Description
"LED-Panel.exe -getCameraTrigger" returns the current state of the digital input "Camera
Trigger."
Return parameters
Return value Description
0
1

6.2.12 Get Stop Trigger Input State

Function
getStopTrigger
Description
"LED-Panel.exe -getStopTrigger" returns the state of the digital input "Stop Trigger."
Return parameters
Return value
0
1
6.2.13 Get the Number of Currently Activated LED
Function
getCurrentLED
Description
With the function "LED-Panel.exe -getCurrentLED," it is possible to read which LED is currently
turned on. The number of switching periods occurred after activating the "Camera Trigger"
input.
Image Engineering
digital input "Camera Trigger" is not activated
digital input "Camera Trigger" is activated
Table 2
Description
digital input "Stop Trigger" is not activated
digital input "Stop Trigger" is activated
Table 3
