5 OPERATING INSTRUCTIONS SOFTWARE

5.1 Requirements

•
PC with Windows 7 32bit/64bit (or higher) operating system
•
One free USB port

5.2 Software installation

Run the installer for your Microsoft Windows operating system. During installation, device
drivers and additional software will be installed. Along with the LED-Panel software, the
installation includes:
•
Microsoft Visual C++ Redistributable
•
Hardware driver
Unless you changed the default installation path, you will find the directory "Image
Engineering\LED-Panel <version number>" in your "Program Files" folder after a successful
installation. Additionally a directory "Image Engineering\LED-Panel" is created in
<root>\Users\<username>\AppData\Roaming (example:
C:\Users\John_Doe\AppData\Roaming\Image Engineering) to store application settings.

5.3 Set up hardware and software for software control

Connect the power cord to the power supply on the side of the LED-Panel. Connect the power
supply to electricity.
Connect the USB cable to the LED-Panel and your PC. Switch on LED-Panel by setting the
power switch to "I." The power switch is located beside the power supply.

5.4 Software activation

Start the iQ-LED software by clicking the 'iQ-LED.exe' or the iQ-LED icon on your desktop.
When you start the LED-Panel software for the first time, you will be asked to activate the
software (Figure 14). To do this, connect your LED-Panel to the computer and enter the
provided license key. The key is in a text file on the USB shipped with the product. After the
activation process is completed, the software starts, and a license file will be written to
C:\Users\<username>\AppData\Roaming\Image Engineering\LED-Panel\Data\.
Image Engineering
Figure 14
