6.2.24 Get the Direction of the LEDs for "Rolling Shutter" Mode

Function
getDirectionMulti
Description
The function "LED-Panel.exe -getDirectionMulti" returns the current moving direction of the
LED columns (each one consisting of ten LEDs) in "Rolling Shutter" mode.
Return values
After executing this function, the device will return a one-digit value of the current direction of
the LED columns. For the possible return values list, please refer to Table 2.

6.2.25 Set LEDs switching time for the "Exposure Time" mode

Function
setTime <XX>
Description
With the function "LED-Panel.exe -setTime <XX>," it is possible to set the switching time of the
LEDs in the "Exposure Time" mode.
Parameters
Please refer to the following table to set the desired switching time between 1/50000s and 10s.
PLEASE NOTE
Parameters 01 to 03 are currently not applicable. They are reserved for future design.
<XX> switching
time [s]
01 1/100000
02 1/80000
03 1/64000
04* 1/50000
05* 1/40000
06* 1/32000
07* 1/25000
08* 1/20000
09* 1/16000
Image Engineering
The column moves from bottom to top
Table 9
<XX> switching
time [s]
21 1/1600
22 1/1500
23 1/1300
24 1/1250
25 1/1000
26 1/800
27 1/640
28 1/600
29 1/500
<XX> switching
time [s]
41 1/64
42 1/60
43 1/50
44 1/40
45 1/32
46 1/30
47 1/25
48 1/20
49 1/16
<XX> switching
time [s]
61 0.8s
62 1s
63 1.25s
64 1.3s
65 1.5s
66 1.6s
67 2s
68 2.5s
69 3s
