routed from any audio source within the matrix. Audio mixing,
treble, bass, volume and audio delay adjustments can be set in
the WebGUI (LPCM 2.0 or analog stereo sources only).
EXTENDED AUDIO OUT 1~4: Four sets of stereo analog audio
7
outputs. These audio ports are capable of independently
outputting audio routed from any audio source within the matrix.
Audio mixing, treble, bass, volume and audio delay adjustments
can be set in the WebGUI (LPCM 2.0 or analog stereo sources
only).
ANALOG AUDIO IN 1~4: Accepts unbalanced analog audio from
8
sources such as DVD players, PCs, MP3 players, etc. These audio
sources can be paired with the video from any HDMI input or can
be mixed with another audio source. Audio mixing can be set in
the WebGUI.
DIGITAL AUDIO IN 1~4: Accepts digital audio (LPCM 2.0 only) from
9
sources such as Blu-ray players, game systems, PCs, etc. These
audio sources can be paired with the video from any HDMI input
or can be mixed with another audio source. Audio mixing can be
set in the WebGUI.
CAT AUDIO I/O 1~2: Can send/receive audio to/from connected
10
compatible CAT Audio devices via standard Cat.5e cable. This
connection allows audio to be sent to/from the matrix over greater
distances than would normally be possible via standard cables.
48kHz audio can be transmitted up to 300m, 96kHz audio can be
transmitted up to 150m and 192kHz audio can be transmitted up
to 100m.
LAN: Connect to an active Ethernet network to allow for Telnet
11
and WebGUI control of the matrix (refer to sections 6.9 and 6.10)
as well as to share the network (including Internet, if available)
with connected compatible LAN equipped HDBaseT receivers. This
allows for any Ethernet equipped device (e.g. a smart TV or game
console) connected to the LAN port of a receiver to share the
network/Internet access.
12 RS-232: Connect directly to your PC/laptop to send RS-232
commands to control the unit (refer to section 6.7).
SERVICE: Used for firmware service updates in the field via USB
13
thumb drive. After connecting a USB thumb drive containing
appropriate firmware, please select navigate via the front panel
7
