Figure 2.1. Machxo2 Breakout Board, Top Side - Lattice Semiconductor MachXO2 Breakout Board User Manual

Table of Contents

Advertisement

MachXO2
PLD (U3)
Two 2 × 20
Header
Landings
(J2, J4)
FTDI USB to
UART/FIFOIC
(U1)
© 2014-2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02051-2.3
4 × 15 60-Hole
LED Array (J4)
Prototype Array (J6)
JTAG Header
USB Mini-B
Landing (J1)
Socket (J7)

Figure 2.1. MachXO2 Breakout Board, Top Side

MachXO2 Breakout Board Evaluation Kit
Power LED
Power/GNDTest
(PWR_ON)
Points (TP1, TP2, TP3)
Evaluation Board User Guide
Two 2 × 20 Header
Landings (J3, J5)
