- Page 1 Box User Manual August 8, 2022 Image Engineering GmbH & Co. KG · Im Gleisdreieck 5 · 50169 Kerpen · Germany T +49 2273 99 99 1-0 · F +49 2273 99 99 1-10 · www.image-engineering.com...
- Page 2 3.1 Camera depth and height ..................4 3.2 Camera pitch and yaw ................... 4 3.3 Camera fine leveling ....................4 3.4 Chart positioning ....................5 ILLUMINATION INTENSITY ..................6 CHART HANDLING ....................6 FIELD OF VIEW CALCULATION................. 7 Image Engineering Seite 2 von 7...
- Page 3 3 CAMERA AND CHART ALIGNMENT You can choose between two different chart setups when using your iQ-FoV Box. These setups will allow you to analyze your images automatically with the iQ-Analyzer-X. For high performance, it is crucial to align your camera inside the box and position the three different chart types in the correct areas.
- Page 4 You can adjust this pin to use your remote control device from other directions. Camera fine leveling The fine leveling of your camera can be regulated with the leveling tool positioned directly under the camera attachment. Image Engineering Seite 4 von 7...
- Page 5 (B) on the left wall and one chart (A) on the right wall. Use folding and rotating for each chart so that its border looks straight-lined in the resulting image: Image 01: Chart positions, Setup 1 Image Engineering Seite 5 von 7...
- Page 6 Measuring and noting the lux value inside the box on a defined position is recommended. 5 CHART HANDLING You must be very careful with the test charts. While positioning, please ensure that you will not touch the chart surface. Image Engineering Seite 6 von 7...
- Page 7 Box measured from the front plate (see the left side of Image 04). The measure's origin is shown in Image 04 on the right side and is located in the center of the front plate.
