1.2.2 Printer Optional Features
The printer offers the following optional features.
Product option feature
GPIO interface (Wi-Fi excluded)
Internal Bluetooth module in front panel
Note: Option for either Wi-Fi or Bluetooth only, not both.
Wi-Fi module kit
Note: Option for either Wi-Fi or Bluetooth only, not both.
Wi-Fi module (with slot-in housing installed already)
Note: Option for either Wi-Fi or Bluetooth only, not
both.
Peel-off module assembly
(include internal liner rewinder)
Minimum label peeling height: 1"
Regular cutter (Guillotine cutter, max: 4 ips)
Paper thickness:
0.06 ~ 0.15 mm
Plus keyboard display unit
Plus programmable smart keyboard

1.3 Printer Specifications

Printer Specifications
Model M9 Plus
Physical
9.8" W (248mm) x 10.8" H (274mm) x 17.2" D (436mm)
dimensions
Weight 20.3 lbs (9.2 kg)
Auto sensing power supply (20% print ratio)
◼
Power
◼
◼
Environmental
◼
condition
Environmental
Comply with Energy Star 2.0, REACH, RoHS, and WEEE
concern
Input: AC 100-240V, ~2.0A, 50-60Hz
Output: DC 24V, 3.75A; 90W
Operation: 5 ~ 40˚C (41 ~ 104˚F), 25~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90% non-condensing
User
option
○
○
○
