Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
No(0) Power-saving capability active.
Yes(1) Power-saving capability inactive.
39
Hide MBA Setup Prompt
Description:
During the MBA boot, the MBA setup prompt is displayed to provide the user the option to
setup and configure various MBA parameters. Options 8,9, 26 - 29 and 39-40 configure the
boot protocol behavior.
Disable (0) Hide the MBA Setup Prompt. The user is NOT give the option to change
the MBA boot parameters.
Enable (1) Show the MBA Setup Prompt. The user is given the option to change the
MBA boot parameters.
40
MBA Setup Hot Key
Description:
Hot Key used to enter the MBA Setup. Options 8,9, 26 - 29 and 39-40 configure the boot
protocol behavior.
Ctrl-S (0) MBA Setup entered via ctrl-s.
Ctrl-B (1) MBA Setup entered via ctrl-b.
41
Capacitive Coupling
Description:
Enable/Disable the PHY to operate with capacitors as line isolators for the 5705 family.
Disable (0) Disable capacitive coupling.
Enable (1) Enable capacitive coupling.
42
SERDES TX Drvr Pre-Emp – Primary (5704 only)
Description:
The TX driver pre-emphasis value that is used for the primary device of a 5704 if it is
enabled by option 44 below.
43
SERDES TX Drvr Pre-Emp – Secondary (5704 only)
Description:
The TX driver pre-emphasis value that is used for the secondary device of a 5704 if it is
enabled by option 44 below.
44
SERDES TX Drvr Pre-Emp – ENABLE (5704 only)
Description:
Enable/Disable the setup of the TX driver pre-emphasis defined in options 42 and 43
above.
Disable (0) Disable TX driver per-emphasis.
Enable (1) Enable TX driver per-emphasis.
45
Reserved. Option no longer in use.
46
Encoded Hot Plug Power 1 & 2 For NIC
Broadcom Confidential and Proprietary
page 48
Configure
Configure
Configure
Configure
Configure
Configure
Reference
Configure
