8.2.2 Maximum HDMI Cable Length

HDMI Resolution
8-bit 1080p
12-bit 1080p
3840×2160@60Hz (YCbCr 4:2:0)
3840×2160@60Hz (YCbCr 4:4:4)
Note:
1. 6G (4K@60Hz YCbCr 4:4:4) HDMI signals will be converted to
3G (4K@60Hz YCbCr 4:2:0) signals when output over the eight
HDBaseT ports. Some TVs may not support YCbCr 4:2:0 color or
4K@60Hz and may display the signal incorrectly, or not at all.
Please check your TV's technical specs before attempting to
display 4K@60Hz signals.
2. The use of "Premium High Speed HDMI" cables is highly
recommended.

8.3 Supported Audio Formats

8.3.1 Analog Audio

Analog Inputs
Max Audio Level
Input Impedance
Analog Outputs
0dBFS Output Level
THD ≤ 80%
THD ≤ 90%
SNR
Frequency Response
Crosstalk
Output Impedance
60
2Vrms
>10kΩ
2Vrms
1K 0dBFS
1K -1dBFS
> 100dB @ 1K 0dBFS
< ±0.5dB @ 20Hz~20KHz
< 90dB @ 20hz~20Khz
> 470Ω
Input Output
10 meters 10 meters
10 meters 10 meters
5 meters 5 meters
3 meters 3 meters
