1.4 Print Specifications

Print Specifications
Printhead resolution
(dots per inch/mm)
Printing method
Dot size
(width x length)
Print speed
(inches per second)
Max. print width
Max. print length
Printout bias

1.5 Ribbon Specifications

Ribbon Specifications
Ribbon outside diameter
Ribbon capacity
Ribbon core
Ribbon width
Ribbon wound type
Note: It is recommended to use a ribbon width wider than the label width.

1.6 Media Specifications

Media Specifications
Media roll
capacity
Media core
diameter
Media type
Media wound type
Media width
Media thickness
Label length
Label length
(peeler mode)
Label length
(cutter mode)
Black mark
Gap height
203 dpi models
203 dots/inch
(8 dots/mm)
0.125 x 0.125 mm
(1 mm = 8 dots)
2,3,...8 ips
Up to 8 ips
4.25" (108 mm)
1000" (25,400 mm)
Vertical: ~Max. 0.039 (1 mm). Horizontal: Max. 0.039 (1 mm)
O.D. Max. 3.2" (81.3 mm)
492 Yards (450 meter long)
1" (25.4 mm)
0.157" ~ 4.33" (40 mm ~ 110 mm)
Ink coated outside wound, ink coated inside wound
O.D. Max. 8" (203.2 mm)
1"~ 3" (25.4 mm ~ 76.2 mm) I.D. core
Continuous, die-cut, black mark, fan-fold, notch
Outside wound
0.79" ~ 4.72" (20 mm ~ 120 mm), Cutter mode: max. 4.49" (114 mm)
0.002 ~ 0.011" (0.06 mm ~ 0.28 mm)
▪ 203 dpi series - 0.197 ~ 1000" (5 mm ~ 25,400 mm)
▪ 300 dpi series – 0.197 ~ 450" (5 mm ~ 11,430 mm)
1" ~ 6" (25.4mm ~ 152.4mm)
▪ 203 dpi - 1 ~ 90"(25.4~2,286 mm)
▪ 300dpi - 1~ 40"(25.4~1016 mm)
Min. .315" W (8 mm) x 0.079" H (2 mm)
Min. 0.079" (2 mm)
Thermal transfer and direct thermal
- 5 -
300 dpi models
300 dots/inch
(12 dots/mm)
0.084 x 0.084 mm
(1 mm = 12 dots)
2,3,...6 ips
Up to 6 ips
4.16" (105.7 mm)
450" (11,430 mm)
