8.3.2 Audio Adjustments

■ Volume: -100dB to 0dB and adjust 0.5dB per step (for both zone
and extended audio).
■ Treble/Bass : Bass range from - 12dB to +12dB, 1dB per step
adjustment. Treble range from - 12dB to +12dB, 1dB per step
adjustment.
■ Audio Delay: 230ms for line-out per channel, 1ms per step
adjustment.
■ Audio Mixer: Mixes any two audio sources into a single channel.
Three mixers in total. Mixer gain is adjustable from 0%~100%.

8.3.3 Linear PCM Audio

Channels (kHz)
LPCM 2.0@44.1
LPCM 2.0@88.2
LPCM 2.0@176.4
LPCM 2.0@32
LPCM 2.0@48
LPCM 2.0@96
LPCM 2.0@192

8.3.4 Compressed Audio

Bitstreams
Standard Bitstream Formats
High-Bandwidth Bitstream Formats
Notes: Audio break away function supported in LPCM format only. The
OAR, optical, coaxial, and Audio CAT functions only support LPCM.
LPCM 5.1@44.1
LPCM 5.1@88.2
LPCM 5.1@176.4
LPCM 5.1@32
LPCM 5.1@48
LPCM 5.1@96
LPCM 5.1@192
LPCM 7.1@44.1
LPCM 7.1@88.2
LPCM 7.1@176.4
LPCM 7.1@32
LPCM 7.1@48
LPCM 7.1@96
LPCM 7.1@192
