5 OPERATING INSTRUCTIONS SOFTWARE

5.1 Requirements

•
PC with Windows 7 32bit/64bit (or higher) operating system
•
One free USB port

5.2 Software installation

Run the installer for your Microsoft Windows operating system. During installation device drivers
and additional software will be installed. Along with the LED-Panel software the installation
includes:
•
Microsoft Visual C++ Redistributable
•
Hardware driver
Unless you changed the default installation path, you will find the directory "Image
Engineering\LED-Panel <version number>" in your "Program Files" folder after a successful
installation. Additionally a directory "Image Engineering\LED-Panel" is created in
<root>\Users\<username>\AppData\Roaming (example:
C:\Users\John_Doe\AppData\Roaming\Image Engineering) to store application settings.

5.3 Set up hardware and software for software control

Connect the power cord to the power supply on the side of LED-Panel V4. Connect the power
supply to electricity.
Connect the USB cable to the LED-Panel V4 and to your PC. Switch on LED-Panel V4 by
setting the power switch to "I". The power switch is located beside the power supply.

5.4 Software activation

Start the iQ-LED software by clicking the 'iQ-LED.exe' or the iQ-LED icon on your desktop.
When you start the LED-Panel software for the first time you will be asked to activate the
software (Figure 14). In order to do this connect your LED-Panel V4 to the computer and enter
the provided license key. The key is located in a text file on the DVD shipped with the product.
After the activation process successfully completed the software starts and a license file will be
written to C:\Users\<username>\AppData\Roaming\Image Engineering\LED-Panel\Data\.
NOTE
The LED-Panel hardware must be connected to your computer via USB during the
activation process.
Operating instructions software
Figure 14
17
