Return parameters
Return value
1
2
Example
LED-Panel.exe -getTriggerMode
After the execution of the command, the device will return the numerical value of the activated
trigger mode.

6.2.5 Set LEDs Switching Time

Function
setTime <time>
Description
With the function "LED-Panel.exe -setTime <time>," it is possible to set the switching time (cycle
duration) of the LED-Panel.
Parameters
Value range LED-Panel V5: from 0.00002-9.9[s]
Value range LED-Panel V4: from 0.0002-9.9[s]
Value precision:
Frame Rate Mode
Value range LED-Panel V5: 1.0 - 200.0[Hz]
Value range LED-Panel V4: 1.0 - 100.0[Hz]
Image Engineering
Description
internal (continuous) trigger
external (single) trigger
0.00002 - 0.0001
0.0001 - 0.001
0.001 - 0.01
0.01 - 0.1
0.1 - 1.0
1.0 - 9.9
steps of 0.000001[s]
steps of 0.00001[s]
steps of 0.0001[s]
steps of 0.001[s]
steps of 0.01[s]
steps of 0.1[s]
steps of 0.1[Hz]
steps of 0.1 – 0.2 – 0.5[Hz]
