Led Mode
Description:
A device can be configured to use one LED to indicate speed and activity or three LEDs.
Use a devices data sheet to verify the LED modes supported by a devices and for
exceptions to the LED modes described below.
Mac Mode (0) The LEDs are controlled by the value in the Mac LED Control Register.
Phy Mode1 (1) Dual Link LED configuration. Two LEDs are used to indicate 10/100
Mbps.
Phy Mode2 (2)
Link/Speed LED configuration. One LED is used to indicate link status
of all 10/100 Mbps.
SharedTraffic (3) Shared Traffic/Link LED Mode. The Link LED performs dual role: Solid
Green, when Link up. Blink when there is an activity.
9
VPD Data
Description:
VPD Product Name and Read Data.
Part Number (1)
Engineering Change (2)
Serial Number (3)
Manufacturing ID (4)
Read only VPD Data (5)
Product Name (6)
A
Super Airplane Mode
Description:
Super Airplane mode
Disable Disable Super Airplane Mode
Enable Enable Super Airplane Mode
B
MBA Configuration
Description:
MBA Configuration
VLan Enable (1)
VLan ID (2)
MBA Hide Banner (3)
MBA Hot Key (4)
MBA Protocol (5)
MBA Config Timeout (6)
MBA Bootstrap (7)
MBA Link Speed (8)
C
Design Type
Description:
Select NIC or LOM based Ethernet controller.
NIC(1) Option selected for a plug in network interface card.
LOM(0) Option selected for a LAN on motherboard.
D
L1 PLL Powerdown Disable
Description:
Disable / Enable L1 PLL Powerdown
Broadcom Confidential and Proprietary
VPD Part Number
VPD Engineering Change
VPD Serial Number
VPD Manufacturing ID
VPD Read only V0 Data
VPD Product Name
Enabled / Disabled
VLan ID
Enabled / Disabled
Ctrl-B / Ctrl-S
PXE / RPL / BOOTP / ISCSI
MBA Config Timeout value
Auto / BBS / INT18 / INT19
Auto /10HD / 10FD / 100HD / 100FD
