6.2.22 Get the Direction of the LEDs for "Response Time" and "Exposure
Time" Modes
Function
getDirectionSingle
Description
The function "LED-Panel.exe -getDirectionSingle" returns the current moving direction of the
LEDs in the "Response Time" and "Exposure Time" modes.
Return values
After executing this function, the device will return a one-digit value of the current LED direction.
For the possible return values list, please refer to Table 1.

6.2.23 Set the Direction of the LEDs for "Rolling Shutter" Mode

Function
setDirectionMulti <value>
Description
"LED-Panel.exe -setDirectionMulti <value>" switches the desired moving direction of the LED
columns (each one consisting of ten LEDs).
There are four possible directions.
Parameters
<value>
1
2
3
Image Engineering
Starting from the bottom left, run from left to right and to the top
Starting from bottom right, run from right to left and to the top
Starting from top left, run from top to bottom and to the right
Starting from top right, run from top to bottom and to the left
Starting from bottom left, run from bottom to top and to the right
Starting from bottom right, run from bottom to top and to the left
Table 8
Description
The column moves from left to right
The column moves from right to left
The column moves from top to bottom
