Parameters
XXX – backlight intensity in steps of 1%; can be set from 0 (OFF) to 100 (fully ON).
Example
To set intensity to 24 % call LED-Panel.exe -setDisplayBrightness 24
6.2.20 Get the Intensity of the Display Back Light
Function
getDisplayBrightness
Description
With the function "LED-Panel.exe -getDisplayBrightness," it is possible to read the intensity of
the backlight illumination of the LCD display.
Return Parameters
After executing the function "LED-Panel.exe -getDisplayBrightness," the device will return a
one-, two- or three-digits value of the backlight intensity in %.
For instance:
Return value 27 means that the intensity of the backlight is 27%.
Return value 0 means that the backlight is turned OFF.
Return value 100 means that the intensity of the backlight is 100%.
6.2.21 Set the Direction of the LEDs for "Response Time" and "Exposure
Time" Modes
Function
setDirectionSingle <X>
Description
"LED-Panel.exe -setDirectionSingle <X>" switches the desired moving direction of the LEDs.
There are eight possible directions.
Parameters
<X>
1
2
Image Engineering
Description
Starting from the top left, run from left to right and to the bottom
Starting from the top right, run from right to left and to the bottom
