one a128Mb Flash ROM to store the firmware and the BIOS. LEDs The Broadcom 12Gb/s SAS HBA has a Heartbeat LED (LT14) that blinks green to indicate that the HBA is capable of general activity, and a thermal event LED (LT10) that illuminates if the IOC experiences an over-temperature condition.

  • Page 6: Physical Characteristics

    Broadcom SAS 9305-24i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide SAS 9305-24i Host Bus Adapter User Guide January 27, 2016 Broadcom SAS 9305-24i HBA Characteristics PCIe Connector (JT9). The 12Gb/s SAS HBA supports a x8 interface. The PCIe host interface connection is through the edge connector, JT9, which provides connections on both the top (JT9 B) and bottom (JT9 A) of the board.

  • Page 7: 12Gb/S Sas Hba Certifications And Safety Characteristics

    12Gb/s SAS HBA Certifications and Safety Characteristics All Broadcom 12Gb/s SAS HBAs meet or exceed the requirements of UL flammability rating 94V-0. Each bare board is marked with the supplier’s name or trademark, type, and UL flammability rating. Because these boards are installed in a PCIe bus slot, all voltages are less than the SELV 42.4-V limit.

  • Page 8: Replacing The Bracket

    Make sure the system provides the required airflow for the controller. Airflow must be at least 200 linear feet per minute (LFM) at 55 °C inlet temperature to avoid operating the Broadcom SAS 3224 processor above the maximum junction temperature.
  • Page 9 Broadcom SAS 9305-24i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide SAS 9305-24i Host Bus Adapter User Guide January 27, 2016 Replacing the Bracket Use an ESD-safe #1 Phillips screwdriver to carefully remove the two Phillips screws that connect the bracket to the board.

  • Page 10: Technical Support

    Exceeding this torque specification can damage the board, connectors, or screws, and can void the warranty on the board. Technical Support For assistance installing, configuring, or running the Broadcom 12Gb/s SAS HBA, contact Technical Support at http://www.avagotech.com/support/. Broadcom Ltd. - 10 -...
