1.4 Print Specifications

Print Specifications
Printhead resolution
(dots per inch/mm)
Printing method
Dot size
(width x length)
Print speed
(inches per second)
Max. print width
Max. print length
Printout bias

1.5 Ribbon Specifications

Ribbon Specifications
Ribbon outside diameter
Ribbon length
Ribbon core inside diameter
Ribbon width
Ribbon wound type
Ribbon end type

1.6 Media Specifications

Media Specifications
Media roll
capacity
Media core
diameter
Media type
Media wound type
Media width
Media thickness
Label length
Black mark
Gap height
203 dpi models 300 dpi models
203 dots/inch
(8 dots/mm)
0.125 x 0.125 mm
(1 mm = 8 dots)
Up to 14 IPS
1000" (25,400 mm)
OD Max. 3.54" (90 mm)
656 Yards (600 meters)
1" (25.4 mm)
1"~4.5" (25.4 mm ~ 114.3 mm)
Ink coated outside wound, ink coated inside wound
Transparency
Max. 8" (203.2 mm) OD; 1.5" or 3" ID core, Rewind 3" only
3" (76.2 mm) or 1.5" (38.1 mm) ID core
Continuous, die-cut, black mark, fan-fold, notch
Outside wound
0.78" ~ 4.49" (20 mm ~ 114 mm)
0.002" ~ 0.011" (0.06 mm ~ 0.28 mm)
0.20" ~ 1,000"
(5 mm ~ 25,400 mm)
Min. .315" (8 mm) Wide x 0.079" (2 mm) High
Min. 0.079" (2 mm)
300 dots/inch
(12 dots/mm)
Thermal transfer and direct thermal
0.084 x 0.084 mm
(1 mm = 12 dots)
Up to 12 IPS
104 mm (4.09")
450" (11,430 mm)
Vertical: 0.027" ~ 0.039" (0.7 ~ 1mm)
0.20" ~ 450"
(5 ~ 11,430 mm)
- 5 -
600 dpi models
600 dots/inch
(24 dots/mm)
0.042 x 0.042 mm
(1 mm = 24 dots)
Up to 6 IPS
100" (2,540 mm)
0.20" ~ 100"
(5 ~ 2,540 mm)
